Brand:Schneider PLC Item No.:Schneider 140DDO35300R Product Origin: France Product Dimensions:250 × 40 × 120 mm Product Weight:0.55 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Schneider 140DDO35300R is a high-performance discrete output module designed for the Modicon Quantum automation platform. It provides reliable 24 V DC output control for a wide range of industrial field devices, including relays, solenoids, actuators, and signaling equipment.
With its 32-channel high-density architecture, this module is engineered for large-scale automation systems where stable switching performance, fast response time, and long-term operational reliability are critical. It integrates seamlessly into Quantum backplane systems, making it suitable for both system expansion and replacement applications.
Technical Specifications
Item
Description
Manufacturer
Schneider Electric
Model
140DDO35300R
Product Type
Discrete Output Module
Platform
Modicon Quantum
Output Channels
32 points
Output Type
24 V DC Solid-State Output
Channel Grouping
4 groups of 8 outputs
Output Voltage Range
19.2 – 30 V DC
Maximum Module Current
16 A
Group Current Limit
4 A per group
Response Time
≤ 1 ms
Protection
Group-level fuse protection
Diagnostics
Per-channel LED indicators
Backplane Interface
Quantum Rack Compatible
Operating Temperature
0°C to 60°C
Storage Temperature
-40°C to 85°C
Certifications
CE, UL, CSA (depending on configuration)
Mechanical Dimensions & Weight
Parameter
Value
Height
250 mm
Width
40 mm
Depth
120 mm
Weight
Approx. 0.45 – 0.55 kg
Recommended Compatible Modules
The 140DDO35300R is commonly used with the following Modicon Quantum modules:
140CPU65150 / 140CPU67160 CPU Modules
140CPS Series Power Supply Modules
140DDI35300 Digital Input Module
140ACI04000 Analog Input Module
140ACO02000 Analog Output Module
140CRA93100 Remote I/O Adapter
140CRP93100 Communication Processor Module
Frequently Used Quantum Series Products
In large-scale industrial systems, these modules are often deployed together:
140CPU43412A
140CPU65150
140CPU67160
140DDI35300
140DAI35300
140DDO35310
140XBP Rack Series
140CPS Power Supply Series
140CRA93100
140CRP93100
Application Fields
The 140DDO35300R is widely used in industrial automation environments requiring precise and reliable output control:
Manufacturing automation lines
Process control systems
Oil and gas production facilities
Power generation plants
Water treatment systems
Chemical processing industries
Packaging machinery
Mining and heavy industry control systems
Infrastructure automation
OEM machine control applications
Key Benefits
32-channel high-density output design for compact control systems
Stable 24 V DC industrial output performance
Fast switching response for real-time automation control
LED diagnostics for quick fault identification
Group-level protection improves system reliability
Seamless integration with Modicon Quantum architecture
Suitable for continuous industrial operation
Supports scalable system expansion
Designed for harsh industrial environments
Reduces maintenance and downtime costs
Technical FAQs
1. What is the main function of the 140DDO35300R?
It provides 32-channel digital output control for Modicon Quantum automation systems.
2. What type of output does it support?
It supports 24 V DC solid-state discrete outputs.
3. How many output channels are available?
The module provides 32 output channels arranged in 4 groups of 8.
4. What is the response speed?
The switching response time is typically ≤ 1 ms.
5. Does the module include protection features?
Yes, it includes group-level fuse protection for improved operational safety.
6. What are the dimensions of this module?
Height: 250 mm, Width: 40 mm, Depth: 120 mm.
7. What is the weight of the module?
Approximately 0.45 – 0.55 kg depending on production revision.
8. Is it compatible with existing Quantum systems?
Yes, it is fully compatible with Modicon Quantum backplane architecture.
9. What industries use this module?
It is widely used in manufacturing, energy, oil & gas, water treatment, and process automation industries.
10. Why is this module widely used?
Because it combines high-density output capability, fast response time, and reliable integration with the Modicon Quantum platform, making it ideal for industrial-grade automation systems.
