The Schneider 170ADM39010 is a Modicon Momentum series discrete I/O base module designed for flexible industrial automation applications. It integrates digital inputs and outputs within a single compact platform, providing efficient signal processing for PLC-based control systems.
This module is widely used in distributed automation architectures where space efficiency, stable signal handling, and easy system integration are essential. It supports 24 V DC industrial signals and is commonly deployed in manufacturing, packaging, material handling, and general machine control systems.
Its modular Momentum design allows direct mounting with compatible processors and communication adapters, enabling scalable system configuration without complex wiring changes.
Technical Specifications
| Item | Description |
|---|---|
| Manufacturer | Schneider Electric |
| Model | 170ADM39010 |
| Product Family | Modicon Momentum |
| Module Type | Discrete I/O Base Module |
| Input Channels | 16 Digital Inputs |
| Output Channels | 12 Digital Outputs |
| Input Voltage | 24 V DC |
| Output Type | Solid-state switching outputs |
| Logic Type | Positive logic |
| Input Standard | IEC 1131-2 Type 1 |
| Output Load Capability | Up to 0.5 A per point (typical Momentum architecture) |
| Response Time | < 0.1 ms (outputs) |
| Mounting | Momentum base system backplane |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Isolation | Channel-to-bus isolation (typical Momentum architecture) |
Mechanical Dimensions & Weight
| Parameter | Value |
| Dimensions (H × W × D) | 141.5 × 125 × 47.5 mm |
| Weight | Approx. 0.26 kg |
Compatible System Components
The 170ADM39010 is typically used within Modicon Momentum systems alongside:
- Momentum CPU processors
- Communication adapters (Modbus / Ethernet / fieldbus)
- Power supply bases
- 170 series I/O expansion modules
- Remote I/O network adapters
- Terminal base assemblies
Commonly Used Momentum Series Modules
Frequently paired or related modules in industrial applications include:
- 170ENT11000 Communication Adapter
- 171CCC78010 Processor Module
- 170PNT11020 Network Adapter
- 170ADI / 170ADO series modules
- Momentum power supply bases
- Remote I/O expansion units
