The Schneider 490NTW00002 is a shielded Ethernet ConneXium patch cable designed for industrial automation and control systems. It provides stable and interference-resistant data transmission between PLCs, controllers, switches, and industrial communication devices.
Engineered for Modicon and ConneXium network environments, this cable ensures high signal integrity and reliable Ethernet connectivity in demanding industrial conditions. It is widely used in factory automation, machine control systems, and industrial networking applications where consistent communication performance is required.
With its factory-assembled RJ45 connectors and shielded twisted-pair construction, the 490NTW00002 reduces installation time while improving network stability and noise immunity.
Technical Specifications
| Item | Description |
|---|---|
| Manufacturer | Schneider Electric |
| Model | 490NTW00002 |
| Product Type | Ethernet Patch Cable |
| Series | ConneXium |
| Cable Type | Shielded twisted pair (SF/UTP) |
| Category | Cat5 / Cat7A (depending on system classification) |
| Connector Type | RJ45 to RJ45 |
| Pin Configuration | 1:1 straight-through |
| Cable Length | 2 m |
| Shielding | Yes (EMI protection) |
| Application | Industrial Ethernet communication |
| Compatibility | Modicon / ConneXium / automation devices |
| Jacket Color | Green / Grey (variant dependent) |
Mechanical Dimensions & Weight
| Parameter | Value |
| Dimensions (H × W × D) | 2000 × 10 × 10 mm (cable length form factor) |
| Weight | Approx. 0.06 – 0.13 kg |
Recommended Compatible Systems
The 490NTW00002 is commonly used with Schneider Electric automation products such as:
- Modicon PLC controllers
- ConneXium Ethernet switches
- Zelio Logic smart relays
- Lexium servo drives
- Industrial HMI systems
- SCADA communication networks
- Remote I/O Ethernet modules
Common Industrial Network Components
This cable is frequently used in Ethernet-based industrial architectures including:
- Modicon Quantum systems
- Modicon M340 / M580 PLC networks
- Industrial Ethernet switches
- Distributed control systems (DCS)
- Factory automation networks
- Machine-level control systems
