The Bently Nevada 330192-00-12-90-05 is a 3300 XL 8 mm Extended Temperature Range (ETR) proximity probe designed for precise, non-contact measurement of shaft vibration and radial position in rotating machinery. It is part of the Bently Nevada 3300 XL proximity transducer system, widely used in machinery protection and condition monitoring applications.

This model features an armored cable construction, a 9.0-meter integral cable (90 option), and hazardous-area certification (05 option, typically CSA/ATEX/IECEx depending on configuration). It is engineered for harsh industrial environments where mechanical protection, long cable reach, and compliance-grade installation are required.

Technical Specifications

Item	Description
Manufacturer	Bently Nevada (Baker Hughes)
Model	330192-00-12-90-05
Product Type	3300 XL 8 mm ETR Armored Proximity Probe
Measurement Principle	Eddy current displacement sensing
System Series	3300 XL Proximity Transducer System
Probe Diameter	8 mm
Thread Size	3/8-24 UNF
Case Length Option	12 – configuration variant within 3300 XL probe family
Unthreaded Length	00 – standard mounting configuration
Cable Length Option	90 – 9.0 m integral cable
Cable Type	Armored, shielded triaxial cable
Agency Approval	05 – hazardous area certified configuration
Output Type	Analog displacement signal
Application	Vibration, shaft position, radial displacement monitoring

Mechanical Dimensions & Weight

Parameter	Value
Dimensions (L × W × H)	9000 × 8 × 8 mm (assembly reference)
Weight	Approx. 0.40 kg – 0.85 kg (armored cable dependent)

Recommended Related Models

The 330192-00-12-90-05 is commonly used with:

Bently Nevada 3300 XL Proximitor® Sensor
330190 Series Extension Cable (when system architecture requires separation)
Bently Nevada 3500/40M Vibration Monitor Module
Bently Nevada 3500 Machinery Protection System
Standard 3300 XL probe mounting hardware

Popular Bently Nevada Models

Frequently used in rotating machinery monitoring systems:

3300 XL 8 mm Proximity Probe series
3300 XL Proximitor Sensor
330190 Extension Cable family
3500/22M Transient Data Interface
3500/42M Vibration Monitoring Module
3500/15 Power Supply Module

Applications

This probe is widely used in industrial condition monitoring systems, including:

Steam turbines
Gas turbines
Centrifugal compressors
Industrial pumps
Electric motors
Generators
Oil & gas facilities
Petrochemical plants
Power generation stations
Heavy rotating machinery

Advantages

Armored cable for enhanced mechanical protection in harsh environments
High-precision non-contact vibration and position measurement
Stable operation in high-temperature and high-vibration conditions
Compatible with Bently Nevada 3300 XL monitoring architecture
Designed for long-distance installations (9.0 m cable)
Supports continuous machinery protection and diagnostics
Resistant to EMI and industrial electrical noise
Suitable for hazardous-area certified installations
Reliable long-term signal stability for critical assets
Optimized for turbine and compressor monitoring systems

Technical FAQs

1. What is the function of the 330192-00-12-90-05?

It measures shaft vibration and radial displacement using eddy current non-contact sensing technology.

2. What system is it compatible with?

It is designed for the Bently Nevada 3300 XL 8 mm proximity transducer system.

3. What does the “90” option indicate?

It represents a 9.0-meter integral cable length.

4. Is this an armored probe?

Yes. The model uses an armored cable construction for enhanced durability.

5. What does the “05” suffix mean?

It indicates hazardous-area certification options (CSA/ATEX/IECEx depending on configuration).

6. What measurement principle does it use?

It uses eddy current displacement measurement technology.

7. What are the dimensions?

Approximately 9000 × 8 × 8 mm including cable assembly.

8. What is the weight?

Approximately 0.40–0.85 kg, depending on armor and configuration.

9. Where is it commonly used?

It is used in turbines, compressors, pumps, motors, and generators.

10. Why is this probe widely used?

Because it provides rugged mechanical protection, long cable reach, and reliable vibration monitoring performance for critical industrial machinery systems.
