Brand:Schneider PLC Item No.:Schneider ATS22D88Q Product Origin:France Product Dimensions:229 × 145 × 207 mm Product Weight:5.3 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Schneider ATS22D88Q is a high-performance Soft Starter from the Altistart 22 series, designed to provide smooth acceleration and deceleration for three-phase asynchronous motors. By minimizing inrush current and mechanical stress during startup, it helps extend equipment life, improve operational reliability, and reduce maintenance costs.
Supporting demanding industrial environments, the ATS22D88Q delivers advanced motor control with integrated protection functions, making it an ideal choice for pumps, fans, compressors, conveyors, crushers, and other heavy-duty applications. Its compact design and user-friendly configuration simplify installation while ensuring stable performance in continuous industrial operations.
Product Specifications
Item
Description
Manufacturer
Schneider Electric
Model
ATS22D88Q
Product Type
Soft Starter
Product Series
Altistart 22
Motor Type
Three-phase asynchronous motor
Rated Operational Current
88 A
Rated Operational Voltage
230...440 VAC
Supply Frequency
50/60 Hz
Control Voltage
100...240 VAC
Built-in Protection
Motor overload, phase loss, overcurrent, thermal protection
Starting Modes
Voltage ramp, current limit, torque control
Communication
Compatible with industrial automation systems via optional communication modules
Mounting Method
Panel mounting
Protection Degree
IP20
Physical Dimensions & Weight
Parameter
Value
Dimensions (L × W × H)
229 × 145 × 207 mm
Weight
Approx. 5.3 kg
Recommended Related Models
The ATS22D88Q is commonly installed together with the following products:
Schneider ATS22D62Q Soft Starter
Schneider ATS22D75Q Soft Starter
Schneider ATS22D105Q Soft Starter
Schneider ATS22C11Q Soft Starter
Schneider TeSys D Contactors
Schneider Harmony Push Buttons
Schneider Modicon PLC Series
Popular Schneider Models
Schneider Electric offers a comprehensive portfolio of industrial automation products, including:
ATS22D32Q Soft Starter
ATS22D47Q Soft Starter
ATS22D62Q Soft Starter
ATS48 Series Soft Starters
Modicon M340 PLC
Modicon M580 PLC
Altivar Process ATV630 Variable Speed Drive
Altivar ATV930 Variable Speed Drive
Typical Applications
The ATS22D88Q is widely used in industrial automation and motor control systems, including:
Water treatment facilities
HVAC systems
Industrial pumping stations
Air compressors
Belt conveyors
Crushers
Mixers and agitators
Mining equipment
Manufacturing production lines
Power generation facilities
Key Advantages
Smooth motor starting and stopping to reduce mechanical wear
Minimizes electrical inrush current during startup
Extends motor and equipment service life
Integrated motor protection functions improve system reliability
Advanced torque control for demanding applications
Compact design saves valuable control cabinet space
Simple parameter configuration and commissioning
High operational stability in continuous-duty environments
Compatible with Schneider automation solutions
Ideal for industrial motor control and energy-efficient operation
Technical FAQs
1. What is the Schneider ATS22D88Q?
It is an Altistart 22 soft starter designed to provide controlled starting and stopping of three-phase asynchronous motors.
2. What is its rated current?
The rated operational current is 88 A.
3. What voltage range does it support?
It operates on 230 to 440 VAC, 50/60 Hz.
4. Which motors is it designed for?
It is intended for three-phase squirrel-cage asynchronous motors used in industrial applications.
5. Does it include motor protection?
Yes. It incorporates motor overload, phase loss, overcurrent, and thermal protection functions.
6. What are the physical dimensions?
The unit measures 229 × 145 × 207 mm (L × W × H).
7. How much does it weigh?
The approximate weight is 5.3 kg.
8. Where is the ATS22D88Q commonly used?
It is widely used in pumps, compressors, conveyors, fans, mixers, HVAC systems, and water treatment facilities.
9. Can it communicate with PLC systems?
Yes. It supports optional communication modules for integration with industrial automation and PLC networks.
10. Why choose the Schneider ATS22D88Q?
The ATS22D88Q delivers reliable soft starting, comprehensive motor protection, reduced maintenance costs, and excellent performance for demanding industrial motor control applications, making it a dependable solution for modern automation systems.
