Brand:Schneider PLC Item No.:Schneider ATS22D88S6U Product Origin:France Product Dimensions:207 × 145 × 247 mm Product Weight:8.35 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Schneider ATS22D88S6U is an Altistart 22 Soft Starter engineered to provide smooth starting and stopping of three-phase asynchronous motors. Designed for industrial applications that require dependable motor control, it effectively limits starting current, minimizes mechanical shock, and extends the service life of motors and driven equipment.
With an 88 A rated current, integrated bypass, and built-in motor protection functions, the ATS22D88S6U is an ideal solution for pumps, fans, compressors, conveyors, and other heavy-duty machinery. Its compact design, intuitive operation, and Modbus communication capability make it easy to integrate into modern automation systems.
Technical Specifications
Item
Description
Manufacturer
Schneider Electric
Model
ATS22D88S6U
Product Type
Soft Starter
Product Series
Altistart 22
Motor Type
Three-phase asynchronous motor
Rated Operational Current
88 A
Rated Supply Voltage
208...600 VAC
Control Voltage
110 VAC
Supply Frequency
50/60 Hz
Rated Motor Power
25 HP @ 208 V / 30 HP @ 230 V / 60 HP @ 460 V / 75 HP @ 575 V
Starting Method
Torque control with current limitation
Integrated Bypass
Yes
Communication
Modbus (RS485)
Protection Rating
IP20
Mounting Method
Panel mounting with heat sink
Physical Dimensions & Weight
Parameter
Value
Dimensions (L × W × H)
207 × 145 × 247 mm
Weight
Approx. 8.35 kg
Recommended Related Models
The ATS22D88S6U is frequently used together with:
Schneider ATS22D62S6U Soft Starter
Schneider ATS22D105S6U Soft Starter
Schneider ATS22C11S6U Soft Starter
Schneider ATS48 Series Soft Starters
Schneider TeSys D Contactors
Schneider Compact NSX Circuit Breakers
Schneider Modicon M340 PLC
Popular Schneider Models
Schneider Electric offers a broad portfolio of industrial automation products, including:
ATS22D32S6U Soft Starter
ATS22D47S6U Soft Starter
ATS22D75S6U Soft Starter
ATS48C Series Soft Starters
Modicon M340 PLC
Modicon M580 PLC
Altivar ATV630 Variable Speed Drive
Altivar ATV930 Variable Speed Drive
Applications
The ATS22D88S6U is widely used in industrial automation and motor control systems, including:
Water treatment plants
HVAC systems
Industrial pumping stations
Air compressors
Conveyor systems
Crushers
Fans and blowers
Mining equipment
Manufacturing production lines
Power generation facilities
Advantages
Smooth motor acceleration and deceleration
Reduces inrush current during motor startup
Integrated bypass reduces heat generation and energy consumption
Built-in overload and phase protection functions
Advanced torque control for demanding applications
Compact design saves panel space
Supports Modbus communication for automation integration
Improves equipment reliability and minimizes maintenance
Suitable for standard and heavy-duty industrial applications
Excellent compatibility with Schneider Electric automation solutions
Technical FAQs
1. What is the Schneider ATS22D88S6U?
It is an Altistart 22 soft starter designed for controlled starting and stopping of three-phase asynchronous motors.
2. What is the rated current?
The ATS22D88S6U has a rated operational current of 88 A.
3. What input voltage does it support?
It operates with a supply voltage of 208 to 600 VAC.
4. What is the control voltage?
The control circuit operates at 110 VAC.
5. Does it include an internal bypass?
Yes. An integrated bypass is built in to improve efficiency and reduce heat dissipation.
6. What are the physical dimensions?
The dimensions are 207 × 145 × 247 mm (L × W × H).
7. What is the weight?
The unit weighs approximately 8.35 kg.
8. Which communication protocol does it support?
It supports Modbus communication via RS485, allowing seamless integration with PLC and SCADA systems.
9. What applications is it suitable for?
It is ideal for pumps, fans, compressors, conveyors, mixers, HVAC equipment, and other industrial motor-driven machinery.
10. Why choose the Schneider ATS22D88S6U?
The ATS22D88S6U combines advanced soft-start technology, integrated motor protection, communication capability, and proven industrial reliability, making it an excellent choice for improving motor performance while reducing maintenance and operating costs.
