Brand:Schneider PLC Item No.:Schneider ATS22D88S6 Product Origin:France Product Dimensions:207 × 145 × 295 mm Product Weight:13 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Schneider ATS22D88S6 is an Altistart 22 series soft starter designed for controlled starting and stopping of three-phase asynchronous motors. It reduces inrush current during motor startup, minimizes mechanical stress, and improves overall system reliability in industrial applications such as pumps, compressors, conveyors, and HVAC systems.
It is widely used as a cost-effective alternative to variable speed drives when only soft starting is required.
Technical Specifications
Item
Description
Manufacturer
Schneider Electric
Model
ATS22D88S6
Product Series
Altistart 22
Product Type
Soft Starter
Motor Type
Three-phase asynchronous motor
Rated Current
88 A
Supply Voltage
230–600 VAC
Control Voltage
AC control (variant dependent)
Starting Method
Voltage ramp / current limitation
Integrated Bypass
Yes
Communication
Modbus (optional depending on configuration)
Protection Functions
Overload, phase loss, thermal protection
Physical Dimensions & Weight
Parameter
Value
Dimensions (L × W × H)
207 × 145 × 295 mm
Weight
Approx. 13 kg
Recommended Related Models
Schneider ATS22D62S6
Schneider ATS22D75S6
Schneider ATS22D105S6
Schneider ATS48 Series Soft Starters
Schneider Altivar ATV630 / ATV930 Drives
Schneider TeSys D Contactors
Applications
Water treatment systems
HVAC installations
Industrial pumps
Air compressors
Conveyor systems
Crushers and mixers
Mining machinery
Manufacturing lines
Power plant auxiliary systems
Key Advantages
Reduces motor starting current
Protects mechanical transmission systems
Extends motor service life
Integrated motor protection functions
Built-in bypass reduces heat loss
Easy panel installation and integration
Stable operation in continuous-duty environments
Compatible with Schneider automation ecosystem
Cost-efficient alternative to VFDs for soft start-only needs
Improves electrical network stability
Technical FAQs
1. What is the ATS22D88S6 used for?
It is used for controlled soft starting and stopping of three-phase asynchronous motors.
2. What is the rated current?
It supports 88 A motor applications.
3. What is the full size of the unit?
The dimensions are 207 × 145 × 295 mm (L × W × H).
4. What is the weight?
The unit weighs approximately 13 kg.
5. Does it support motor protection?
Yes, it includes overload, phase loss, and thermal protection.
6. Does it include a bypass?
Yes, it has an integrated bypass contactor.
7. What type of motors is it used for?
Three-phase squirrel-cage induction motors.
8. Can it be used in pumps and compressors?
Yes, it is widely used in both applications.
9. Is it compatible with automation systems?
Yes, it can integrate with PLC systems via communication modules.
10. Why choose this model?
Because it provides stable motor starting, reduces mechanical wear, and improves system reliability in industrial environments.
