Brand:Schneider PLC Item No.:ATS01N209QN Product Origin:France Product Dimensions:124 x 45 x 131 mm Product Weight:0.42 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Schneider Electric ATS01N209QN belongs to the Altistart 01 soft starter family. It operates by gradually increasing voltage supplied to an AC induction motor, enabling smooth acceleration instead of direct full-voltage starting.
This reduces mechanical wear on driven equipment and limits electrical stress on the power system, making it suitable for standard industrial motor control applications requiring simple and reliable starting performance.
Technical Specifications
Parameter
Specification
Product Type
Soft Starter
Series
Altistart 01
Model
ATS01N209QN
Rated Current
9 A
Supply Voltage
380–415 VAC
Motor Type
AC induction motor
Control Method
Voltage ramp start
Dimensions (W × H × D)
124 × 45 × 131 mm
Weight
0.42 kg / 0.93 lb
Mounting Type
DIN rail mounting
Protection Degree
IP20
Installation Orientation
Vertical mounting
Recommended Related Models
Schneider ATS01N206QN Soft Starter
Schneider ATS01N206RT Soft Starter
Schneider ATS01N212FT Soft Starter
Siemens 3RW30 Series Soft Starters
ABB PSR Series Soft Starters
Popular Related Models
Schneider ATS22 Series Soft Starters
Siemens 3RW40 Series Soft Starters
ABB PSTX Series Soft Starters
Danfoss MCD 201 Soft Starter
Rockwell SMC-3 Series
Applications
The ATS01N209QN is used in general-purpose motor control systems where smooth starting is required without variable speed control.
Typical applications include:
HVAC ventilation and air handling systems
Water pumping and circulation systems
Small industrial compressors
Conveyor and material handling systems
Packaging machinery
Light automation equipment
Auxiliary industrial motor drives
It is commonly used in OEM machine panels and compact industrial control systems.
Advantages
Reduces motor starting current
Minimizes mechanical stress during startup
Compact DIN-rail mounted design
Stable and repeatable soft-start performance
Integrated bypass for efficient operation after ramp-up
Simple configuration and commissioning
Suitable for repetitive start cycles
Improves motor and system reliability
Technical FAQs
Q1: What is the main function of ATS01N209QN?
It controls motor starting by gradually increasing voltage to reduce current and mechanical stress.
Q2: Does it provide speed control?
No, it does not control motor speed; it only manages starting and stopping.
Q3: What type of motor is compatible?
Three-phase AC induction motors.
Q4: What is the advantage over direct-on-line starting?
It reduces inrush current and mechanical shock during motor startup.
Q5: Does it include bypass operation?
Yes, it switches to internal bypass after the motor reaches full speed.
Q6: Is it suitable for heavy-load applications?
It is designed for light to medium duty motor loads.
Q7: Does it require complex programming?
No, it is designed for simple setup and commissioning.
Q8: What happens if overload occurs?
The device will trigger protection and stop operation.
Q9: Is it suitable for frequent starts?
Yes, it supports repeated start-stop operation cycles.
Q10: Is it a variable frequency drive (VFD)?
No, it is not a VFD and does not provide speed control.
