Brand:Schneider PLC Item No.:ATV12H037M2 Product Origin:France Product Dimensions:72 x 143 x 121.2 mm Product Weight:0.7 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Schneider ATV12H037M2 Frequency Converter is a compact variable speed drive designed for simple motor control tasks in industrial and commercial environments. It provides reliable speed regulation for small three-phase motors, improving energy efficiency and process stability.
Technical Specifications
Parameter
Value
Model
ATV12H037M2
Product Series
Altivar 12
Product Type
Frequency Converter / VFD
Supply Voltage
200–240 V AC (single-phase input)
Output Voltage
0–240 V AC (three-phase output)
Rated Power
0.37 kW
Output Current
2.4 A
Control Method
V/f Control
Communication
Modbus RS485
Protection Functions
Overload, thermal, short-circuit protection
Switching Frequency
Up to 4 kHz
Operating Temperature
-10°C to +60°C
Protection Rating
IP20
Dimensions
143 × 72 × 121.2 mm
Weight
0.7 kg
Recommended Related Models
Model
Product Name
ATV12H018M2
Schneider Altivar 12 Frequency Converter
ATV12H055M2
Schneider Altivar 12 Variable Speed Drive
ATV320U04M2
Schneider Altivar 320 Compact VFD
ATV320U06M2
Schneider Altivar 320 Industrial Drive
Popular Related Models
Model
Product Name
ATV12H075M2
Schneider Altivar 12 VFD
ATV310H037N4
Schneider Altivar 310 Frequency Converter
ATV320U07M2
Schneider Altivar 320 Compact Drive
ATV12P037M2
Schneider Altivar 12 OEM Drive Variant
Applications
• Designed for compact industrial and commercial motor speed control applications.
• Suitable for small pumps used in water circulation, cooling systems, and light fluid handling processes.
• Used in HVAC systems such as small fans, ventilation units, and air extraction equipment.
• Applied in light conveyor systems for packaging, sorting, and material transport.
• Ideal for OEM machinery requiring simple and reliable variable speed control.
Key Advantages
• Provides smooth and stable motor speed regulation using efficient V/f control technology.
• Integrated Modbus RS485 communication enables easy integration with PLC and automation systems.
• Compact design allows installation in space-limited control cabinets.
• Built-in motor protection functions enhance operational safety and equipment reliability.
• Simple parameter structure enables fast commissioning and user-friendly configuration.
Technical FAQs
Q1: What motor type is supported by this drive?
It is designed for three-phase asynchronous motors with single-phase 200–240 V input.
Q2: What is the rated power of this model?
It has a rated output power of 0.37 kW.
Q3: Does it support industrial communication?
Yes, it supports Modbus RS485 communication protocol.
Q4: Is it suitable for HVAC applications?
Yes, it is widely used in small fans and ventilation systems.
Q5: What control method does it use?
It uses V/f (voltage/frequency) control for basic motor speed regulation.
Q6: Does it include motor protection?
Yes, it includes overload, thermal, and fault protection functions.
Q7: Can it be used for pump control?
Yes, it is commonly used in small pump applications.
Q8: What is the installation environment?
It is designed for indoor installation inside a ventilated control cabinet.
Q9: Does it require complex setup?
No, it is designed for quick and simple commissioning.
Q10: Is it suitable for continuous operation?
Yes, it is designed for continuous industrial-duty operation.
