Brand:Epro PLC Item No.:PR6424/111-000 Product Origin:Germany Product Dimensions:Sensor Head Diameter: 16 mm Product Weight:0.2 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Epro PR6424/111-000 16 mm Eddy Current Sensor is a high-precision non-contact displacement measurement device designed for critical rotating machinery monitoring. It is widely used in industrial condition monitoring systems where accurate shaft vibration and position data are essential for equipment safety and performance optimization.
Technical Specifications
Parameter
Value
Model
PR6424/111-000
Series
Epro PR6424
Type
Eddy Current Displacement Sensor
Measurement Principle
Non-contact eddy current
Sensor Head Diameter
16 mm
Sensitivity
4 V/mm (typical system level)
Measurement Range
±2.0 mm (static) / up to 1,000 µm dynamic
Target Material
Conductive ferromagnetic steel
Minimum Shaft Diameter
≥80 mm
Operating Temperature
-35°C to +180°C
Signal Output
Analog voltage via signal converter
Cable Type
High-temperature shielded industrial cable
Installation Type
Fixed proximity probe mounting
Weight
0.2 kg
Recommended Related Models
Model
Product Name
PR6424/010-130
Epro 16 mm Eddy Current Sensor
PR6424/003-010
Epro High Precision Vibration Sensor
PR6424/012-000
Epro Shaft Displacement Probe
CON021
Epro Signal Converter Module
Popular Related Models
Model
Product Name
PR6423/010-040
Epro Eddy Current Proximity Sensor
PR9268/202-000
Epro Vibration Monitoring Sensor
CON011
Epro Signal Conditioning Unit
MMS6000 System
Epro Machinery Monitoring System
Applications
• Used in turbomachinery shaft vibration monitoring systems for steam, gas, and hydro turbines.
• Applied in rotating equipment such as compressors, pumps, and large industrial fans for real-time displacement measurement.
• Suitable for condition monitoring systems in power generation plants to detect shaft eccentricity and axial movement.
• Integrated into machinery protection systems for early fault detection in high-speed rotating equipment.
• Used in predictive maintenance setups where continuous non-contact vibration feedback is required.
Key Advantages
• Non-contact eddy current measurement ensures stable performance without mechanical wear.
• High precision signal response enables accurate detection of micro-displacement in rotating shafts.
• Excellent stability in harsh industrial environments with high temperature and vibration conditions.
• Compatible with standard Epro signal converters for flexible system integration.
• Designed for long-term operation with minimal drift and consistent measurement reliability.
Technical FAQs
Q1: What is the operating principle of this sensor?
It uses eddy current technology to measure distance changes between the probe tip and conductive target surfaces.
Q2: What type of machinery is it typically used on?
It is commonly used on turbines, compressors, pumps, and large rotating industrial machines.
Q3: Does it require physical contact with the shaft?
No, it operates as a non-contact displacement and vibration sensor.
Q4: What kind of signals does it generate?
It produces a voltage signal proportional to the gap distance between sensor and target.
Q5: Is it suitable for high-speed rotating equipment?
Yes, it is designed for high-speed turbomachinery monitoring applications.
Q6: Can it detect both static and dynamic movement?
Yes, it measures both steady displacement and dynamic vibration signals.
Q7: What material is required on the target surface?
It is optimized for conductive ferromagnetic materials such as steel shafts.
Q8: Is it compatible with industrial monitoring systems?
Yes, it works with dedicated Epro signal conditioners and monitoring modules.
Q9: Does it require calibration during installation?
Yes, system calibration is typically required with the corresponding converter module.
Q10: Is it suitable for continuous operation?
Yes, it is designed for continuous industrial monitoring environments.
