Brand:Bently Nevada PLC Item No.:991-06-XX-01-05 Product Origin:USA Product Dimensions:100.1 x 73.9 x 53.3 mm Product Weight:0.43 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Bently Nevada 991-06-XX-01-05 164113-02 991 Thrust Sensor is a loop-powered thrust transmitter used for measuring axial displacement in rotating machinery. It converts input from proximity probe systems into a standardized 4–20 mA signal for control and protection systems.
Technical Specifications
Parameter
Value
Model
991-06-XX-01-05 / 164113-02
Series
Bently Nevada 991 Thrust Transmitter
Type
Axial Displacement / Thrust Transmitter
Measurement Principle
Eddy current-based proximity system
Input Signal
3300 NSv proximity probe system
Output Signal
4–20 mA analog thrust signal
Power Supply
Loop-powered (DC supply)
Operating Temperature
-40°C to +85°C
Enclosure Rating
Industrial sealed housing (IP-rated)
Installation
DIN rail / panel mount
Dimensions
100.1 x 73.9 x 53.3 mm
Weight
0.43 kg
Recommended Related Models
Model
Product Name
991-06-XX-01-00
Bently Nevada 991 Thrust Transmitter Variant
991-01-XX-02-05
Bently Nevada Thrust Transmitter
330130-045-11-05
Bently Nevada Extension Cable 4.5 m
330180-X2-05
Bently Nevada Preamplifier Sensor
Popular Related Models
Model
Product Name
330106-00-30-10-02-00
Bently Nevada Proximity Probe
330105-02-12-10-12-00
Bently Nevada Reverse Mount Probe
330104-13-20-10-02-00
Bently Nevada Standard Probe
3500/40-01-00
Bently Nevada Monitoring Module
Applications
• Used for axial displacement (thrust) monitoring in small to medium rotating machinery.
• Applied in compressors, pumps, motors, and fans for continuous thrust position supervision.
• Common in OEM machinery packages where a direct 4–20 mA thrust signal is required.
• Used in industrial automation systems for integrating thrust data into PLC or DCS control logic.
• Suitable for condition monitoring where space-saving and simplified wiring are required.
Key Advantages
• Converts proximity probe signals into a direct 4–20 mA thrust output.
• Integrated design reduces the need for separate monitoring modules.
• Stable performance in continuous industrial operation environments.
• Compatible with Bently Nevada 3300 NSv proximity probe systems.
• Compact construction supports easy installation in OEM machinery designs.
Technical FAQs
Q1: What is the main function of this sensor?
It measures axial shaft displacement and converts it into a 4–20 mA output signal.
Q2: What measurement principle does it use?
It uses eddy current proximity measurement technology combined with signal conditioning.
Q3: Is it a standalone probe?
No, it works with a proximity probe system and functions as a transmitter.
Q4: What output signal does it provide?
It provides a 4–20 mA analog signal proportional to thrust position.
Q5: What systems is it compatible with?
It is designed for use with Bently Nevada 3300 NSv probe systems.
Q6: Where is it typically installed?
It is installed in control panels or machinery electrical cabinets.
Q7: Does it require external signal processing?
No, signal conditioning is integrated into the unit.
Q8: Can it operate continuously?
Yes, it is designed for 24/7 industrial monitoring applications.
Q9: Is calibration required?
Yes, system calibration is required during setup.
Q10: Which industries use it?
Power generation, oil & gas, petrochemical, and OEM machinery manufacturing.
