Brand:Schneider PLC Item No.:Schneider ATS48C14Q Product Origin:France Product Dimensions:340 × 200 × 265 mm Product Weight:13.7 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Schneider ATS48C14Q Soft Starter Module belongs to the Altistart 48 series and is designed for the controlled starting and stopping of three-phase asynchronous motors. By regulating motor acceleration and deceleration, the unit helps limit starting current and reduce mechanical shock during operation.
Suitable for both standard-duty and heavy-duty applications, the ATS48C14Q can be installed in pumping systems, ventilation equipment, compressors, conveyors, and other industrial machinery. It also incorporates motor monitoring and protection functions, making it suitable for integration into industrial automation and motor control systems.
Product Specifications
Parameter
Specification
Brand
Schneider Electric
Model
ATS48C14Q
Product Type
Soft Starter Module
Product Series
Altistart 48
Rated Operational Current
131 A
Rated Supply Voltage
230–415 VAC, 3-Phase
Supply Frequency
50/60 Hz
Motor Power (Standard Application)
Up to 75 kW (Inline, 400 V)
Motor Power (Heavy-Duty Application)
Up to 55 kW (Inline, 400 V)
Motor Power (Inside Delta Connection)
Up to 110 kW (Standard), 90 kW (Heavy Duty)
Starting Method
Torque Control System (TCS)
Utilization Category
AC-53A
Protection Degree
IP00
Communication
Modbus (Standard), Optional Communication Modules
Mounting Method
Vertical Panel Mounting
Operating Temperature
-10°C to +40°C (without derating)
Dimensions & Weight
Item
Specification
Dimensions (H × W × D)
340 × 200 × 265 mm
Weight
Approx. 13.7 kg
Recommended Related Models
Schneider ATS48C11Q
Schneider ATS48C17Q
Schneider ATS48C21Q
Schneider ATS48D32Q
Schneider ATS48D47Q
Commonly Selected Schneider Electric Soft Starters
ATS22D32Q
ATS22D47Q
ATS48D17Q
ATS48D32Q
ATS48C14Q
ATS48C17Q
ATS48C21Q
ATS48C25Q
Typical Applications
The ATS48C14Q is suitable for a wide range of industrial motor control applications, including:
Water supply and wastewater treatment
Pumping stations
Ventilation and exhaust systems
Air compressors
Conveyor systems
Material handling equipment
Mining facilities
HVAC installations
Manufacturing production lines
Process industries
Product Features
Designed for controlled motor starting and stopping
Supports inline and inside-delta motor connections
Integrated motor thermal monitoring and protection
Torque-controlled acceleration for three-phase motors
Standard Modbus communication interface
Compatible with optional industrial communication modules
Suitable for both standard and heavy-duty operating conditions
Simple parameter configuration through the front interface
Intended for installation in industrial control cabinets
Compatible with Schneider Electric Altistart 48 accessories
Technical FAQs
1. What is the ATS48C14Q used for?
It is used to control the starting and stopping of three-phase asynchronous motors.
2. Which product family does this model belong to?
It is part of the Schneider Electric Altistart 48 series.
3. What is the rated operational current?
The rated operational current is 131 A.
4. What input voltage does it support?
The unit operates on 230–415 VAC, 50/60 Hz, three-phase power.
5. Does it support inside-delta installation?
Yes. The ATS48C14Q supports both inline and inside-delta motor connections.
6. Which communication protocol is available as standard?
The unit includes a Modbus communication interface as standard.
7. What types of motors can it control?
It is designed for three-phase squirrel-cage asynchronous motors.
8. Where is this soft starter commonly installed?
It is typically installed inside industrial electrical control panels for motor control applications.
9. What protection functions are included?
The unit provides motor thermal monitoring, phase supervision, overload protection, and operating diagnostics.
10. Which industries commonly use the ATS48C14Q?
It is commonly used in water treatment, manufacturing, mining, HVAC systems, material handling, and general industrial automation.
