Brand:Schneider PLC Item No.:ATS22D32S6U Product Origin:France Product Dimensions:265 x 130 x 169 mm Product Weight:7 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The ATS22D32S6U is a soft starter from the Schneider Electric Altistart 22 range. It is designed for controlled motor starting by gradually applying voltage to the motor terminals.
After the motor reaches nominal operating conditions, the internal bypass contactor connects to reduce power losses in the starter.
The device is intended for installation in electrical control panels for fixed-speed motor systems.
Technical Specifications
Parameter
Value
Manufacturer
Schneider Electric
Product Range
Altistart 22
Model
ATS22D32S6U
Device Type
Soft starter
Rated Operational Current
32 A
Supply Voltage
3-phase 208–600 VAC
Control Supply Voltage
110 VAC
Frequency
50/60 Hz
Starting Mode
Voltage ramp
Bypass
Integrated contactor
Communication
RS485 Modbus RTU
Mounting Type
Panel mounting
Installation Position
Vertical
Protection Degree
IP20
Dimensions (H × W × D)
265 × 130 × 169 mm
Weight
7 kg / 15.43 lb
Recommended Related Models
ATS22D17S6U
ATS22D47S6U
ATS22D62S6U
ATS48C11Q
ATS48C25Q
Popular Related Models
ATS22D32S6U
ATS22D17S6U
ATS22D47S6U
ATS22D62S6U
ATS48C17Q
Applications
Used for controlled starting and stopping of three-phase asynchronous motors in fixed-speed installations.
Applicable installation types:
Pump motor control systems
Fan motor control systems
Compressor motor control systems
Conveyor motor starting systems
General industrial motor starting circuits
Advantages
Voltage ramp motor starting method
Reduced starting current compared with direct-on-line starting
Internal bypass contactor included
Panel-mounted installation design
Designed for three-phase asynchronous motors
Suitable for fixed-speed motor operation
Technical FAQs (10 Questions)
Q1: Does this device provide motor speed control?
A1: No. It does not provide speed variation.
Q2: What type of starting method is used?
A2: Voltage ramp starting.
Q3: Is it designed for single-phase motors?
A3: No. It is designed for three-phase motors.
Q4: Does it require an external bypass contactor?
A4: No. It includes an internal bypass contactor.
Q5: Can it operate continuously as a drive?
A5: No. It is not a variable speed drive.
Q6: Is parameter setting required?
A6: Yes. Motor rated current setting is required.
Q7: Does it include motor protection functions?
A7: Yes. Motor protection functions are integrated.
Q8: Can it be used in pump systems?
A8: Yes. It is used in pump motor starting circuits.
Q9: Can it replace a VFD?
A9: No. It is not a VFD replacement device.
Q10: What happens after starting sequence?
A10: The bypass contactor is activated for running mode.
