Introduction The Schneider Altistart 22 ATS22D75Q is a motor starting module designed to support gradual acceleration of three-phase motors in industrial environments. It is positioned between traditional direct-on-line starters and variable speed drive solutions.
This model is widely used where stable equipment startup behavior and simplified operation are required.
Technical Specifications (Including Dimensions & Weight) Parameter Value Product Model ATS22D75Q Manufacturer Schneider Electric Series Altistart 22 Device Type Soft Starter Module Rated Current 75 A Supply Voltage 230–440 VAC Control Voltage 230 VAC Motor Power Range 18.5–37 kW Frequency 50/60 Hz Dimensions (H × W × D) 295 × 145 × 207 mm Weight 12.00 kg / 26.46 lb Protection Class IP20 Mounting Type Vertical panel mounting Cooling Method Air convection Communication Modbus RTU (RS485) Operating Temperature -10°C to +40°C Extended Operation Up to +60°C (derated use)
Recommended Related Models
ATS22D62S6 – Medium power industrial variant
ATS22D47S6 – Lower current soft starter model
ATS22D88Q – Higher capacity version for larger motors
ATS48 Series – Advanced soft starter platform
ATV320 Series – Variable speed drive alternative
Popular Related Models
ATS22D17S6
ATS22D32S6
ATS22D47S6
ATS22D62S6
ATS22D75Q
Applications The Schneider ATS22D75Q Soft Starter is used in industrial motor systems where controlled startup behavior is required for three-phase equipment.
Common application areas include:
Water treatment and pumping installations
HVAC ventilation and cooling systems
Conveyor and material transport lines
Industrial processing machinery
Mining and material handling equipment
Compressor and fan systems
General industrial automation equipment
It is typically used in systems where motors need a smooth transition from standstill to normal operation.
Advantages The ATS22D75Q provides stable and consistent motor starting behavior in industrial environments.
Supports gradual motor startup process
Helps reduce sudden electrical demand during startup phase
Integrated bypass function for normal running mode
Compact structure suitable for cabinet installation
Compatible with a wide range of industrial motor systems
Stable performance under varying load conditions
Simplified installation and configuration process
Suitable for continuous industrial operation
Technical FAQs (10 Questions) Q1: What type of motor is compatible with ATS22D75Q?
Q2: Does it include a bypass function?
Q3: Can it be used in pump systems?
Q4: What communication interface is supported?
Q5: Can it be integrated with PLC systems?
Q6: Is external motor protection required?
Q7: Can it handle repeated start cycles?
Q8: Does it support gradual startup behavior?
Q9: What installation position is required?
Q10: Is configuration required before operation?
