Bently Nevada 3500/25-02-03-RU Enhanced Bond Phase Module
Bently Nevada 3500/25-02-03-RU Enhanced Bond Phase Module
0.0
Points
Brand:Bently Nevada PLC Item No.:3500/25-02-03-RU Product Origin:USA Product Dimensions:119.9 x 24.4 x 256.5 mm Product Weight:0.34 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Bently Nevada 3500/25-02-03-RU Enhanced Bond Phase Module is a precision interface component designed to provide reliable phase reference processing within advanced machinery protection systems. It enables accurate rotational timing information, which is essential for analyzing shaft movement, vibration behavior, and equipment operating conditions.
As a component of the Bently Nevada 3500 platform, this module works alongside vibration monitoring, position monitoring, and protection modules to provide comprehensive machinery health information. Accurate phase reference signals are critical for applications such as vibration vector analysis, balancing, and fault diagnosis.
The 3500/25-02-03-RU combines reliable signal processing, compact design, and industrial compatibility to support long-term monitoring of critical rotating equipment.
Technical Specifications
Specification
Details
Product Brand
Bently Nevada
Model Number
3500/25-02-03-RU
Product Series
3500 Machinery Protection System
Module Type
Enhanced Bond Phase Module
Function
Phase Reference and Keyphasor® Signal Processing
Application
Rotating Machinery Monitoring and Diagnostics
Signal Type
Rotational Phase Reference Input
System Compatibility
Bently Nevada 3500 Monitoring Platform
Installation Type
Rack Mount Module
Dimensions
119.9 × 24.4 × 256.5 mm
Weight
0.34 kg (0.75 lb)
Recommended Related Models
Model
Description
Bently Nevada 3500/25-02-01-00
Enhanced Bond Phase Module for phase reference applications
Bently Nevada 3500/25-02-01-02
Enhanced Bond Phase Module variant
Bently Nevada 3500/25-01-01-00
Enhanced Bond Phase Module with alternate configuration
Bently Nevada 3500/05
3500 System Rack for module installation
Popular Related Models
Model
Description
Bently Nevada 3500/22
Transient Data Interface Module for machinery event recording
Bently Nevada 3500/32
4-Channel Relay Module for alarm and protection control
Bently Nevada 3500/40M
Four-Channel Proximity Monitor Module
Bently Nevada 3500/42M
Proximity Monitor Module for vibration and position monitoring
Applications in Machinery Phase Reference and Rotating Equipment Diagnostics
The Bently Nevada 3500/25-02-03-RU Enhanced Bond Phase Module is designed to provide accurate phase reference signal processing and Keyphasor® signal management within the Bently Nevada 3500 Machinery Protection System. This module supplies essential rotational timing information used for vibration analysis, shaft position monitoring, balancing operations, and advanced machinery diagnostics.
Designed for demanding industrial applications, the 3500/25-02-03-RU is suitable for monitoring critical rotating equipment including turbines, compressors, generators, pumps, and other large machinery systems. Reliable phase reference information enables engineers to better evaluate machine behavior, analyze vibration characteristics, and identify developing mechanical issues.
With compact rack integration and dependable signal processing capability, this Enhanced Bond Phase Module supports effective machinery protection strategies and helps improve predictive maintenance performance in industrial environments.
Technical Features and Benefits
Feature
Description
Enhanced Phase Processing
Provides accurate rotational phase reference signal handling
Keyphasor® Signal Interface
Supports shaft speed, timing, and phase measurement functions
3500 System Integration
Designed for Bently Nevada 3500 machinery monitoring racks
Reliable Signal Processing
Improves vibration analysis and machine diagnostics
Industrial-Grade Construction
Suitable for continuous monitoring applications
Rack-Mounted Design
Enables efficient installation in protection systems
Technical FAQs
1. What is the main purpose of the Bently Nevada 3500/25-02-03-RU?
It processes phase reference signals and provides Keyphasor® functionality for the 3500 Machinery Protection System.
2. What role does a phase reference signal play in machinery monitoring?
It provides rotational timing information needed for accurate vibration analysis and shaft position evaluation.
3. What is Keyphasor® used for?
Keyphasor® provides a once-per-revolution reference point for measuring shaft speed, phase angle, and vibration characteristics.
4. Which types of machinery use this module?
It is commonly used with turbines, compressors, generators, pumps, and other rotating industrial equipment.
5. Does this module directly measure vibration?
No. It provides phase reference data that enhances the analysis of vibration monitoring signals.
6. Is this module compatible with the Bently Nevada 3500 rack system?
Yes. It is designed specifically for integration into the 3500 Machinery Protection System.
7. How does this module support predictive maintenance?
It provides accurate rotational reference data that helps detect abnormal machine conditions and analyze faults.
8. What factors affect phase measurement accuracy?
Sensor installation, signal quality, shaft reference alignment, and system configuration influence accuracy.
9. Can this module operate continuously in industrial environments?
Yes. It is designed for permanent installation in machinery protection and monitoring systems.
10. What are the benefits of using an Enhanced Bond Phase Module?
It improves diagnostic capability by providing precise rotational reference information for machinery analysis.
