Bently Nevada 3500/25-03-01-01 Enhanced Bond Phase Module
Bently Nevada 3500/25-03-01-01 Enhanced Bond Phase Module
0.0
Points
Brand:Bently Nevada PLC Item No.:3500/25-03-01-01 Product Origin:USA Product Dimensions:119.9 x 24.4 x 256.5 mm Product Weight:0.34 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Bently Nevada 3500/25-03-01-01 Enhanced Bond Phase Module is a precision interface module designed to provide accurate phase reference processing for industrial machinery protection applications. It supplies essential rotational timing information required for detailed analysis of rotating equipment performance.
As part of the Bently Nevada 3500 Machinery Protection System, this module integrates with other monitoring components to create a complete machinery health monitoring solution. Reliable phase reference information is essential for vibration vector analysis, balancing procedures, and identification of mechanical problems.
The 3500/25-03-01-01 combines dependable signal processing, compact rack installation, and industrial reliability to support continuous monitoring of critical rotating assets.
Technical Specifications
Specification
Details
Product Brand
Bently Nevada
Model Number
3500/25-03-01-01
Product Series
3500 Machinery Protection System
Module Type
Enhanced Bond Phase Module
Function
Phase Reference and Keyphasor® Signal Processing
Application
Rotating Machinery Monitoring and Diagnostics
Signal Type
Rotational Phase Reference Input
System Compatibility
Bently Nevada 3500 Monitoring Platform
Installation Type
Rack Mount Module
Dimensions
119.9 × 24.4 × 256.5 mm
Weight
0.34 kg (0.75 lb)
Recommended Related Models
Model
Description
Bently Nevada 3500/25-02-01-00
Enhanced Bond Phase Module for phase reference applications
Bently Nevada 3500/25-02-01-02
Enhanced Bond Phase Module variant
Bently Nevada 3500/25-02-03-RU
Enhanced Bond Phase Module with RU configuration
Bently Nevada 3500/05
3500 System Rack for module installation
Popular Related Models
Model
Description
Bently Nevada 3500/22
Transient Data Interface Module for machinery event recording
Bently Nevada 3500/32
4-Channel Relay Module for alarm and protection control
Bently Nevada 3500/40M
Four-Channel Proximity Monitor Module
Bently Nevada 3500/42M
Proximity Monitor Module for vibration and position monitoring
Applications in Rotating Machinery Phase Monitoring and Diagnostic Systems
The Bently Nevada 3500/25-03-01-01 Enhanced Bond Phase Module is designed to provide reliable phase reference signal processing and Keyphasor® signal management within the Bently Nevada 3500 Machinery Protection System. It delivers accurate rotational timing information required for advanced vibration analysis, shaft position monitoring, balancing operations, and machinery condition diagnostics.
This module is designed for use with critical rotating equipment including steam turbines, gas turbines, compressors, generators, pumps, and other industrial machinery requiring precise shaft reference data. By providing accurate phase information, the 3500/25-03-01-01 helps engineers analyze machine behavior, improve fault detection, and optimize maintenance strategies.
Integrated into the Bently Nevada 3500 platform, this Enhanced Bond Phase Module supports reliable machinery protection and condition monitoring by improving diagnostic accuracy and providing essential rotational reference information.
Technical Features and Benefits
Feature
Description
Enhanced Phase Signal Processing
Provides accurate rotational phase reference measurement
Keyphasor® Signal Support
Enables shaft timing and phase analysis functions
3500 Machinery Protection Compatibility
Designed for installation in Bently Nevada 3500 racks
Precision Timing Reference
Supports vibration analysis and balancing applications
Continuous Monitoring Capability
Suitable for permanent industrial installations
Compact Rack Design
Allows efficient integration into protection systems
Technical FAQs
1. What is the main function of the Bently Nevada 3500/25-03-01-01?
It processes phase reference signals and provides Keyphasor® functionality for the Bently Nevada 3500 Machinery Protection System.
2. Why is phase reference data important in rotating machinery monitoring?
Phase reference information helps identify shaft position, vibration phase relationships, and machine operating conditions.
3. What is the purpose of the Keyphasor® signal?
The Keyphasor® signal provides a rotational reference point used for speed, phase, and vibration analysis.
4. What equipment can use this module?
It is commonly used with turbines, compressors, generators, pumps, and other critical rotating equipment.
5. Does this module perform vibration measurement itself?
No. It provides phase reference signals that support vibration monitoring and diagnostic analysis.
6. Can the module be installed in an existing 3500 system?
Yes. It is designed for use with Bently Nevada 3500 monitoring racks.
7. How does it support predictive maintenance?
It improves diagnostic accuracy by providing precise rotational reference information for machine condition analysis.
8. What factors affect phase signal quality?
Sensor installation, signal stability, shaft reference setup, and monitoring system configuration affect performance.
9. Is this module suitable for continuous industrial operation?
Yes. It is designed for long-term use in machinery protection and monitoring systems.
10. What advantages does enhanced phase processing provide?
It enables more accurate vibration analysis, fault identification, and rotating equipment evaluation.
