ABB 086318-002 Power Supply Module

Introduction

The ABB 086318-002 is a reliable and efficient power supply module designed to provide continuous, stable 24 VDC output to industrial automation and control systems. With its high efficiency, advanced protection features, and compact design, this module is ideal for a wide range of applications, including process control, energy management, and telecommunication systems. The 086318-002 is engineered to ensure safe, reliable, and uninterrupted power to critical equipment in harsh industrial environments. Its compliance with global standards ensures it meets the highest safety and quality requirements.

Technical Specifications

Specification	Details
Model	086318-002
Module Type	Power Supply Module
Input Voltage	380-480 VAC
Output Voltage	24 VDC
Output Current	25 A
Size (W x H x D)	150 x 90 x 60 mm
Weight	1.7 kg
Mounting Type	DIN Rail
Efficiency	> 85%
Operating Temperature	-20°C to +60°C
Certifications	CE, UL, RoHS

Recommended Related Models

Model	Module Type	Input Voltage	Output Voltage	Output Current
ABB 086318-001	Power Supply Module	380-480 VAC	24 VDC	20 A
ABB 086318-003	Power Supply Module	380-480 VAC	24 VDC	30 A
ABB 086318-004	Power Supply Module	380-480 VAC	24 VDC	35 A

Popular ABB Models

Model	Module Type	Input Voltage	Output Voltage	Output Current
ABB 086318-001	Power Supply Module	380-480 VAC	24 VDC	20 A
ABB 086318-002	Power Supply Module	380-480 VAC	24 VDC	25 A
ABB 086318-005	Power Supply Module	380-480 VAC	24 VDC	40 A

Applications

Industrial Automation: The ABB 086318-002 is designed to supply power to industrial automation systems, providing stable 24 VDC output for driving controllers, sensors, and actuators in manufacturing environments.
Process Control: It is widely used in process control systems, ensuring continuous power to process management devices in industries such as chemicals, pharmaceuticals, and food production.
Energy Management: This module powers energy monitoring and optimization systems, ensuring the stable operation of controllers, meters, and communication devices in energy management applications.
Telecommunications: The 086318-002 is used in telecommunication systems, ensuring reliable power to communication equipment and ensuring minimal downtime.
Building Automation: It powers various components in building automation systems, such as HVAC systems, lighting, and security controls, contributing to the efficient operation of modern buildings.

Advantages

High Efficiency: With an efficiency rating of > 85%, the ABB 086318-002 minimizes energy loss and reduces operational costs, contributing to long-term sustainability.
Compact and Space-Saving: The DIN rail mounting design makes the module easy to install in confined spaces, saving valuable room in control panels.
Wide Input Voltage Range: The 086318-002 can operate with an input voltage range of 380-480 VAC, allowing for use in various global power systems.
Reliable Protection: Built-in protection features, such as overload, short-circuit, and thermal protection, ensure safe operation and protect both the module and connected equipment.
Global Standards Compliance: The module is CE, UL, and RoHS certified, meeting global safety, quality, and environmental standards.
