Introduction

The ABB ACS580-01-05A6-4 Frequency Converter is a general-purpose AC drive developed to provide efficient and reliable motor control for modern industrial applications. As part of the ACS580 family, it offers a balanced combination of performance, flexibility, and ease of use.

Designed for wall-mounted installation, this frequency converter provides an effective solution for controlling small and medium motor systems while maintaining excellent operational stability. Its integrated functions simplify system configuration and help users improve productivity, reduce energy consumption, and enhance equipment reliability.

With its compact structure, dependable control performance, and versatile application capability, the ACS580-01-05A6-4 is an excellent drive solution for industries seeking efficient motor management and long-term operational value.

Technical Specifications

Specification	Details
Product Type	Frequency Converter
Manufacturer	ABB
Model Number	ACS580-01-05A6-4
Product ID	3AUA0000080489
Drive Series	ACS580
Module Type	Frequency Converter Module
Rated Output Current	5.6A
Rated Power	2.2 kW
Input Voltage	380–480V AC
Input Phase	Three-phase
Frequency Range	47.5–63 Hz
Control Method	Scalar Control, Vector Control
Communication Interface	Industrial Communication Options
Safety Function	Safe Torque Off (STO)
Mounting Type	Wall-mounted
Protection Class	IP21
Frame Size	R0
Operating Temperature	-15°C to +50°C
Dimensions (H × W × D)	468 × 228 × 345 mm
Weight	4.8 kg (10.58 lb)

Recommended Related Models

Model	Description
ABB ACS580-01-04A1-4	Compact frequency converter for low-power motor applications
ABB ACS580-01-07A2-4	Higher-capacity drive for increased motor requirements
ABB ACS580-01-09A4-4	Flexible frequency converter for wider industrial applications
ABB ACS580-01-12A6-4	General-purpose drive for larger low-power systems

Popular Related Models

Model	Description
ABB ACS580-01-018A-4	Reliable frequency converter for industrial automation
ABB ACS580-01-026A-4	General-purpose AC drive for machinery applications
ABB ACS580-01-033A-4	Medium-power motor control solution for industry
ABB ACS880-01-045A-3	Advanced industrial drive for demanding applications
ABB ACS580-04-050A-4	Modular frequency converter for industrial systems

Applications

The ABB ACS580-01-05A6-4 Frequency Converter is a compact and reliable industrial drive designed to provide efficient motor control, smooth operation, and flexible automation performance for low-power applications. With its practical design and dependable control capability, this frequency converter delivers stable performance for systems requiring accurate speed regulation and improved energy efficiency.

This model is widely used in pumps, fans, conveyors, compressors, mixers, HVAC equipment, and general industrial machinery. It helps optimize motor operation by adjusting speed according to actual process requirements, reducing unnecessary energy consumption while maintaining consistent equipment performance.

The ACS580-01-05A6-4 is a suitable choice for OEM manufacturers, machine builders, and industrial operators who require a reliable frequency converter with simple commissioning, flexible integration, and long service life.

Advantages

The ABB ACS580-01-05A6-4 combines advanced drive technology with a compact structure to deliver dependable motor management for various industrial applications.

Efficient Motor Control: Provides accurate speed adjustment and stable torque performance for smooth operation.
Compact Industrial Design: Allows flexible installation in automation cabinets and machinery systems.
Energy Optimization: Helps reduce operating costs by matching motor speed with actual process demand.
Simplified Setup: User-friendly configuration reduces installation time and improves operational convenience.
Wide Application Flexibility: Suitable for different variable-speed industrial equipment.
Reliable Protection Functions: Supports stable operation through integrated monitoring and control features.
Long-Term Performance: Designed for continuous industrial environments requiring dependable drive operation.

Technical FAQs

1. What is the ABB ACS580-01-05A6-4 Frequency Converter used for?
It is used to control the speed, torque, and operation of three-phase AC motors in industrial systems.

2. What type of motors are compatible with this frequency converter?
It is designed for three-phase AC induction motors commonly used in industrial machinery.

3. Does the ACS580-01-05A6-4 support advanced motor control functions?
Yes. It provides reliable motor control functions for accurate speed regulation and stable operation.

4. Can this frequency converter be integrated with automation systems?
Yes. It can be connected with industrial control systems through compatible communication solutions.

5. What applications are commonly used with this model?
Typical applications include pumps, fans, conveyors, compressors, mixers, and HVAC equipment.

6. Does this drive include motor protection features?
Yes. It provides monitoring and protection functions to improve system reliability.

7. How are parameters configured on the ACS580-01-05A6-4?
Parameters can be adjusted through the drive interface and supported configuration tools.

8. Can this frequency converter improve energy efficiency?
Yes. It helps optimize motor performance by adjusting speed based on actual load conditions.

9. Is this model suitable for continuous industrial operation?
Yes. It is designed for stable and reliable operation in industrial environments.

10. Can the ACS580-01-05A6-4 be used for upgrading existing equipment?
Yes. It can be applied in suitable modernization projects where electrical requirements match.
