Brand:GE Fanuc PLC Item No.:IC693MDL760B Product Origin:USA Product Dimensions:108 × 7.2 × 7.2 mm Product Weight:0.36 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The GE IC693MDL760B Solenoid Output Module is a specialized automation module designed for GE Fanuc Series 90-30 PLC systems. It combines pneumatic control capability with traditional DC outputs, providing a flexible solution for industrial machines that rely on compressed-air actuators and solenoid-driven devices.
By integrating multiple pneumatic outputs into a compact PLC module, the IC693MDL760B helps reduce cabinet wiring requirements while improving system reliability and maintenance efficiency. Its practical design makes it especially valuable for manufacturing equipment, automated production lines, and legacy PLC applications requiring dependable pneumatic control.
Technical Specifications
Specification
Description
Manufacturer
GE Fanuc / Emerson
Model
IC693MDL760B
Product Type
Solenoid Output Module
PLC Platform
Series 90-30
Output Type
Pneumatic Solenoid + 24 VDC Sourcing Output
Pneumatic Outputs
11 Points
DC Outputs
5 Points
Output Logic
Positive Logic
Pneumatic Supply Pressure
Maximum 100 PSI
External Solenoid Power
21.6–26.4 VDC
Solenoid Inrush Current
33 mA per Valve
Solenoid Holding Current
13 mA per Valve
DC Output Load Current
0.5 A per Point
Total DC Output Current
2.0 A Maximum
Response Time
Approx. 12 ms ON/OFF
Indicators
Output Status LEDs
Mounting Type
Single PLC I/O Slot
Dimensions
Approx. 85 × 120 × 140 mm
Weight
Approx. 0.17 kg
Recommended Companion Models
Model
Product Name
IC693CPU350
Series 90-30 CPU Module
IC693PWR321
Series 90-30 Power Supply Module
IC693MDL753
32-Point 12/24 VDC Discrete Output Module
IC693MDL645
16-Point 24 VDC Discrete Input Module
Frequently Selected Alternatives
Model
Product Name
IC693MDL760A
Series 90-30 Solenoid Output Module
IC693MDL750
12/24 VDC Positive Logic Output Module
IC693MDL752
32-Point 5/24 VDC Output Module
IC693MDL754
32-Point Relay Output Module
Where It Excels in Industrial Use
Pneumatic actuator control in GE Fanuc Series 90-30 PLC systems
Automated machine tooling and assembly equipment
Solenoid valve control applications
Packaging and material handling systems
Factory automation with pneumatic devices
Process equipment requiring compact valve control
Industrial motion and actuator management
Manufacturing lines using compressed air systems
Retrofit projects for existing Series 90-30 PLC installations
Equipment requiring integrated pneumatic and DC output control
Key Strengths at a Glance
Integrated solenoid output module for Series 90-30 PLC platforms
Built-in three-way solenoid valves simplify pneumatic control
Supports external 24 VDC solenoid power supply
Handles pneumatic supply pressure up to 100 PSI
Individual output status indicators improve troubleshooting efficiency
Compact single-slot PLC installation design
Reduces external valve wiring complexity
Designed for reliable industrial automation applications
Ideal for upgrading and maintaining legacy GE PLC systems
Technical FAQs
1. What is the primary function of the GE IC693MDL760B?
The IC693MDL760B is a Series 90-30 PLC solenoid output module designed to control pneumatic outputs and 24 VDC field devices.
2. How many outputs does the IC693MDL760B provide?
The module provides 11 pneumatic outputs and 5 additional 24 VDC sourcing outputs for industrial control applications.
3. How do the pneumatic outputs operate?
Each pneumatic output contains an internal three-way solenoid-operated valve. When activated, the valve connects the supplied air pressure to the output port; when deactivated, the output is vented.
4. What type of PLC system is compatible with this module?
The IC693MDL760B is designed for GE Fanuc Series 90-30 PLC systems.
5. What is the maximum pneumatic supply pressure?
The module supports a maximum pneumatic supply pressure of approximately 100 PSI.
6. Does the module require an external power supply?
Yes. The solenoid outputs require an external 24 VDC power source connected through the front-panel DC output connector.
7. What type of output logic does the IC693MDL760B use?
The module uses positive logic output operation for its DC output channels.
8. Are LED indicators available for output monitoring?
Yes. The module includes LED indicators to provide visual confirmation of output operation and simplify maintenance troubleshooting.
9. Can the module directly control pneumatic valves?
Yes. The integrated pneumatic solenoid valves allow direct control of pneumatic devices without requiring separate external valve assemblies.
10. What applications commonly use this module?
Typical applications include automated machinery, pneumatic actuators, assembly equipment, and manufacturing systems requiring PLC-controlled air valves.
