Brand:GE Fanuc PLC Item No.:IC693MDL930H Product Origin:USA Product Dimensions:202 × 21 × 261 mm Product Weight:0.3 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The GE IC693MDL930H Relay Output Module is a high-performance discrete output solution designed for GE Fanuc Series 90-30 PLC automation systems. Featuring eight individually isolated normally open relay channels, it provides a flexible interface between PLC control logic and industrial field equipment.
Designed for applications where electrical separation and load flexibility are essential, the IC693MDL930H allows engineers to control AC and DC devices such as motors, solenoids, and industrial indicators within a single compact PLC module. Its isolated relay architecture helps improve system reliability in environments where different voltage levels and field conditions exist.
With proven Series 90-30 compatibility, strong switching capability, and straightforward diagnostics, this module remains a practical choice for automation maintenance, retrofit projects, and industrial control upgrades.
Technical Specifications
Specification
Description
Manufacturer
GE Fanuc / Emerson
Model
IC693MDL930H
Product Type
Relay Output Module
PLC Platform
Series 90-30
Output Type
Isolated Relay Output
Contact Type
Normally Open (Form A)
Number of Outputs
8 Points
Output Isolation
Individual Channel Isolation
Rated Voltage
24 VDC / 120 VAC / 240 VAC
Operating Voltage Range
5–30 VDC / 5–250 VAC
Output Current Rating
4 A per Point
Pilot Duty Rating
2 A per Point
Isolation Voltage
1500 VAC Field Side to Logic Side
Group Isolation
500 VAC Between Groups
Response Time
15 ms Maximum ON/OFF
Minimum Load Current
10 mA
Maximum Inrush Current
5 A
Indicators
8 Output Status LEDs
Power Consumption
6 mA from 5 VDC Bus; 70 mA from Relay 24 V Bus
Connection Type
20-Pin Screw Terminal Block
Mounting Type
Single Series 90-30 I/O Slot
Dimensions
Approx. 130 × 125 × 40 mm
Weight
Approx. 0.45 kg
Recommended Companion Models
Model
Product Name
IC693CPU374
Series 90-30 Ethernet CPU Module
IC693PWR321
Series 90-30 Power Supply Module
IC693MDL645F
Series 90-30 24 VDC 16-Point Input Module
IC693MDL753F
Series 90-30 32-Point 12/24 VDC Output Module
Frequently Selected Alternatives
Model
Product Name
IC693MDL931
Series 90-30 8-Point 8 Amp Relay Output Module
IC693MDL940
Series 90-30 16-Point Relay Output Module
IC693MDL754
Series 90-30 32-Point Relay Output Module
IC200MDL740G
VersaMax 16-Point 12/24 VDC Output Module
Where It Excels in Industrial Use
GE Fanuc Series 90-30 PLC control systems
Industrial motor starter and contactor switching
Solenoid valve and actuator control applications
Machine automation and production equipment
Packaging and material handling systems
Industrial lighting and indicator control
Process automation requiring AC/DC load switching
Legacy Series 90-30 PLC maintenance and upgrade projects
Control panels requiring isolated relay outputs
Applications with mixed voltage field devices
Key Strengths at a Glance
8-point individually isolated relay output design
Supports both AC and DC load switching
4 A output switching capability per relay channel
Normally open Form A relay contacts
Separate common terminal for each output point
High electrical isolation between field side and PLC logic
Compatible with GE Fanuc Series 90-30 PLC platforms
Individual LED indicators for output status monitoring
Flexible control of motors, solenoids, and indicators
Reliable relay-based switching for demanding industrial environments
Technical FAQs
1. What is the primary function of the GE IC693MDL930H?
The IC693MDL930H is an isolated relay output module designed for GE Fanuc Series 90-30 PLC systems. It provides eight normally open relay outputs for controlling external field loads.
2. How many output channels does the IC693MDL930H provide?
The module provides eight individually isolated relay output channels. Each channel operates independently with its own relay contact and common connection.
3. What type of loads can this module control?
The IC693MDL930H can control various AC and DC loads, including motor starters, solenoid valves, contactors, and industrial indicator devices.
4. What is the maximum current rating per output?
Each relay output supports up to 4 A switching capacity for resistive loads. Pilot-duty applications are typically limited to lower current levels depending on operating conditions.
5. What voltage ranges are supported?
The module supports 5–30 VDC and 5–250 VAC operating voltage ranges, including common industrial 24 VDC and 120/240 VAC applications.
6. Are the relay outputs electrically isolated?
Yes. Each output point is individually isolated, with isolation between field circuits and PLC logic to improve system protection and reliability.
7. Does the module require an external field power supply?
Yes. The user must provide AC or DC power for the connected field devices because the relay contacts only perform switching functions.
8. How are output states monitored?
Each relay channel includes an LED indicator that displays the ON/OFF status of the corresponding output point, helping simplify troubleshooting and maintenance.
9. Which PLC systems are compatible with the IC693MDL930H?
The module is designed for GE Fanuc Series 90-30 PLC systems and can be installed in available I/O slots on compatible baseplates.
10. Why choose a relay output module instead of a transistor output module?
Relay outputs provide greater flexibility because they can switch both AC and DC loads and support a wider variety of industrial devices without requiring dedicated output electronics.
