Brand:GE Fanuc PLC Item No.:IC200UEX636-C Product Origin:USA Product Dimensions:202 × 21 × 261 mm Product Weight:0.30 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The GE IC200UEX636-C Analog Expansion Unit extends the analog processing capabilities of VersaMax Micro PLC systems by providing four high-performance analog inputs and two precision analog outputs. Designed for applications requiring accurate monitoring and control of continuous process variables, it offers flexible support for both voltage and current signal standards.
Its integrated AC power supply, built-in sensor power output, and compact modular construction simplify system design while minimizing additional hardware requirements. The removable terminal blocks and diagnostic indicators further enhance installation efficiency and maintenance convenience.
Engineered for dependable industrial performance, the IC200UEX636-C delivers the accuracy, reliability, and scalability required for process automation, machine control, and distributed analog measurement applications.
Technical Specifications
Parameter
Details
Model
IC200UEX636-C
Product Type
Analog Expansion Unit
Series
GE VersaMax Micro
Analog Inputs
4 Channels
Analog Outputs
2 Channels
Input Signal Types
0–10 VDC, ±10 VDC, 0–20 mA, 4–20 mA
Output Signal Types
0–10 VDC, 0–20 mA, 4–20 mA
A/D Resolution
12-bit
D/A Resolution
12-bit
Supply Voltage
120/240 VAC
Power Consumption
15 VA
Sensor Power Output
24 VDC, 200 mA
Expansion Interface
VersaMax Micro Expansion Connector
Terminal Type
Removable Terminal Blocks
Status Indicators
Power and Module Status LEDs
Mounting Method
DIN Rail Mounted
Operating Temperature
0°C to 55°C
Dimensions
Approx. 95 × 90 × 76 mm
Weight
Approx. 0.90 kg
Recommended Companion Models
Model
Product Name
IC200CBL501
VersaMax Micro Expansion Cable
IC200UDR064
VersaMax Micro PLC CPU Module
IC200PWR002G
VersaMax Power Supply Module
IC200MDL640J
VersaMax 16-Point Discrete Input Module
Frequently Selected Alternatives
Model
Product Name
IC200UEX624
VersaMax Micro Analog Input Expansion Unit
IC200UEX626
VersaMax Micro Analog I/O Expansion Unit
IC200UEX736
VersaMax Micro Analog I/O Expansion Unit (±10 V Version)
IC200UEX826
VersaMax Micro Universal Analog Expansion Unit
Where It Excels in Industrial Use
• Designed for GE VersaMax Micro PLC systems, the IC200UEX636-C Analog Expansion Unit expands analog processing capability by adding multiple high-precision input and output channels for demanding industrial control applications.
• Ideal for machine automation, water treatment, HVAC systems, packaging equipment, and process control applications requiring accurate acquisition and transmission of analog signals.
• Supports connection to transmitters, pressure sensors, flow meters, temperature controllers, variable frequency drives, and other analog field instruments using voltage or current signals.
• Well suited for VersaMax Micro installations where flexible analog expansion, reliable measurement accuracy, and simplified system integration are essential for continuous industrial operation.
Key Strengths at a Glance
• Provides 4 analog input channels and 2 analog output channels within a single expansion unit, reducing hardware requirements while increasing system flexibility.
• Supports multiple industry-standard signal ranges including 0–10 VDC, ±10 VDC, 0–20 mA, and 4–20 mA with 12-bit resolution for precise signal processing.
• Operates from a 120/240 VAC power supply while delivering 24 VDC sensor power up to 200 mA, simplifying field device connections.
• Features removable terminal strips, integrated expansion connectors, and front-panel status LEDs for convenient installation, maintenance, and system diagnostics.
Technical FAQs
1. What type of module is the GE IC200UEX636-C?
The IC200UEX636-C is an analog expansion unit designed for GE VersaMax Micro PLC systems.
2. How many analog channels are available?
The unit provides four analog input channels and two analog output channels.
3. Which analog input signal types are supported?
The inputs support 0–10 VDC, ±10 VDC, 0–20 mA, and 4–20 mA signal ranges.
4. Which analog output signal types are available?
The outputs support 0–10 VDC, 0–20 mA, and 4–20 mA analog signals.
5. What resolution does the analog conversion provide?
Both the analog inputs and outputs utilize 12-bit resolution for accurate signal processing.
6. What power supply is required for the IC200UEX636-C?
The module operates from a 120/240 VAC power source.
7. Does the module provide sensor power?
Yes. It supplies 24 VDC auxiliary power with a maximum output of 200 mA for compatible field sensors.
8. Which devices can be connected to the analog channels?
Typical devices include pressure transmitters, flow sensors, level transmitters, variable frequency drives, control valves, and analog measuring instruments.
9. Is the IC200UEX636-C compatible with VersaMax Micro controllers?
Yes. It is specifically designed as an expansion unit for compatible GE VersaMax Micro PLC systems.
10. What should be verified before replacing the IC200UEX636-C?
Engineers should confirm controller compatibility, analog signal configuration, wiring integrity, field power availability, and expansion cable connections before installation.
