Brand:GE Fanuc PLC Item No.:IC200UEX011-B Product Origin:USA Product Dimensions:108 × 7.2 × 7.2 mm Product Weight:0.30 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The GE IC200UEX011-B Expansion Unit is a compact digital I/O expansion module developed for VersaMax Micro PLC systems. It increases controller capacity by adding eight 24 VDC discrete inputs and six relay outputs while incorporating its own universal AC power supply, making it an efficient solution for growing automation systems.
Designed for industrial applications requiring dependable digital control, the IC200UEX011-B combines flexible field connectivity with relay-based output switching capable of handling a wide variety of industrial loads. The integrated 24 VDC auxiliary supply further simplifies installation by powering compatible sensors directly from the module.
Offering compact dimensions, reliable performance, and seamless compatibility with VersaMax Micro PLC platforms, the IC200UEX011-B is an excellent choice for machine expansion, system upgrades, and long-term industrial automation projects.
Technical Specifications
Parameter
Details
Model
IC200UEX011-B
Product Type
Expansion Unit
Series
GE VersaMax Micro
Total I/O Points
14
Digital Inputs
8 Points
Input Type
24 VDC Positive/Negative Logic
Digital Outputs
6 Points
Output Type
Form A Relay (SPST Normally Open)
Relay Load Rating
2 A Resistive @ 24 VDC / 250 VAC
Input Supply Voltage
100–240 VAC Nominal
Input Frequency
50/60 Hz
Input Power Rating
13 VA
Auxiliary Sensor Supply
Isolated 24 VDC, 200 mA Maximum
Maximum Expansion Units
Up to 4 per VersaMax Micro PLC
Terminal Type
Removable Screw Terminal Blocks
Mounting Method
DIN Rail Mounted
Operating Temperature
0°C to 55°C
Protection
Hinged Terminal Covers
Dimensions
95 × 90 × 76 mm
Weight
Approx. 0.37 kg
Recommended Companion Models
Model
Product Name
IC200UDR064
VersaMax Micro PLC CPU Module
IC200CBL501
VersaMax Micro Expansion Cable
IC200UEX012
VersaMax Micro 14-Point Expansion Unit (24 VDC Powered)
IC200UEX636-C
VersaMax Micro Analog Expansion Unit
Frequently Selected Alternatives
Model
Product Name
IC200UEX012
VersaMax Micro 14-Point Expansion Unit (24 VDC Powered)
IC200UEX013
VersaMax Micro 14-Point Expansion Unit (12 VDC Powered)
IC200UEX014
VersaMax Micro 14-Point Digital Expansion Unit
IC200UEX122
VersaMax Micro 14-Point ESCP Digital Expansion Unit
Where It Excels in Industrial Use
• Designed for GE VersaMax Micro PLC systems, the IC200UEX011-B expands digital I/O capacity by providing additional 24 VDC inputs and relay outputs, making it ideal for compact industrial control systems requiring flexible field connectivity.
• Well suited for packaging machinery, conveyor automation, material handling equipment, HVAC systems, water treatment facilities, and OEM machine control applications where additional discrete I/O is required without replacing the primary controller.
• Ideal for interfacing with pushbuttons, proximity sensors, limit switches, solenoid valves, motor starters, relays, and indicator lamps in industrial automation environments.
• Supports modular VersaMax Micro installations where compact cabinet design, simplified wiring, and scalable I/O expansion are essential for long-term system reliability.
Key Strengths at a Glance
• Provides 14 additional I/O points consisting of 8 discrete 24 VDC inputs and 6 Form A relay outputs within a single compact expansion unit.
• Accepts universal 100–240 VAC input power while supplying an isolated 24 VDC auxiliary output (200 mA) for field sensors and input circuits.
• Relay outputs support resistive loads up to 2 A at both 24 VDC and 250 VAC, providing excellent flexibility for switching industrial devices.
• Features removable terminal blocks, integrated expansion connectivity, and front-panel status indicators for fast installation, maintenance, and troubleshooting.
Technical FAQs
1. What type of module is the GE IC200UEX011-B?
The IC200UEX011-B is a VersaMax Micro 14-point digital expansion unit with integrated AC power supply.
2. How many I/O points are available on the IC200UEX011-B?
The module provides 8 discrete 24 VDC input points and 6 relay output points.
3. What input voltage powers the expansion unit?
The module operates from a nominal 100 to 240 VAC power supply.
4. What input devices are compatible with the IC200UEX011-B?
It supports 24 VDC field devices such as pushbuttons, limit switches, proximity sensors, and photoelectric sensors.
5. What type of outputs does the module provide?
The output section consists of six normally open Form A (SPST) relay outputs.
6. What is the maximum relay load rating?
Each relay output supports resistive loads up to 2 A at 24 VDC or 250 VAC.
7. Does the IC200UEX011-B provide auxiliary sensor power?
Yes. The module provides an isolated 24 VDC auxiliary output with a maximum capacity of 200 mA.
8. How many expansion units can be connected to a VersaMax Micro PLC?
A compatible VersaMax Micro controller can support up to four expansion units connected in sequence.
9. Is the IC200UEX011-B compatible with all VersaMax Micro controllers?
It is designed for compatible VersaMax Micro PLC models that support discrete expansion modules.
10. What should be checked before replacing an IC200UEX011-B?
Verify controller compatibility, expansion cable connections, AC input voltage, field wiring, relay load ratings, and PLC hardware configuration before installation.
