Brand:GE Fanuc PLC Item No.: HE693RTD600M Product Origin:USA Product Dimensions:202 × 21 × 261 mm Product Weight:0.30 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The GE HE693RTD600M RTD Input Module is a specialized temperature measurement solution developed for GE Series 90-30 PLC systems. It enables direct connection of RTD sensors and converts resistance-based temperature signals into digital values for PLC processing, providing a reliable interface between field instrumentation and automation control systems.
Designed for industrial temperature monitoring applications, the HE693RTD600M integrates signal conditioning and conversion functions inside the module, reducing installation complexity while improving measurement stability. With six RTD channels and support for multiple sensor technologies, it provides flexibility for applications requiring accurate thermal data acquisition.
Combining dependable operation, broad sensor compatibility, and proven Series 90-30 integration, the HE693RTD600M remains a practical choice for process automation, equipment upgrades, and industrial temperature control systems.
Technical Specifications
Parameter
Details
Model
HE693RTD600M
Product Type
RTD Input Module
Series
GE Series 90-30
Input Channels
6 Channels
Input Type
RTD Resistance Temperature Detector
Wiring Configuration
3-Wire RTD
Supported RTD Types
Pt100, Pt1000, Ni-120, Cu-10, Cu-50, Cu-53, Cu-100, TD5R, Linear Resistance
Temperature Range
Approx. -100°C to +850°C (Sensor Dependent)
Resolution
0.5°C / 0.5°F
Accuracy
±0.5°C Typical
A/D Conversion
16-bit Integrating
Update Rate
50 Channels/Second
Input Impedance
>1000 MΩ
RTD Excitation Current
Approx. 330 µA (Pt100)
Fault Protection
Zener Diode Clamp
Isolation
1500 VAC Channel-to-Bus
Power Consumption
Approx. 75 mA @ 5 VDC
Terminal Type
20-Screw Terminal Block
Mounting Type
Series 90-30 Rack Mounted
Operating Temperature
0°C to 60°C
Dimensions
Approx. 127 × 51 × 127 mm
Weight
Approx. 0.30 kg
Recommended Companion Models
Model
Product Name
IC693CPU374
Series 90-30 CPU Module
IC693PWR321S
Series 90-30 Power Supply Module
IC693CHS391M
Series 90-30 10-Slot Baseplate
HE693THM889B
Series 90-30 Thermocouple Input Module
Frequently Selected Alternatives
Model
Product Name
HE693RTD601
Series 90-30 High Resolution RTD Input Module
HE693RTD660
Series 90-30 Isolated RTD Input Module
IC693ALG600
Series 90-30 RTD Input Module
IC693ALG392B
Series 90-30 Analog Current Output Module
Where It Excels in Industrial Use
• Designed for GE Series 90-30 PLC systems, the HE693RTD600M provides accurate temperature acquisition through direct connection with RTD sensors, eliminating the need for external transmitters or signal conditioning devices.
• Ideal for process industries including chemical processing, food and beverage production, HVAC systems, furnace monitoring, and industrial heating applications where precise temperature feedback is essential.
• Supports multiple RTD sensor types including Pt100, Pt1000, Ni-120, Cu-10, Cu-50, and other resistance-based temperature sensors, allowing flexible integration into various measurement environments.
• Suitable for automation upgrades, OEM equipment, and legacy Series 90-30 installations requiring dependable temperature monitoring and stable analog data acquisition.
Key Strengths at a Glance
• Provides six RTD input channels for simultaneous multi-point temperature monitoring within a compact PLC module.
• Performs analog signal processing, digital conversion, and temperature calculation directly inside the module, simplifying system design and improving measurement consistency.
• Supports 3-wire RTD configurations with compatibility for common industrial temperature sensors, including platinum, nickel, and copper resistance devices.
• Delivers reliable temperature measurement with 16-bit integrating A/D conversion, high input impedance, diagnostic protection, and stable channel tracking performance.
Technical FAQs
1. What type of module is the GE HE693RTD600M?
The HE693RTD600M is a six-channel RTD input module designed for GE Series 90-30 PLC systems.
2. How many RTD input channels does the module provide?
The module provides six independent RTD temperature input channels.
3. Which RTD sensors are supported by the HE693RTD600M?
The module supports Pt100, Pt1000, Pt-100E, Pt-100C, Ni-120, Cu-10, Cu-50, Cu-53, Cu-100, TD5R, and linear resistance inputs.
4. Does the module require external signal conditioning equipment?
No. The HE693RTD600M performs RTD signal processing internally without requiring external transmitters or signal converters.
5. What type of RTD wiring configuration is supported?
The module supports 3-wire RTD sensor connections for industrial temperature measurement applications.
6. What type of analog conversion technology is used?
The module uses integrating A/D conversion technology for accurate temperature signal processing.
7. Does the module provide temperature value conversion automatically?
Yes. The module converts RTD resistance signals into digital temperature values that can be read by the PLC analog input table.
8. What PLC family is compatible with the HE693RTD600M?
The module is designed for GE Series 90-30 PLC platforms.
9. What applications commonly use this RTD module?
Typical applications include industrial ovens, heating systems, process vessels, environmental control systems, and temperature-regulated machinery.
10. What should be verified before replacing the HE693RTD600M?
Confirm RTD sensor type, wiring configuration, PLC compatibility, channel configuration, and temperature scaling parameters before installation.
