Brand:GE Fanuc PLC Item No.:IC200PWR101G Product Origin:USA Product Dimensions:202 × 21 × 261 mm Product Weight:0.30 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The GE IC200PWR101G Power Supply Module is a dependable AC power solution designed for GE VersaMax PLC systems. It provides regulated backplane power for CPUs, Network Interface Units, and I/O modules, helping maintain stable control performance across industrial automation applications.
With support for both 120 VAC and 240 VAC input environments, the IC200PWR101G offers flexible installation options for machine builders and system integrators. Its ability to operate as either a main power supply or supplemental power source makes it suitable for scalable automation architectures.
Combining compact VersaMax design, reliable DC output regulation, and built-in protection features, the IC200PWR101G remains a practical choice for industrial control upgrades, replacement applications, and long-term system maintenance.
Technical Specifications
Parameter
Details
Model
IC200PWR101G
Product Type
Power Supply Module
Series
GE VersaMax
Input Voltage
85–132 VAC / 176–264 VAC
Nominal Input Voltage
120 VAC / 240 VAC
Input Frequency
47–63 Hz
Input Power
27 VA
Output Voltage
5 VDC, 3.3 VDC
Maximum Total Output Current
1.5 A
Maximum 3.3 VDC Output Current
0.25 A
Maximum 5 VDC Output Current
1.5 A minus 3.3 VDC load
Hold-Up Time
20 ms
Protection
Short Circuit, Overload Protection
Application Mode
Primary or Supplemental Power Supply
Compatible Hardware
VersaMax CPU, NIU, I/O Modules
Cooling Method
Natural Convection
Mounting Type
VersaMax Carrier Mounted
Operating Temperature
0°C to 60°C
Dimensions
Approx. 130 × 107 × 32 mm
Weight
Approx. 0.30 kg
Recommended Companion Models
Model
Product Name
IC200CPU005
VersaMax CPU Module
IC200CHS002
VersaMax I/O Carrier Module
IC200ALG260A
VersaMax Analog Input Module
IC200MDL750B
VersaMax Discrete Output Module
Frequently Selected Alternatives
Model
Product Name
IC200PWR101
VersaMax 120/240 VAC Power Supply Module
IC200PWR102B
VersaMax Expanded AC Power Supply Module
IC200PWR102J
VersaMax Expanded AC Power Supply Module
IC200PWR001
VersaMax Power Supply Module
Where It Excels in Industrial Use
• Designed for GE VersaMax PLC systems, the IC200PWR101G provides reliable 120/240 VAC power conversion for CPUs, Network Interface Units (NIUs), and I/O modules, ensuring stable backplane operation in industrial automation environments.
• Ideal for machine automation, packaging equipment, production lines, material handling systems, and process control applications where consistent PLC power availability is critical.
• Suitable for VersaMax installations requiring a compact primary power source or additional system power support for expanded I/O configurations.
• Commonly applied in OEM equipment, control cabinets, and modernization projects where dependable power regulation and compatibility with existing VersaMax hardware are required.
Key Strengths at a Glance
• Supports 120 VAC and 240 VAC nominal input operation through jumper-based voltage selection, providing flexibility for different industrial power environments.
• Delivers regulated 5 VDC and 3.3 VDC backplane outputs with up to 1.5 A total output current capacity for VersaMax modules.
• Functions as both a primary station power supply and a supplemental power source when installed with a Power Supply Booster Carrier.
• Includes short-circuit and overload protection features to enhance system reliability during industrial operation.
Technical FAQs
1. What type of module is the GE IC200PWR101G?
The IC200PWR101G is a VersaMax 120/240 VAC Power Supply Module designed to provide backplane power for PLC system components.
2. Which PLC platform is compatible with the IC200PWR101G?
The module is designed for GE VersaMax PLC and distributed I/O systems.
3. What input voltage range does the IC200PWR101G support?
It supports 85–132 VAC with the 120 VAC jumper configuration and 176–264 VAC for 240 VAC nominal operation.
4. What output voltages are provided by this power supply module?
The module provides regulated 5 VDC and 3.3 VDC outputs for VersaMax backplane power distribution.
5. What is the maximum output current capacity?
The combined output current is rated up to 1.5 A, with the 3.3 VDC output supporting up to 0.25 A.
6. Can the IC200PWR101G be used as a secondary power source?
Yes. When installed on a Power Supply Booster Carrier, it can provide supplemental power for expanded VersaMax configurations.
7. Does the module require jumper configuration?
Yes. A jumper is used for 120 VAC operation, while 240 VAC operation requires the jumper to be removed.
8. What protection functions are included in the IC200PWR101G?
The module includes short-circuit and overload protection to help protect connected automation equipment.
9. What type of modules receive power from the IC200PWR101G?
It supplies power for VersaMax CPUs, NIUs, and various I/O modules installed on the system rack.
10. What should be checked before replacing the IC200PWR101G?
Confirm input voltage configuration, jumper position, system power requirements, carrier compatibility, and connected module load before installation.
