Brand:GE Fanuc PLC Item No.:IC200UDR002 Product Origin:USA Product Dimensions:110 × 66.8 × 50 mm Product Weight:0.3 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The GE IC200UDR002 Micro PLC Module is a compact automation controller developed for the VersaMax Micro PLC family. By combining processing capability, integrated I/O, and power management into a single unit, it provides an efficient control solution for small and medium-scale automation applications.
Featuring eight 24 VDC inputs and six relay outputs, the IC200UDR002 allows direct connection to common industrial field devices while reducing the need for additional I/O modules. Its built-in high-speed counter capability and flexible input configuration make it suitable for applications requiring both standard machine control and faster signal monitoring.
With its compact footprint, reliable relay switching performance, and proven VersaMax Micro architecture, the IC200UDR002 remains a practical choice for OEM machinery, standalone controllers, and industrial automation upgrades.
Technical Specifications
Parameter
Details
Model
IC200UDR002
Product Type
Micro PLC Module
Series
GE VersaMax Micro
I/O Points
14 Points
Digital Inputs
8 × 24 VDC Inputs
Input Type
Positive/Negative Logic DC Inputs
Digital Outputs
6 × Relay Outputs
Output Type
Normally Open Relay
Relay Output Rating
2 A Maximum
Relay Voltage Range
5–30 VDC / 5–250 VAC
High-Speed Counter Support
Up to 4 Type A or 1 Type A + 1 Type B
Power Supply Input
24 VDC Nominal
Input Voltage Range
24 VDC -20%/+25%
Input Current
Approx. 0.16 A at 24 VDC
Input Power Rating
4 W
User Power Output
24 VDC, 200 mA Maximum
Serial Port Output Power
+5 VDC, 100 mA Maximum
Scan Rate
Approx. 1.1 ms/K Boolean Logic
Mounting Type
Panel Mount
Dimensions
90 × 95 × 76 mm
Weight
Approx. 0.30 kg
Recommended Companion Models
Model
Product Name
IC200UEX012
VersaMax Micro Expansion Unit
IC200PWR102J
VersaMax AC Power Supply Module
IC200MDL750B
VersaMax Discrete Output Module
IC200ALG260A
VersaMax Analog Input Module
Frequently Selected Alternatives
Model
Product Name
IC200UDR001
VersaMax Micro PLC Module
IC200UDR005
VersaMax Micro PLC Module
IC200UDR010
VersaMax Micro PLC Module
IC200UDD110
VersaMax Micro PLC Module
Where It Excels in Industrial Use
• Designed for GE VersaMax Micro PLC systems, the IC200UDR002 integrates CPU control, digital inputs, relay outputs, and power supply functions into a compact standalone automation controller.
• Ideal for compact machine automation, packaging equipment, conveyor systems, small process control units, and OEM equipment requiring reliable PLC functionality without a large modular rack structure.
• Suitable for applications involving pushbuttons, proximity sensors, limit switches, motor starters, solenoids, alarms, and indicator devices through its built-in discrete I/O capability.
• Well suited for space-limited control cabinets and retrofit projects where a self-contained PLC solution can simplify wiring, reduce installation complexity, and improve system maintainability.
Key Strengths at a Glance
• Combines PLC processing, eight 24 VDC digital inputs, six relay outputs, and a 24 VDC power supply into a compact VersaMax Micro controller platform.
• Provides six normally open relay outputs rated up to 2 A, supporting a wide range of AC and DC industrial loads.
• Supports high-speed counter functionality with up to four Type A counters or one Type A and one Type B counter for motion and counting applications.
• Includes built-in user power output capability, serial communication support, and flexible input configuration for efficient machine control solutions.
Technical FAQs
1. What type of module is the GE IC200UDR002?
The IC200UDR002 is a VersaMax Micro 14-point PLC module with integrated CPU, digital inputs, relay outputs, and 24 VDC power supply.
2. How many input points are available on the IC200UDR002?
The module provides eight 24 VDC positive/negative logic input circuits.
3. How many outputs does the IC200UDR002 provide?
The module provides six normally open relay output circuits.
4. What type of loads can the relay outputs control?
The relay outputs can control devices such as motor starters, solenoids, contactors, and indicator equipment using compatible AC or DC field power.
5. What power supply voltage does the IC200UDR002 require?
The module operates from a nominal 24 VDC input power source.
6. Does the IC200UDR002 support high-speed counters?
Yes. It supports up to four Type A high-speed counters or one Type A and one Type B high-speed counter configuration.
7. Can the input channels be used with different logic types?
Yes. The DC inputs support both positive and negative logic configurations.
8. What communication features are available on this PLC?
The module provides serial communication capability for connection with programming devices and compatible communication equipment.
9. Can the relay outputs be used for pulse output functions?
No. The relay outputs support standard relay switching and high-speed counter output functions but are not designed for pulse train or PWM output operation.
10. What should be checked before replacing the IC200UDR002?
Verify the 24 VDC supply requirements, I/O wiring, relay load ratings, communication settings, and PLC program compatibility before replacement.
