Brand:GE Fanuc PLC Item No.: IC200UER016 Product Origin:USA Product Dimensions:109 × 64 × 58 mm Product Weight:0.30 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The GE IC200UER016 Relay Output Expansion Module is a practical expansion solution for VersaMax Micro PLC systems, providing sixteen additional relay outputs to accommodate growing automation requirements. Designed for reliable industrial switching, it allows engineers to control a wide range of AC and DC field devices while maintaining the compact footprint of the VersaMax Micro platform.
Its normally open relay contacts offer excellent electrical isolation and broad voltage compatibility, making the IC200UER016 suitable for applications involving motors, solenoid valves, alarms, contactors, and other industrial equipment. The included expansion cable enables straightforward integration with compatible VersaMax Micro controllers.
Built for dependable operation and flexible system expansion, the IC200UER016 is an excellent choice for OEM equipment, machine upgrades, and industrial automation projects that demand reliable relay output performance.
Technical Specifications
Parameter
Details
Model
IC200UER016
Product Type
Relay Output Expansion Module
Series
GE VersaMax Micro
Output Channels
16
Output Type
Normally Open Relay (Form A, SPST)
Rated Output Voltage
5–30 VDC / 5–250 VAC
Maximum Output Current
2 A per Point
Maximum Common Current
5 A per Common
Maximum Resistive Load
2 A @ 24 VDC / 240 VAC
Response Time
15 ms Maximum
Isolation (Field to Logic)
1500 V RMS
Isolation Between Groups
500 V RMS
Supply Voltage
24 VDC Nominal
Input Voltage Range
19.2–30 VDC
Input Current
0.16 A Typical
Input Power
4 W
Expansion Cable
IC200CBL501 Included
Mounting Type
Panel Mount
Operating Temperature
0°C to 55°C
Dimensions
Approx. 95 × 90 × 76 mm
Weight
Approx. 0.35 kg
Recommended Companion Models
Model
Product Name
IC200UDR040
VersaMax Micro PLC Module
IC200UEI016
VersaMax Micro 16-Point Digital Input Expansion Module
• Designed for GE VersaMax Micro PLC systems, the IC200UER016 expands controller output capacity by adding 16 relay output channels for industrial machine control and automation applications.
• Ideal for packaging machinery, conveyor systems, assembly equipment, material handling systems, and OEM machines that require additional relay-controlled field devices.
• Suitable for switching motor starters, contactors, solenoid valves, alarm devices, signal lamps, and other AC or DC loads where electrically isolated relay contacts are preferred.
• Well suited for automation upgrades and system expansion projects requiring increased output capacity without replacing the existing VersaMax Micro PLC.
Key Strengths at a Glance
• Provides 16 normally open Form A (SPST) relay outputs for flexible industrial load control.
• Supports switching voltages from 5–30 VDC and 5–250 VAC, allowing compatibility with a wide range of industrial equipment.
• Delivers up to 2 A per relay output with 5 A maximum per common terminal, making it suitable for demanding industrial applications.
• Operates from a 24 VDC power supply and connects directly to compatible VersaMax Micro PLCs using the supplied expansion cable for quick installation.
Technical FAQs
1. What type of module is the GE IC200UER016?
The IC200UER016 is a 16-point relay output expansion module for GE VersaMax Micro PLC systems.
2. How many relay outputs does the module provide?
The module provides sixteen normally open relay output channels.
3. What relay contact configuration is used?
Each output uses a Form A (SPST) normally open relay contact.
4. What output voltage range is supported?
The relay outputs can switch loads from 5–30 VDC or 5–250 VAC.
5. What is the maximum current rating per relay output?
Each output supports up to 2 A, while each common terminal supports a maximum of 5 A.
6. Does the IC200UER016 require external field power?
Yes. External AC or DC field power is required to operate connected field devices.
7. What supply voltage powers the expansion module?
The module operates from a nominal 24 VDC power supply.
8. Is the relay output section electrically isolated?
Yes. The module provides 1500 V RMS isolation between the field side and logic side, with 500 V RMS isolation between output groups.
9. Which PLC family is compatible with the IC200UER016?
The IC200UER016 is designed specifically for GE VersaMax Micro PLC systems.
10. What should be checked before replacing the IC200UER016?
Verify PLC compatibility, output load ratings, 24 VDC supply, relay wiring, and expansion cable connections before installation.
