Brand:GE Fanuc PLC Item No.: IC693APU300H Product Origin:USA Product Dimensions:110 × 66.8 × 50 mm Product Weight:0.30 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The GE IC693APU300H High-Speed Counter Module is engineered to deliver accurate pulse counting and encoder processing for demanding industrial automation systems. As part of the Series 90-30 PLC family, it extends standard PLC capabilities by handling high-speed input events independently of the CPU scan cycle, ensuring precise position, speed, and motion measurements.
Supporting multiple counter operating modes, configurable filters, and dedicated high-speed outputs, the IC693APU300H offers exceptional flexibility for machine builders and automation engineers. Its ability to process encoder feedback and pulse signals at frequencies up to 80 kHz makes it an excellent solution for high-performance production equipment.
With proven Series 90-30 compatibility, rugged industrial construction, and advanced counting functionality, the IC693APU300H remains a trusted choice for precision automation, motion monitoring, and factory modernization projects.
Technical Specifications
Parameter
Details
Model
IC693APU300H
Product Type
High-Speed Counter Module
Series
GE Series 90-30
Counter Modes
6 Configurable Modes
Maximum Count Frequency
80 kHz
Minimum Count Frequency
20 Hz
Digital Inputs
12 High-Speed Inputs
Input Voltage
5 VDC or 10–30 VDC Positive Logic
Digital Outputs
4 High-Speed Outputs
Output Voltage
10–30 VDC @ 500 mA, 4.75–6 VDC @ 20 mA
Output Protection
3 A Common Fuse
Input Filters
2.5 μs / 12.5 ms Selectable
Counter Presets
Two per Counter
Strobe Registers
Supported
Isolation
Optical Isolation
Backplane Current
250 mA @ 5 VDC
Connector Type
20-Screw Terminal Block
Mounting
Series 90-30 Baseplate
Operating Temperature
0°C to 60°C
Dimensions
Approx. 130 × 130 × 30 mm
Weight
Approx. 0.75 kg
Recommended Companion Models
Model
Product Name
IC693CPU364
CPU Module
IC693PWR330
High Capacity Power Supply Module
IC693CHS398
16-Slot Expansion Baseplate
IC693ACC307
Hand-Held Programmer
Frequently Selected Alternatives
Model
Product Name
IC693APU301
High-Speed Counter Module
IC693APU302
Motion Mate APM Motion Control Module
IC695HSC304
PACSystems RX3i High-Speed Counter Module
IC200HSC001
VersaMax High-Speed Counter Module
Where It Excels in Industrial Use
• Designed for GE Series 90-30 PLC systems, the IC693APU300H High-Speed Counter Module provides precision counting and high-speed position feedback for demanding industrial automation applications. It supports multiple counting modes with frequencies up to 80 kHz.
• Ideal for encoder feedback, conveyor tracking, cut-to-length machinery, packaging equipment, printing presses, labeling systems, and motion monitoring applications requiring accurate pulse acquisition.
• Compatible with incremental encoders, proximity sensors, optical sensors, and high-speed pulse generators used in manufacturing, material handling, and process automation systems.
• Perfect for OEM machine builders and retrofit projects where high-speed event processing and dependable counter performance are essential.
Key Strengths at a Glance
• Supports six configurable counter operating modes, including independent up/down counting, quadrature encoder counting, and differential counting for versatile industrial applications.
• Processes high-frequency input signals up to 80 kHz with selectable input filtering for both high-speed and low-speed applications.
• Features twelve high-speed digital inputs and four protected high-speed outputs for integrated counting and control functions.
• Provides optical isolation, configurable preset outputs, strobe registers, and hardware protection to ensure reliable operation in harsh industrial environments.
Technical FAQs
1. What type of module is the GE IC693APU300H?
The IC693APU300H is a High-Speed Counter Module for the GE Series 90-30 PLC platform.
2. What is the maximum counting frequency?
The module supports high-frequency counting up to 80 kHz and low-frequency counting down to approximately 20 Hz.
3. How many digital inputs are available?
The IC693APU300H provides twelve high-speed digital input channels for pulse and encoder signals.
4. How many outputs does the module provide?
The module includes four high-speed positive logic outputs for preset and control functions.
5. Which encoder types are supported?
The module supports incremental encoders, including A/B quadrature encoder inputs for bidirectional position measurement.
6. Does the module support configurable input filtering?
Yes. Selectable high-frequency (2.5 μs) and low-frequency (12.5 ms) input filters are available to match application requirements.
7. Are the outputs protected against short circuits?
Yes. The four outputs are protected by a common 3 A fuse.
8. What input voltage does the module accept?
Inputs support either 5 VDC or 10–30 VDC positive logic signals depending on jumper configuration.
9. Can the IC693APU300H be installed in a standard Series 90-30 rack?
Yes. The module is fully compatible with supported GE Series 90-30 baseplates and CPUs.
10. What should be verified before replacing the module?
Verify the counter configuration, encoder wiring, input voltage selection, CPU compatibility, preset parameters, and application program before installation.
