Brand:GE Fanuc PLC Item No.: IC693APU300L Product Origin:USA Product Dimensions:109 × 64 × 58 mm Product Weight:0.30 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The GE IC693APU300L High-Speed Counter Module is a specialized intelligent I/O module developed for the GE Fanuc Series 90-30 PLC platform. It provides fast and accurate pulse counting for industrial systems where conventional PLC inputs and scan times are insufficient.
By processing high-frequency signals directly at the module level, the IC693APU300L reduces CPU workload and enables precise control of high-speed machinery. It is widely used in applications involving rotary encoders, flow meters, motion systems, and production equipment requiring accurate event counting.
The module remains valuable in industrial maintenance and retrofit projects where existing Series 90-30 automation systems require continued high-speed measurement capability.
Technical Specifications
Parameter
Details
Model
IC693APU300L
Product Type
High-Speed Counter Module
Series
GE Fanuc Series 90-30
Module Function
High-Speed Pulse Counting
Inputs
12 Positive Logic Inputs
Outputs
4 Positive Logic Outputs
Input Voltage
5 VDC / 10–30 VDC
Output Voltage
10–30 VDC / 5 VDC
Maximum Count Rate
80 kHz
Counter Modes
Up, Down, Up/Down, Differential
Output Protection
Short-Circuit Protection
Backplane Power
5 VDC
Current Consumption
Approx. 250 mA
Mounting
Single Series 90-30 Rack Slot
Configuration
Software Configured
Operating Temperature
0°C to 60°C
Hardware Revision
L
Recommended Companion Models
Model
Product Name
IC693CPU331
Series 90-30 CPU Module
IC693CPU341
Series 90-30 CPU Module
IC693CHS391
Series 90-30 10-Slot Baseplate
IC693PWR321
Series 90-30 Power Supply Module
IC693MDL645
24 VDC Input Module
Frequently Selected Alternatives
Model
Product Name
IC694APU300
RX3i/Series 90-30 High-Speed Counter Module
IC693DSM302
Motion Control Module
IC693APU301
Enhanced High-Speed Counter Variant
IC695HSC304
PACSystems RX3i High-Speed Counter Module
Where It Excels in Industrial Use
• The GE IC693APU300L is a High-Speed Counter (HSC) Module designed for the GE Fanuc Series 90-30 PLC family, providing dedicated processing of high-frequency pulse signals that are too fast for normal PLC scan-based counting.
• Ideal for applications such as:
Encoder feedback
Turbine flow measurement
Meter proving
Velocity measurement
Material handling
Motion control
Process monitoring
• The module performs counting and output response independently of the PLC CPU scan cycle, improving accuracy in high-speed automation applications.
• Commonly used in legacy Series 90-30 systems where precise pulse counting and fast output triggering are required.
Key Strengths at a Glance
• Supports high-speed pulse processing up to approximately 80 kHz, allowing accurate counting of rapid input signals.
• Provides 12 positive logic inputs supporting 5 VDC and 10–30 VDC signal levels.
• Includes 4 positive logic outputs for direct high-speed control actions.
• Supports multiple counting modes:
Up counting
Down counting
Up/down counting
Differential counting
• Configurable through GE programming tools without hardware jumper settings.
Technical FAQs
1. What type of module is the GE IC693APU300L?
The IC693APU300L is a Series 90-30 High-Speed Counter Module.
2. What is the main purpose of this module?
It provides dedicated high-speed pulse counting for applications where standard PLC inputs cannot process fast enough.
3. What PLC family uses the IC693APU300L?
It is designed for the GE Fanuc Series 90-30 PLC family and can also be used in supported PACSystems RX3i configurations.
4. How many inputs does the module provide?
The module provides 12 positive logic inputs.
5. How many outputs are available?
The module provides 4 positive logic outputs.
6. What input voltage levels are supported?
Inputs support:
5 VDC
10–30 VDC
7. What is the maximum counting frequency?
The module supports high-speed counting up to approximately 80 kHz depending on configuration and operating mode.
8. Does the module require CPU processing for counting?
No. The module directly processes pulse inputs and can respond with outputs without waiting for CPU scan processing.
9. How is the module configured?
Configuration is performed through GE programming software such as Logicmaster, VersaPro, or Logic Developer-PLC.
