Brand:Schneider PLC Item No.:TM238LDD24DT Product Origin:France Product Dimensions:202 × 21 × 261 mm Product Weight:0.30 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Schneider TM238LDD24DT Logic Controller Module is part of the Modicon M238 PLC family, developed for compact industrial automation systems requiring reliable control, fast signal processing, and flexible machine integration. Featuring 24 integrated I/O points, high-speed inputs, transistor outputs, internal memory, and expansion capability, it provides a dependable automation foundation for OEM machine builders and industrial system designers.
Designed for demanding automation environments, the TM238LDD24DT combines compact installation with strong processing performance. Its fast I/O architecture makes it especially suitable for machines requiring accurate sequencing, rapid response, and stable production operation.
Technical Specifications
Parameter
Specification
Brand
Schneider Electric
Model Number
TM238LDD24DT
Product Type
Logic Controller Module
Product Range
Modicon M238
Controller Type
Compact PLC
Rated Supply Voltage
24 VDC
Integrated I/O Number
24
Digital Inputs
6
Fast Inputs
8
Input Voltage
24 VDC
Input Type
Sink/Source
Digital Outputs
6
Fast Outputs
4
Output Type
24 VDC Transistor
Output Current
Up to 0.5 A per output
Internal Memory
500 kB RAM
Communication Interface
USB Programming Port
Communication Protocol
Modbus
Expansion Capability
Up to 7 Expansion Modules
Mounting Type
DIN Rail / Panel Mount
Protection Rating
IP20
Operating Temperature
-10...55°C
Storage Temperature
-40...70°C
Dimensions (W × H × D)
Approx. 157 × 118 × 86 mm
Weight
Approx. 560 g
Recommended Companion Models
Model
Product Name
TM2AMI2HT
Schneider Modicon M238 Analog Input Module
TM2DDI16DT
Schneider Modicon M238 Digital Input Expansion Module
• Compact Industrial Machine Automation
The Schneider TM238LDD24DT is a Modicon M238 compact logic controller designed for machine automation applications requiring fast processing, integrated I/O control, and reliable 24 VDC operation. With 24 integrated discrete I/O points, it provides an efficient control platform for packaging equipment, material handling systems, assembly machines, and compact production lines where space optimization and dependable performance are critical.
• High-Speed Motion and Sequencing Control
The TM238LDD24DT integrates fast inputs and fast transistor outputs, making it suitable for applications involving counting, positioning, pulse operations, and synchronized machine sequences. Its high-speed processing capability supports automation systems that require accurate timing and rapid response.
• Sensor and Actuator Integration Systems
With multiple digital inputs and transistor outputs, the controller can directly manage sensors, solenoid valves, actuators, and industrial devices. Its compact architecture reduces additional hardware requirements while maintaining flexible machine control capability.
• Expandable Automation Platforms
The TM238LDD24DT supports Modicon M238 expansion modules, allowing additional I/O functionality to be added for larger automation projects. This makes it suitable for OEM equipment designs requiring future scalability and system upgrades.
Key Strengths at a Glance
• 24 Integrated I/O Points
The TM238LDD24DT provides a balanced I/O configuration with digital inputs, fast inputs, standard outputs, and fast transistor outputs for versatile industrial control applications.
• Fast Input and Output Performance
The controller includes high-speed input channels and fast 24 VDC transistor outputs, supporting precise counting, rapid switching, and time-sensitive automation processes.
• Powerful Memory Capacity
With 500 kB internal RAM, the TM238LDD24DT provides sufficient application memory for structured PLC programs, machine logic, and retained variables used in industrial automation projects.
• Flexible Communication and Expansion Design
USB programming capability, Modbus communication support, and compatibility with M238 expansion modules provide convenient commissioning and long-term system flexibility.
Technical FAQs
1. What type of product is the Schneider TM238LDD24DT?
The Schneider TM238LDD24DT is a Modicon M238 compact logic controller designed for industrial machine automation applications.
2. How many integrated I/O points does the TM238LDD24DT provide?
The TM238LDD24DT provides 24 discrete I/O points, including digital inputs and transistor outputs.
3. What type of outputs does the TM238LDD24DT use?
The TM238LDD24DT uses 24 VDC transistor outputs, including fast outputs for applications requiring rapid switching performance.
4. What power supply does the TM238LDD24DT require?
The TM238LDD24DT operates with a 24 VDC power supply suitable for industrial control cabinet applications.
5. Does the TM238LDD24DT support high-speed counting functions?
Yes. The TM238LDD24DT supports fast input functions for applications requiring high-speed counting and event processing.
6. Which programming software is used for the TM238LDD24DT?
The TM238LDD24DT is programmed using Schneider Electric SoMachine software for Modicon M238 controllers.
7. Does the TM238LDD24DT support Modbus communication?
Yes. The TM238LDD24DT supports Modbus communication functions for industrial device integration.
8. Can the TM238LDD24DT be expanded with additional modules?
Yes. The TM238LDD24DT supports up to 7 I/O expansion modules for extending system functionality.
9. What type of mounting is supported by the TM238LDD24DT?
The TM238LDD24DT supports 35 mm DIN rail mounting and panel mounting installation methods.
10. Is the TM238LDD24DT suitable for OEM automation equipment?
Yes. The TM238LDD24DT is designed for OEM machinery requiring compact PLC control, fast I/O response, and flexible expansion capability.
