Brand:Schneider PLC Item No.: TM238LFAC24DR Product Origin:France Product Dimensions:110 × 66.8 × 50 mm Product Weight:0.36 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Schneider TM238LFAC24DR Logic Controller Module is part of the Modicon M238 PLC family, developed for industrial automation systems requiring reliable processing, flexible I/O control, and network communication capability. Featuring 24 integrated I/O points, mixed relay and transistor outputs, CANopen communication, and expansion support, it provides a practical control solution for machine builders and automation engineers.
Designed for demanding industrial environments, the TM238LFAC24DR combines compact installation with versatile control functions. Its combination of standard relay switching and fast transistor outputs allows engineers to build efficient automation systems that require both dependable load control and rapid signal response.
Technical Specifications
Parameter
Specification
Brand
Schneider Electric
Model Number
TM238LFAC24DR
Product Type
Logic Controller Module
Product Range
Modicon M238
Controller Type
Compact PLC
Rated Supply Voltage
110...240 VAC
Integrated I/O Number
24
Digital Inputs
6
Fast Inputs
8
Input Voltage
24 VDC
Input Type
Sink / Source
Relay Outputs
6
Transistor Outputs
4
Transistor Output Voltage
24 VDC
Relay Output Voltage
24 VDC / 240 VAC
Maximum Transistor Output Current
500 mA
Relay Output Current
Up to 4 A per common
Communication Interface
CANopen + Serial Line
Communication Ports
2
Communication Protocol
CANopen / Modbus
Internal Memory
1000 kB RAM
Expansion Capability
Up to 7 I/O Modules
Programming Software
SoMachine
Mounting Type
DIN Rail / Panel Mount
Protection Rating
IP20
Operating Temperature
-10...55°C
Storage Temperature
-25...70°C
Dimensions (W × H × D)
Approx. 157 × 118 × 86 mm
Weight
Approx. 500 g
Recommended Companion Models
Model
Product Name
TM2AMI2HT
Schneider Modicon M238 Analog Input Expansion Module
TM2DDI16DT
Schneider Modicon M238 Digital Input Expansion Module
• Industrial Machine Control with Mixed Output Requirements
The Schneider TM238LFAC24DR is a Modicon M238 compact logic controller designed for automation systems requiring a combination of relay outputs, transistor outputs, CANopen communication, and flexible I/O management. Its mixed output architecture makes it suitable for packaging machines, material handling systems, assembly equipment, and industrial production lines that require both standard switching and fast response control.
• Complex Sequencing and High-Speed Signal Processing
With fast digital inputs and solid-state transistor outputs, the TM238LFAC24DR supports applications involving high-speed counting, event detection, and precise machine sequencing. It provides reliable control performance for equipment where accurate timing and rapid signal processing are important.
• CANopen-Based Automation Networks
The integrated CANopen communication capability allows the TM238LFAC24DR to connect with distributed automation devices, drives, and remote I/O systems, making it suitable for coordinated machine architectures and networked control applications.
• Expandable Compact PLC Systems
Supporting Modicon M238 expansion modules, the controller can be extended with additional I/O modules to meet growing automation requirements. This provides OEM machine builders with a scalable control platform for different machine configurations.
Key Strengths at a Glance
• 24-Point Integrated I/O Configuration
The TM238LFAC24DR provides 24 integrated discrete I/O points, including digital inputs, fast inputs, relay outputs, and transistor outputs for versatile industrial control tasks.
• Combination of Relay and Transistor Outputs
The controller integrates 6 relay outputs and 4 solid-state transistor outputs, allowing flexible control of different field devices such as contactors, valves, and fast-response actuators.
• CANopen and Modbus Communication Support
Built-in CANopen capability together with serial communication interfaces helps simplify integration with industrial networks and automation components.
• Large Application Memory Capacity
With 1000 kB internal RAM, the TM238LFAC24DR provides sufficient memory space for structured PLC programs, machine logic, and retained application variables.
Key Strengths at a Glance
• 24-Point Integrated I/O Configuration
The TM238LFAC24DR provides 24 integrated discrete I/O points, including digital inputs, fast inputs, relay outputs, and transistor outputs for versatile industrial control tasks.
• Combination of Relay and Transistor Outputs
The controller integrates 6 relay outputs and 4 solid-state transistor outputs, allowing flexible control of different field devices such as contactors, valves, and fast-response actuators.
• CANopen and Modbus Communication Support
Built-in CANopen capability together with serial communication interfaces helps simplify integration with industrial networks and automation components.
• Large Application Memory Capacity
With 1000 kB internal RAM, the TM238LFAC24DR provides sufficient memory space for structured PLC programs, machine logic, and retained application variables.
Technical FAQs
1. What type of product is the Schneider TM238LFAC24DR?
The Schneider TM238LFAC24DR is a Modicon M238 compact logic controller designed for industrial automation and machine control applications.
2. How many integrated I/O points does the TM238LFAC24DR provide?
The TM238LFAC24DR provides 24 integrated discrete I/O points, including digital inputs and digital outputs.
3. What type of outputs does the TM238LFAC24DR use?
The TM238LFAC24DR uses 6 relay outputs and 4 solid-state transistor outputs for controlling industrial devices.
4. What power supply does the TM238LFAC24DR require?
The TM238LFAC24DR operates with a 110...240 VAC rated supply voltage.
5. Does the TM238LFAC24DR support high-speed inputs?
Yes. The TM238LFAC24DR includes fast input channels designed for high-speed signal acquisition and counting applications.
6. Which communication protocols are supported by the TM238LFAC24DR?
The TM238LFAC24DR supports CANopen communication and serial communication interfaces for industrial networking.
7. Which programming software is used for the TM238LFAC24DR?
The TM238LFAC24DR is programmed using Schneider Electric SoMachine software for Modicon M238 controllers.
8. Can the TM238LFAC24DR be expanded with additional modules?
Yes. The TM238LFAC24DR supports up to 7 I/O expansion modules for extending system functionality.
9. What type of mounting is supported by the TM238LFAC24DR?
The TM238LFAC24DR supports 35 mm DIN rail mounting and panel mounting installation methods.
10. Is the TM238LFAC24DR suitable for OEM machine builders?
Yes. The TM238LFAC24DR is designed for OEM automation equipment requiring compact PLC control, communication capability, and flexible I/O configuration.
