Brand:Schneider PLC Item No.: TM238LFDC24DT Product Origin:France Product Dimensions:202 × 21 × 261 mm Product Weight:0.3 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Schneider TM238LFDC24DT Logic Controller Module is part of the Modicon M238 PLC family, developed for industrial automation systems requiring fast processing, reliable control, and flexible machine communication. Featuring 24 integrated I/O points, CANopen networking, fast transistor outputs, high-speed inputs, and expandable architecture, it provides a powerful solution for OEM machine builders and automation engineers.
Designed for demanding production environments, the TM238LFDC24DT combines compact installation with advanced control functionality. Its high-speed I/O performance and communication flexibility make it suitable for machines requiring precise sequencing, coordinated device control, and dependable long-term operation.
Technical Specifications
Parameter
Specification
Brand
Schneider Electric
Model Number
TM238LFDC24DT
Product Type
Logic Controller Module
Product Range
Modicon M238
Controller Type
Compact PLC
Rated Supply Voltage
24 VDC
Supply Voltage Range
19.2...30 VDC
Integrated I/O Number
24
Standard Digital Inputs
6
Fast Inputs
8
Input Type
24 VDC Sink/Source
Standard Outputs
6
Fast Outputs
4
Output Type
24 VDC Transistor
Maximum Output Current
500 mA
PWM / PTO Output Current
100 mA
Internal Memory
1000 kB RAM
Communication Interface
CANopen
Communication Protocol
CANopen / Modbus
Expansion Capability
Up to 7 I/O Modules
Programming Software
SoMachine
Mounting Type
35 mm DIN Rail / Panel Mount
Protection Rating
IP20
Operating Temperature
-10...55°C
Storage Temperature
-40...70°C
Dimensions (W × H × D)
Approx. 157 × 118 × 86 mm
Weight
Approx. 1.66 kg
Recommended Companion Models
Model
Product Name
TM2AMI2HT
Schneider Modicon M238 Analog Input Expansion Module
TM2DDI16DT
Schneider Modicon M238 Digital Input Expansion Module
• High-Performance Compact Machine Automation
The Schneider TM238LFDC24DT is a Modicon M238 compact logic controller designed for advanced industrial automation applications requiring fast signal processing, CANopen communication, and reliable 24 VDC operation. With 24 integrated I/O points, it provides an efficient control platform for packaging systems, assembly equipment, material handling machines, and OEM automation solutions where compact design and strong processing capability are essential.
• Motion-Oriented and High-Speed Control Applications
The TM238LFDC24DT integrates fast inputs and fast transistor outputs, making it suitable for high-speed counting, pulse train output, PWM control, frequency generation, and synchronized machine operations. It delivers precise response performance for applications requiring accurate timing and repeatable motion sequences.
• CANopen-Based Distributed Automation Systems
With built-in CANopen communication capability, the TM238LFDC24DT can connect with drives, remote I/O devices, and distributed automation components, supporting efficient communication architectures for complex industrial machines.
• Expandable Industrial Control Platforms
Supporting up to 7 I/O expansion modules, the TM238LFDC24DT allows engineers to extend system functionality with additional digital, analog, and specialized modules, providing flexibility for evolving automation requirements.
Key Strengths at a Glance
• 24 Integrated I/O Configuration
The TM238LFDC24DT provides 24 discrete I/O points, including 6 standard inputs, 8 fast inputs, 6 standard outputs, and 4 fast outputs for versatile machine control applications.
• Fast Transistor Output Capability
The controller features four fast transistor outputs supporting rapid switching functions, with compatibility for PWM, frequency generator, and pulse-related applications.
• Large Internal Memory Capacity
With 1000 kB internal RAM, the TM238LFDC24DT provides sufficient application space for structured PLC programs, machine logic, retained variables, and complex automation sequences.
• Flexible Communication Architecture
The integrated CANopen interface, Modbus capability, and programming connectivity simplify machine networking, commissioning, and long-term system maintenance.
Technical FAQs
1. What type of product is the Schneider TM238LFDC24DT?
The Schneider TM238LFDC24DT is a Modicon M238 compact logic controller designed for industrial automation and machine control applications.
2. How many integrated I/O points does the TM238LFDC24DT provide?
The TM238LFDC24DT provides 24 integrated discrete I/O points, including standard inputs, fast inputs, standard outputs, and fast outputs.
3. What type of outputs does the TM238LFDC24DT use?
The TM238LFDC24DT uses 24 VDC transistor outputs, including four fast outputs designed for high-speed control functions.
4. What power supply does the TM238LFDC24DT require?
The TM238LFDC24DT requires a 24 VDC power supply with an operating range of approximately 19.2...30 VDC.
5. Does the TM238LFDC24DT support high-speed counting?
Yes. The TM238LFDC24DT includes fast input channels designed for high-speed counting and event processing applications.
6. Which communication protocol does the TM238LFDC24DT support?
The TM238LFDC24DT supports CANopen communication for integration with industrial devices and automation networks.
7. Which programming software is used for the TM238LFDC24DT?
The TM238LFDC24DT is programmed using Schneider Electric SoMachine software for Modicon M238 controllers.
8. Can the TM238LFDC24DT support PWM and pulse functions?
Yes. The TM238LFDC24DT supports PWM, pulse train output, and frequency generator functions through dedicated fast outputs.
9. Can the TM238LFDC24DT be expanded with additional modules?
Yes. The TM238LFDC24DT supports up to seven I/O expansion modules for additional automation functions.
10. Is the TM238LFDC24DT suitable for OEM machine builders?
Yes. The TM238LFDC24DT is designed for OEM machinery requiring compact PLC control, fast I/O processing, communication capability, and scalable expansion options.
