Brand:Schneider PLC Item No.: TM241C24T Product Origin:France Product Dimensions:202 × 21 × 261 mm Product Weight:0.30 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Schneider TM241C24T Logic Controller Module is part of the Modicon M241 PLC family, developed for machine automation applications that require high-speed control, flexible communication, and reliable system expansion. Featuring 24 integrated I/O points, transistor outputs, fast processing capability, and compatibility with Schneider Electric expansion modules, it provides a powerful foundation for modern industrial automation systems.
Designed for compact control cabinets and demanding production environments, the TM241C24T combines performance with installation efficiency. Its fast transistor output design makes it especially suitable for machines requiring accurate motion sequences, rapid switching operations, and dependable long-term operation.
• High-Speed Machine Automation Control
The Schneider TM241C24T is a Modicon M241 compact logic controller designed for demanding machine automation applications requiring fast processing, transistor output performance, and flexible system integration. With 24 integrated I/O points, it provides an efficient control solution for packaging equipment, material handling systems, assembly machines, and production automation lines where precision and response speed are essential.
• Motion and Pulse-Based Control Applications
The TM241C24T features high-speed transistor outputs and fast input channels, making it suitable for applications involving pulse train output, high-speed counting, positioning tasks, and synchronized machine operations. Its transistor-based architecture enables accurate control of fast-response industrial devices and motion-related components.
• Compact Automation Systems with Flexible Communication
Designed for modern machine architectures, the TM241C24T supports Modbus communication and expansion capabilities, allowing seamless integration with HMIs, drives, remote devices, and additional I/O modules. It helps simplify machine design while maintaining long-term scalability.
• OEM Equipment Development Platforms
The TM241C24T provides a balance between processing capability, compact dimensions, and expandable functionality, making it an ideal controller for OEM builders developing standardized machines and customized automation solutions.
Key Strengths at a Glance
• 24-Point Transistor I/O Configuration
The TM241C24T integrates 14 digital inputs and 10 transistor outputs, including 8 fast inputs and 4 fast outputs, providing a versatile hardware structure for industrial control applications.
• Fast PNP Transistor Output Performance
The controller uses 24 VDC source transistor outputs with fast switching capability, supporting applications requiring rapid actuator control, pulse output, and accurate timing functions.
• Efficient Machine Programming Environment
The TM241C24T is programmed through EcoStruxure Machine Expert, providing engineers with structured programming tools, reusable function blocks, and efficient commissioning features.
• Expandable Control Architecture
Supporting local and remote I/O expansion options, the TM241C24T allows additional modules to be added for increased system flexibility, helping machines adapt to future production requirements.
Technical FAQs
1. What type of product is the Schneider TM241C24T?
The Schneider TM241C24T is a Modicon M241 programmable logic controller designed for industrial machine automation and compact control applications.
2. How many integrated I/O points does the TM241C24T provide?
The TM241C24T provides 24 integrated I/O points, including 14 digital inputs and 10 transistor outputs.
3. What type of outputs are available on the TM241C24T?
The TM241C24T uses 24 VDC PNP transistor outputs, including four fast outputs designed for high-speed control functions.
4. What power supply does the TM241C24T require?
The TM241C24T operates with a 24 VDC power supply, with an allowable supply range of approximately 20.4 to 28.8 VDC.
5. Does the TM241C24T support high-speed counting functions?
Yes. The TM241C24T includes fast input channels designed for high-speed counting and rapid signal processing applications.
6. Which programming software is used for the TM241C24T?
The TM241C24T is programmed using Schneider Electric EcoStruxure Machine Expert software.
7. Does the TM241C24T support pulse output functions?
Yes. The TM241C24T supports pulse train output and other high-speed output functions through its dedicated fast transistor outputs.
8. What communication functions are supported by the TM241C24T?
The TM241C24T supports serial communication functions including Modbus communication for industrial device integration.
9. Can the TM241C24T be expanded with additional modules?
Yes. The TM241C24T supports additional I/O expansion modules, allowing engineers to extend system capacity for larger automation projects.
10. Is the TM241C24T suitable for OEM machine builders?
Yes. The TM241C24T is designed for OEM applications requiring compact PLC control, fast transistor outputs, reliable communication, and scalable automation performance.
