Brand:Schneider PLC Item No.:TM241C40T Product Origin:France Product Dimensions:110 × 66.8 × 50 mm Product Weight:0.36 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
Introduction: Built for Modern Industrial Automation
The Schneider TM241C40T CPU Module represents a balanced solution between compact machine control and advanced automation performance. Designed within the Modicon M241 family, it combines integrated I/O, communication capabilities, and programming flexibility into a single industrial controller.
This module helps manufacturers create smarter machines with improved operational stability and easier lifecycle management. Whether used in standalone equipment or integrated production systems, the TM241C40T provides the processing foundation required for reliable industrial automation.
Its combination of performance, scalability, and engineering convenience makes it a preferred choice for applications where efficiency and long-term reliability are essential.
Technical Specifications
Parameter
Details
Product Model
TM241C40T
Product Series
Modicon M241
Module Type
CPU Module / Logic Controller
Digital Inputs
24 inputs
Digital Outputs
16 transistor outputs
Fast Inputs
8 fast inputs
Fast Outputs
4 fast outputs
Supply Voltage
24 V DC
Memory Capacity
8 MB program memory, 64 MB system RAM
Storage Support
SD card support up to 16 GB
Communication Interface
Serial communication ports, USB mini-B programming port
Communication Protocol
Modbus master/slave
Programming Software
EcoStruxure Machine Expert
Mounting Type
DIN rail mounting
Protection Rating
IP20
Operating Temperature
-10°C to +55°C
Dimensions (W × H × D)
190 × 90 × 95 mm
Weight
0.62 kg
Recommended Related Models
Model
Module Type
Description
TM241C24T
CPU Module
Compact Modicon M241 controller for smaller automation systems
TM241CE24T
CPU Module
M241 controller with Ethernet communication capability
TM241CE40T
CPU Module
Higher connectivity version with Ethernet support
TM251MESE
CPU Module
Advanced M251 controller for complex machine applications
Popular Related Models
Model
Category
Application
TM221CE40T
Machine Controller
Compact machine automation and OEM equipment
TM262L20MESE8T
Motion Controller
Advanced motion and synchronized machine control
BMXP342020
PLC CPU Module
Industrial PLC automation platforms
TM3DI16
Digital Input Module
Additional digital input expansion
TM3DQ16T
Digital Output Module
Additional transistor output expansion
Schneider TM241C40T CPU Module provides a reliable and scalable automation foundation for manufacturers seeking efficient machine control, flexible expansion, and dependable industrial performance. Its compact architecture and engineering-friendly features make it a strong choice for modern automation projects.
Where It Excels in Industrial Use
• High-I/O Machine Automation Systems
The Schneider TM241C40T is a Modicon M241 compact logic controller designed for medium-to-complex industrial machines requiring a higher number of digital I/O points, fast transistor switching, and scalable automation capability. With 40 integrated I/O points, it is suitable for packaging machines, conveyors, assembly lines, labeling systems, and OEM machinery.
• High-Speed Motion and Pulse Applications
The TM241C40T uses transistor outputs rather than relays, making it ideal for applications requiring rapid switching, pulse train output (PTO), PWM control, and high-speed actuator control. The controller includes fast inputs and fast outputs for precise timing operations.
• PNP Transistor Output Control
The controller provides 24 VDC source (PNP) transistor outputs, allowing direct control of compatible sensors, valves, drives, and actuators where fast response and electrical efficiency are required.
• Expandable OEM Automation Platform
The TM241C40T supports TM3/TM4 expansion modules, allowing additional digital, analog, and communication functions to be added for larger automation projects.
Key Advantages of Schneider TM241C40T
High-Performance Machine Control
The TM241C40T delivers efficient application execution for demanding automation tasks, supporting precise control functions and smooth machine operation. Its processing capability helps reduce response times and improves overall production consistency.
Integrated I/O Flexibility
Featuring 40 integrated I/O channels, this controller combines digital inputs and transistor outputs in a compact design. The built-in fast inputs and fast outputs make it suitable for applications involving positioning, counting, and motion-related control functions.
Simplified Engineering Experience
Through EcoStruxure Machine Expert programming software, users can configure, program, and maintain automation systems more efficiently. Ready-to-use function blocks and intuitive programming tools help shorten development cycles.
Expandable Automation Platform
The TM241C40T supports system expansion through Schneider Electric Modicon TM3 and TM4 expansion solutions, allowing machines to grow with future production requirements.
Technical FAQs
1. What type of controller is Schneider TM241C40T?
The TM241C40T is a Modicon M241 logic controller designed for industrial machine automation and embedded control applications.
2. How many digital inputs and outputs does TM241C40T provide?
The controller includes 24 digital inputs and 16 transistor outputs, with dedicated fast input and fast output channels for high-speed applications.
3. Which programming software is used for TM241C40T?
The TM241C40T is programmed and configured using Schneider Electric EcoStruxure Machine Expert software.
4. Does TM241C40T support communication functions?
Yes. The controller provides serial communication capabilities and a USB mini-B programming interface for configuration and maintenance.
5. Can TM241C40T be expanded with additional modules?
Yes. The M241 platform supports expansion modules to increase system I/O capability and functional flexibility.
6. What type of outputs are integrated into TM241C40T?
The controller uses transistor outputs with positive logic (source type), suitable for fast switching and industrial control applications.
7. Does TM241C40T support motion-related applications?
Yes. Its fast inputs and outputs allow integration into applications requiring pulse counting, positioning control, and synchronized machine operations.
8. What communication protocol is available through the serial interfaces?
The controller supports serial communication functions including Modbus master/slave communication.
9. Is TM241C40T suitable for OEM machine development?
Yes. It is widely suitable for OEM applications requiring compact design, flexible programming, and reliable machine control.
10. How does TM241C40T improve automation system maintenance?
Integrated diagnostics, status indicators, memory functions, and software-based configuration help engineers troubleshoot and maintain systems more efficiently.
