Introduction

The Schneider TM241CE24R CPU Module is a Modicon M241 logic controller developed for modern machine automation systems that require reliable processing, Ethernet communication, and flexible control capabilities. Designed for OEM builders and industrial integrators, it combines compact PLC functionality with advanced connectivity features to support efficient automation development.

Featuring integrated I/O management, relay output capability, fast signal handling, and compatibility with EcoStruxure Machine Expert, the TM241CE24R provides a practical solution for machines that require dependable operation and simplified engineering.

Its combination of communication capability, scalability, and industrial reliability makes it a strong choice for manufacturers looking to build efficient and connected automation systems.

Technical Specifications

Parameter	Details
Model Number	TM241CE24R
Product Series	Modicon M241
Module Type	CPU Module / Logic Controller
Rated Supply Voltage	100...240 V AC
Integrated I/O	24 I/O points
Digital Inputs	14 inputs including 8 fast inputs
Digital Outputs	6 relay outputs + 4 transistor outputs
Output Type	Relay / Transistor
Fast Output Function	Supported
Ethernet Interface	Integrated Ethernet port
Serial Communication	Supported
Programming Software	EcoStruxure Machine Expert
Expansion Capability	TM3 expansion modules
Mounting Type	DIN Rail Mounting
Protection Rating	IP20
Operating Temperature	-10°C to +50°C
Dimensions (W × H × D)	150 × 90 × 95 mm
Weight	Approx. 0.53 kg

Recommended Companion Models

Model	Product Name
TM241C24R	Modicon M241 24 I/O Relay Logic Controller
TM241CE40R	Modicon M241 40 I/O Relay Ethernet Logic Controller
TM241CEC24R	Modicon M241 24 I/O Relay Ethernet CANopen Logic Controller
TM251MESE	Modicon M251 Ethernet Logic Controller

Frequently Selected Alternatives

Model	Product Name
TM221CE24R	Modicon M221 Ethernet Relay Logic Controller
TM241CE24T	Modicon M241 24 I/O Transistor Ethernet Logic Controller
TM262L10MESE8T	Modicon M262 Motion Logic Controller
BMXP342020	Modicon M340 Processor Module

Where It Excels in Industrial Use

• Compact Machine Automation Systems
The Schneider TM241CE24R CPU Module is designed for compact industrial machines requiring reliable logic control, Ethernet connectivity, and flexible I/O management. It is suitable for packaging equipment, assembly systems, conveyor applications, and automated production units.

• Connected OEM Equipment Development
With integrated Ethernet communication, the TM241CE24R provides an efficient control solution for OEM manufacturers developing connected machines that require simplified integration, remote access, and improved system management.

• Manufacturing Line Control Applications
The controller supports stable machine operation in production environments where dependable relay outputs, fast signal processing, and scalable automation architecture are required.

• Industrial Communication-Based Automation
The TM241CE24R is suitable for automation systems that require Ethernet-based connectivity, serial communication, and integration with modern industrial control networks.

Key Strengths at a Glance

• Integrated Ethernet Communication
The TM241CE24R combines PLC control functions with Ethernet connectivity, enabling efficient machine communication, programming access, and system integration.

• Balanced I/O Performance
With 24 integrated I/O points, including relay outputs and transistor fast outputs, the controller provides flexible control options for various machine automation requirements.

• Reliable Relay Output Control
The relay output configuration allows the TM241CE24R to handle a wide range of industrial devices while maintaining dependable switching performance.

• Scalable Automation Architecture
The controller supports expansion modules, allowing engineers to extend system functionality and adapt automation solutions for future production needs.

Technical FAQs

1. What type of controller is the Schneider TM241CE24R CPU Module?

The Schneider TM241CE24R is a Modicon M241 logic controller designed for industrial machine automation applications with Ethernet communication capability.

2. What communication interfaces are available on the TM241CE24R?

The TM241CE24R provides Ethernet connectivity along with serial communication interfaces and a USB programming port for engineering and maintenance operations.

3. How many I/O channels does the TM241CE24R provide?

The TM241CE24R provides 24 integrated I/O channels, including digital inputs, relay outputs, and transistor fast outputs.

4. Which software is used to program the TM241CE24R?

The TM241CE24R is programmed and configured using Schneider Electric EcoStruxure Machine Expert software.

5. Does the TM241CE24R support expansion modules?

Yes. The TM241CE24R supports Modicon TM3 expansion modules, allowing additional I/O and functional extensions.

6. What type of outputs are included in the TM241CE24R?

The TM241CE24R includes relay outputs and transistor outputs, providing flexible options for different industrial control loads.

7. Can the TM241CE24R be used for high-speed applications?

Yes. The controller includes fast inputs and fast transistor outputs suitable for pulse processing, counting functions, and responsive machine control tasks.

8. Is Ethernet communication important for TM241CE24R applications?

Yes. Ethernet connectivity improves machine integration, programming efficiency, and communication between automation devices.

9. Is the TM241CE24R suitable for OEM machine builders?

Yes. Its compact design, flexible programming environment, and expandable architecture make it suitable for OEM automation projects.

10. What advantages does TM241CE24R provide in industrial automation systems?

The TM241CE24R provides reliable control performance, communication flexibility, and scalable expansion options for modern automation applications.
