Introduction

The Schneider TM241CE24U CPU Module is part of the Modicon M241 series, providing a compact and efficient control solution for industrial machine automation. Designed for OEM builders and system integrators, it combines reliable logic processing, Ethernet communication, transistor output technology, and flexible expansion options in a single controller platform.

With support for EcoStruxure Machine Expert and scalable automation architecture, the TM241CE24U helps engineers develop connected machines with improved efficiency, simplified commissioning, and easier lifecycle management.

Its combination of communication capability, fast response performance, and modular expansion makes it a practical choice for manufacturers seeking dependable automation control.

Technical Specifications

Parameter	Details
Model Number	TM241CE24U
Product Series	Modicon M241
Module Type	CPU Module / Logic Controller
Rated Supply Voltage	24 V DC
Integrated I/O	24 I/O points
Digital Inputs	14 inputs
Fast Inputs	8 fast inputs
Digital Outputs	10 transistor outputs
Fast Outputs	4 fast outputs
Output Type	NPN Transistor
Output Voltage	24 V DC
Ethernet Interface	Integrated Ethernet port
Serial Communication	Supported
Programming Software	EcoStruxure Machine Expert
Expansion Capability	TM3 expansion modules
Mounting Type	DIN Rail Mounting
Protection Rating	IP20
Operating Temperature	-10°C to +50°C
Dimensions (W × H × D)	150 × 90 × 95 mm
Weight	Approx. 0.54 kg

Recommended Companion Models

Model	Product Name
TM241C24U	Modicon M241 24 I/O Transistor Logic Controller
TM241CE40U	Modicon M241 40 I/O Transistor Ethernet Logic Controller
TM241CE24T	Modicon M241 24 I/O Transistor PNP Ethernet Logic Controller
TM251MESE	Modicon M251 Ethernet Logic Controller

Frequently Selected Alternatives

Model	Product Name
TM221CE24U	Modicon M221 Ethernet Transistor Logic Controller
TM241CE24R	Modicon M241 24 I/O Relay Ethernet Logic Controller
TM262L10MESE8T	Modicon M262 Motion Logic Controller
BMXP342020	Modicon M340 Processor Module

Where It Excels in Industrial Use

• Ethernet-Connected Machine Automation
The Schneider TM241CE24U CPU Module is designed for modern automation systems requiring reliable control performance, Ethernet communication, and efficient machine integration. It is suitable for packaging equipment, assembly machines, conveyor systems, and compact manufacturing solutions.

• OEM Machine Development Platforms
The TM241CE24U provides a flexible controller solution for OEM manufacturers developing customized machines. Its scalable architecture helps engineers create efficient automation systems with simplified programming and future expansion capability.

• High-Speed Industrial Control Applications
With transistor outputs and fast I/O functions, the controller supports applications requiring rapid signal processing, pulse control, and accurate machine synchronization.

• Integrated Production Automation Systems
The TM241CE24U is suitable for industrial environments where stable PLC operation, Ethernet connectivity, and flexible communication between automation devices are required.

Key Strengths at a Glance

• Integrated Ethernet Communication
The TM241CE24U combines logic control with Ethernet connectivity, enabling efficient machine networking, programming access, and easier system maintenance.

• Fast Transistor Output Performance
The transistor output design provides rapid switching capability, making the controller suitable for applications involving high-speed control signals and dynamic machine operations.

• Flexible I/O Management
With 24 integrated I/O points, including digital inputs and transistor outputs, the TM241CE24U provides a balanced solution for compact automation systems.

• Expandable Automation Architecture
Support for Modicon TM3 expansion modules allows users to increase system capacity and adapt automation solutions to changing production requirements.

Technical FAQs

1. What type of controller is the Schneider TM241CE24U CPU Module?

The Schneider TM241CE24U is a Modicon M241 logic controller designed for machine automation applications with Ethernet communication and transistor output control.

2. Which programming software is compatible with the TM241CE24U?

The TM241CE24U is programmed and configured using EcoStruxure Machine Expert software for industrial automation development.

3. How many I/O points are available on the TM241CE24U?

The TM241CE24U provides 24 integrated I/O points, including 14 digital inputs and 10 transistor outputs.

4. Does the TM241CE24U support high-speed signal processing?

Yes. The controller includes fast inputs and fast outputs designed for pulse processing, counting functions, and responsive machine control applications.

5. What type of output technology does the TM241CE24U use?

The TM241CE24U uses NPN transistor outputs with 24 V DC output technology for fast and reliable industrial switching operations.

6. Does the TM241CE24U support Ethernet communication?

Yes. The TM241CE24U includes an integrated Ethernet interface for machine communication, programming, and industrial network integration.

7. Can the TM241CE24U be expanded with additional modules?

Yes. The controller supports Modicon TM3 expansion modules to increase I/O capacity and extend automation functionality.

8. Is the TM241CE24U suitable for motion-related applications?

Yes. The fast I/O capability allows the controller to support basic positioning, pulse output, and synchronized machine control tasks.

9. What communication functions are supported by the TM241CE24U?

The TM241CE24U supports Ethernet communication and serial communication functions for integration with industrial automation systems.

10. Why is the TM241CE24U suitable for OEM automation projects?

The TM241CE24U combines compact PLC design, Ethernet connectivity, flexible programming, and expansion capability, making it suitable for customized machine automation solutions.
