Brand:Schneider PLC Item No.:TSXDSZ08T2 Product Origin:France Product Dimensions:260 x 180 x 57 mm Product Weight:0.329 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Schneider TSXDSZ08T2 Discrete Output Module is designed to provide reliable digital signal output for industrial automation systems based on the Modicon TSX Micro PLC platform. It serves as an important connection point between PLC control programs and physical equipment in the field.
In modern industrial environments, automation systems depend on accurate output control to operate machines, valves, actuators, and other devices. A high-quality output module ensures that PLC commands are executed correctly, improving production efficiency and reducing system interruptions.
The TSXDSZ08T2 uses transistor output technology to provide stable switching performance for industrial applications. Its compact structure allows efficient integration into control cabinets while maintaining reliable operation.
For automation engineers, machine builders, and maintenance teams, the Schneider TSXDSZ08T2 provides a practical solution for PLC output expansion, system upgrades, and industrial equipment control.
Technical Specifications
Specification
Details
Product Type
Discrete Output Module
Manufacturer
Schneider Electric
Model Number
TSXDSZ08T2
Product Series
Modicon TSX Micro
Output Type
Solid-State Transistor Output
Number of Outputs
8 Outputs
Output Voltage
24 V DC
Output Logic
Positive Logic
Output Current
0.5 A
Application
Industrial Digital Output Control
Protection Function
Overload and Short-Circuit Protection
Connection Type
Screw Terminal Connection
Installation Method
PLC Rack Mounting
Dimensions
260 × 180 × 57 mm
Weight
0.33 kg (0.73 lb)
Recommended Related Models
Model
Product Type
Schneider TSXDSZ08R5
Relay Discrete Output Module
Schneider TSXDSY08T2
Discrete Output Module
Schneider TSXDSY08T22
Discrete Output Module
Schneider TSXDSY32T2K
Discrete Output Module
Schneider TSXDMZ28DT
Discrete Mixed I/O Module
Popular Related Models
Model
Product Type
Schneider TM221CE24R
Modicon M221 Logic Controller
Schneider TM241CE24R
Modicon M241 Logic Controller
Schneider BMXDDO1602
Modicon X80 Discrete Output Module
Schneider BMXP342020
Modicon M340 Processor Module
Schneider BMEP582040
Modicon M580 Processor Module
Industrial Applications and Usage Areas
The Schneider TSXDSZ08T2 Discrete Output Module is a reliable digital output expansion module designed for Modicon TSX Micro PLC automation systems. It provides stable output control between the PLC controller and connected field devices, allowing industrial equipment to execute programmed automation commands accurately.
The TSXDSZ08T2 is designed for applications requiring dependable 24 V DC discrete output control. Its solid-state switching technology provides fast response performance and long operational durability, making it suitable for industrial systems where frequent switching operations and stable control signals are required.
This module is widely used by automation engineers, system integrators, and maintenance professionals who need to expand PLC output capability while maintaining efficient system performance and reliable machine operation.
Typical application areas include:
Industrial machine automation
Packaging and assembly equipment
Conveyor control systems
Production line automation
Material handling equipment
Process control systems
OEM customized machinery
Factory automation projects
Industrial electrical cabinets
The Schneider TSXDSZ08T2 provides a dependable connection between PLC logic programs and external devices, helping improve automation efficiency, production stability, and equipment control accuracy.
Reliable Output Control Advantages and Application Benefits
The Schneider TSXDSZ08T2 Discrete Output Module combines solid-state output technology with industrial reliability. It is designed for automation applications that require fast switching response, stable performance, and long service life.
Advantage
Description
Solid-State Output Design
Provides reliable electronic switching performance with fast response.
8 Output Channels
Supports multiple field devices within a compact PLC system.
24 V DC Control Capability
Suitable for common industrial automation applications.
Stable Switching Performance
Ensures accurate execution of PLC control commands.
Compact Installation Structure
Helps optimize control cabinet space utilization.
Industrial Reliability
Designed for continuous operation in automation environments.
Technical FAQs
Q1: What is the main function of the Schneider TSXDSZ08T2 module? A: The TSXDSZ08T2 is a PLC output module that converts digital control commands from the PLC program into electrical signals for operating external industrial devices.
Q2: How many output channels does the TSXDSZ08T2 provide? A: The module provides 8 discrete output channels for controlling connected automation equipment.
Q3: What type of output technology is used in the TSXDSZ08T2? A: The module uses solid-state transistor output technology, which provides fast switching performance and improved durability.
Q4: What devices can be controlled by the TSXDSZ08T2? A: It can control compatible industrial devices such as solenoid valves, relays, contactors, indicators, and actuators.
Q5: What should be checked if an output channel does not work? A: Check PLC program logic, module status, wiring connections, field device condition, and external power supply.
Q6: What are common reasons for output faults? A: Common causes include incorrect wiring, excessive load current, short circuits, damaged connected devices, or incorrect system configuration.
Q7: Is the TSXDSZ08T2 suitable for frequent switching applications? A: Yes. The solid-state output design supports frequent switching operations commonly required in industrial automation systems.
Q8: How can users improve the reliability of the TSXDSZ08T2? A: Proper installation, correct load selection, stable power supply, and regular inspection can improve long-term operating reliability.
Q9: How does the TSXDSZ08T2 communicate with the PLC controller? A: The module exchanges control information with the PLC processor through the internal Modicon TSX Micro rack system.
Q10: Why is the TSXDSZ08T2 suitable for industrial automation projects? A: Its compact design, reliable digital output performance, and compatibility with Schneider PLC systems make it suitable for various automation applications.
