The ABB GCU-02 (Generator Control Unit) is a sophisticated and highly reliable solution designed for the monitoring, control, and protection of generator systems in a variety of industrial applications. This module integrates seamlessly into ABB's automation systems, providing critical functionality for safe and efficient generator operation. Whether in power generation, oil & gas, or any other industry requiring reliable power generation and control, the GCU-02 ensures maximum performance and operational safety.

With its advanced control algorithms and intuitive interface, the GCU-02 allows for easy integration and operation, offering precise control over the generator’s performance, speed, voltage, and frequency. Additionally, the unit includes protective features that prevent damage due to faults, ensuring that the generator operates within safe parameters.

Technical Specifications

Feature	Description
Model Name	GCU-02
Type	Generator Control Unit
Input Voltage Range	24 VDC ±20%
Power Consumption	2.0 A (Max)
Dimensions (W x H x D)	250 mm x 180 mm x 120 mm
Weight	1.5 kg
Operating Temperature	-20°C to +70°C
Storage Temperature	-40°C to +85°C
Communication Ports	1 x Ethernet, 2 x RS-232/RS-485
Communication Protocols	Modbus RTU, Modbus TCP/IP
Control Functionality	Speed control, voltage regulation, fault detection, synchronization
Protection Features	Overload, underload, overvoltage, undervoltage, short circuit protection
Certification	CE, UL, CSA
