Brand:Schneider PLC Item No.:TWDDRA8RT Product Origin:France Product Dimensions:23.5 x 90 x 70 mm Product Weight:0.11 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Schneider TWDDRA8RT Discrete Output Module is a practical expansion component designed for Twido PLC automation platforms. It increases system output capacity while maintaining the reliability and simplicity required for industrial control applications.
The module uses relay output technology to provide flexible switching performance for various industrial devices. This makes it suitable for automation systems that require reliable control of actuators, motors, valves, indicators, and other field equipment.
For machine builders and industrial users maintaining Twido-based systems, the TWDDRA8RT offers an efficient way to expand automation functions without redesigning the complete control architecture. Its compact structure, stable operation, and easy integration make it a valuable component for industrial PLC applications.
Technical Specifications and Product Data
Parameter
Specification
Manufacturer
Schneider Electric
Model Number
TWDDRA8RT
Product Type
Discrete Output Module
Automation Platform
Twido
Output Type
Relay Output
Number of Outputs
8 relay outputs
Output Contact Type
Normally Open (NO)
Switching Application
Industrial AC/DC load control
Connection Type
Screw terminal connection
Installation Type
PLC expansion mounting
Application
Digital output expansion
Dimensions
23.5 × 90 × 70 mm
Weight
0.11 kg (0.24 lb)
Recommended Related Models for Twido PLC Expansion
Model
Product Type
TWDDRA8RT
Twido Relay Output Module
TWDDRA16RT
Twido Relay Output Expansion Module
TWDLMDA20DTK
Twido Compact Controller
TWDLMDA40DTK
Twido Compact Controller
TWDLCAA24DRF
Twido Compact Base Controller
Popular Related Models and Alternative Solutions
Model
Product Type
TM3DQ8R
Modicon TM3 Relay Output Module
TM3DQ16R
Modicon TM3 Relay Output Module
TM221C24R
Modicon M221 Logic Controller
TM241C24R
Modicon M241 Logic Controller
TM251MESE
Modicon M251 Logic Controller
Industrial Applications and Output Control Expansion
The Schneider TWDDRA8RT Discrete Output Module is a relay output expansion module designed for Twido PLC automation systems. It provides additional output channels for industrial controllers, enabling machines and automation equipment to control external devices with greater flexibility and reliability.
The TWDDRA8RT is designed for applications where additional digital output capacity is required, including:
Packaging machinery
Assembly line automation
Conveyor control systems
Valve and actuator control
Industrial equipment panels
Small production systems
OEM machine solutions
With its compact design, reliable relay switching capability, and seamless integration with Twido controllers, the TWDDRA8RT helps improve system flexibility while reducing the need for major PLC hardware changes.
Engineering Advantages and Performance Benefits
The Schneider TWDDRA8RT Discrete Output Module provides dependable output expansion performance for compact industrial automation systems.
Flexible Relay Switching Capability
The module provides 8 relay output channels, allowing connection with different types of industrial loads such as contactors, indicators, solenoid valves, and control devices.
Efficient PLC Expansion Solution
The TWDDRA8RT allows Twido PLC systems to increase output capacity without replacing the existing controller, making it suitable for system upgrades and machine expansion.
Reliable Electrical Isolation
Relay output technology provides effective electrical separation between PLC control signals and external field devices, improving system stability.
Simplified Installation and Maintenance
The compact module structure and practical terminal connection design make wiring, replacement, and troubleshooting more convenient for engineers.
Space-Saving Industrial Design
The module occupies minimal cabinet space, making it suitable for compact control panels and machine automation applications.
