Brand:Schneider PLC Item No.:TWDLMDA40DUK Product Origin:France Product Dimensions:202 × 21 × 261 mm Product Weight:0.30 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Schneider TWDLMDA40DUK Modular Base Controller is a high-performance PLC developed for industrial automation systems requiring extensive digital I/O, flexible expansion, and dependable machine control. Integrating 24 digital inputs, 16 high-speed transistor sink outputs, and a powerful CPU within one compact platform, it delivers an efficient solution for OEM equipment manufacturers and industrial system integrators.
Designed around the proven Twido architecture, the TWDLMDA40DUK combines reliable operation with modular scalability, integrated communication interfaces, and straightforward programming. Whether used for new control panels or maintaining established Twido installations, it offers dependable performance for a broad range of industrial automation applications.
Technical Specifications
Specification
Details
Manufacturer
Schneider Electric
Model
TWDLMDA40DUK
Product Family
Twido
Module Type
Modular Base Controller
PLC Type
Modular PLC
Supply Voltage
24 VDC
Digital Inputs
24 × 24 VDC
Digital Outputs
16 × NPN Transistor (Sink)
Total Digital I/O
40 Points
Output Current
0.3 A per output
Output Type
High-Speed Transistor
Expansion Capacity
Up to 7 Twido Expansion Modules
Communication Ports
RS232, RS485
Communication Protocol
Modbus RTU / ASCII
Memory Expansion
Optional Memory Cartridge
RTC Support
Yes
Programming Software
TwidoSuite
Mounting Type
DIN Rail
Protection Rating
IP20
Operating Temperature
0…55°C
Dimensions
90 × 47.5 × 70 mm
Weight
Approx. 0.18 kg
Recommended Companion Models
Model
Product Name
Schneider TWDDDI32DK
Digital Input Module
Schneider TWDDDO16TK
Digital Output Module
Schneider TWDNOZ485T
RS485 Serial Interface Module
Schneider TWDXCPMFK32
Memory Cartridge
Frequently Selected Alternatives
Model
Product Name
Schneider TWDLMDA40DTK
Modular Base Controller
Schneider TWDLMDA20DUK
Modular Base Controller
Schneider TM221M32TK
Modicon M221 Logic Controller
Schneider TM241C40U
Modicon M241 Logic Controller
Where It Excels in Industrial Use
• Advanced Machine Automation
The Schneider TWDLMDA40DUK is a Twido modular base controller engineered for medium-sized automation systems requiring integrated control, flexible expansion, and high-density digital I/O. With 24 digital inputs and 16 transistor sink outputs, it is well suited for demanding industrial machinery and OEM equipment.
• Packaging, Conveying, and Material Handling
Its fast transistor outputs and extensive onboard I/O enable reliable control of conveyors, sortation systems, packaging machinery, and automated production lines where rapid switching and accurate sequencing are essential.
• Scalable Industrial Control Systems
Supporting multiple Twido expansion modules, the controller allows engineers to increase I/O capacity as automation requirements grow while maintaining a compact PLC architecture.
• Legacy Twido System Upgrades
The TWDLMDA40DUK remains an excellent replacement solution for maintaining and modernizing existing Twido installations, helping extend equipment service life without redesigning complete control systems.
Key Strengths at a Glance
• Integrated 40-Point Digital I/O
Combines a powerful PLC CPU with 24 digital inputs and 16 transistor sink outputs, minimizing external hardware while simplifying installation and maintenance.
• High-Speed NPN Transistor Outputs
Sixteen sink transistor outputs provide rapid switching performance for applications involving positioning, indexing, high-speed counting, and machine sequencing.
• Expandable Modular Design
Supports up to seven Twido expansion modules, allowing the controller to adapt to evolving automation requirements without replacing the CPU.
• Integrated Industrial Communications
Equipped with built-in RS232 and RS485 serial communication ports supporting Modbus protocols for programming, diagnostics, and industrial networking.
Technical FAQs
1. What type of controller is the Schneider TWDLMDA40DUK?
The TWDLMDA40DUK is a Twido modular base PLC controller with an integrated processor, digital inputs, and transistor sink outputs.
2. How many onboard digital I/O points are available?
The controller provides 24 digital inputs and 16 transistor outputs, totaling 40 onboard digital I/O points.
3. What power supply does the controller require?
It operates from a nominal 24 VDC power supply designed for industrial control cabinets.
4. What output technology is used?
The controller features NPN transistor (sink) outputs designed for high-speed DC load switching.
5. How many expansion modules can be connected?
The TWDLMDA40DUK supports up to seven compatible Twido expansion modules, providing significant system scalability.
6. Which programming software is compatible with this controller?
The controller is programmed using Schneider Electric TwidoSuite software.
7. What communication interfaces are included?
Integrated RS232 and RS485 serial ports support Modbus communication, controller programming, and diagnostics.
8. Does the controller support optional memory expansion?
Yes. Optional memory cartridges and real-time clock cartridges can be installed to expand storage and system functionality.
9. What industries commonly use the TWDLMDA40DUK?
Typical applications include packaging, material handling, food processing, assembly automation, textile machinery, and general factory automation.
10. Is the TWDLMDA40DUK still supported for maintenance projects?
Although discontinued, the controller continues to be widely used in legacy Twido installations for maintenance and replacement purposes.
