Product Introduction

The Schneider VW3M4112 Connector Module is a professional servo connection accessory developed for Lexium 23 Plus motion control systems. It provides a dependable CN1 interface connection solution that helps engineers integrate servo drives into advanced automation architectures.

With its dedicated design, compact structure, and reliable connection performance, the VW3M4112 supports efficient machine commissioning and simplified control panel design. It is an ideal accessory for automation professionals who require stable servo signal connections and long-term operational reliability.

For OEM manufacturers and system integrators, this connector helps create cleaner, more maintainable, and highly efficient motion control installations.

Technical Specifications

Specification	Details
Manufacturer	Schneider Electric
Model	VW3M4112
Product Type	Connector Module
Accessory Category	Servo Drive Connection Accessory
Main Function	CN1 Interface I/O Connector
Product Range	Lexium
Compatible Range	Lexium 23 Plus
Connector Application	Servo Drive I/O Interface
Connection Type	CN1 Connector
Installation Type	Servo Control Panel / Automation System
Application	Motion Control Signal Connection
Dimensions	Approx. 80 × 80 × 20 mm (package size)
Product Weight	Approx. 0.03 kg

Recommended Related Models

Model	Product
Schneider VW3M4113	Lexium 23 Plus Connection Accessory
Schneider LXM23AU04M3X	Lexium 23 Plus Servo Drive
Schneider LXM23AU07M3X	Lexium 23 Plus Servo Drive
Schneider BCH Series	Servo Motor
Schneider VW3M2208	Encoder Connector Accessory

Popular Related Models

Model	Product Type
Schneider VW3M4112	Lexium CN1 I/O Connector
Schneider LXM23 Plus Series	Servo Drive Platform
Schneider BCH Servo Motor Series	Servo Motor
Schneider VW3M2207	Servo Connection Accessory
Schneider Lexium 28 Series	Servo Motion System

Applications in Servo Motion Connection Systems

The Schneider VW3M4112 Connector Module is a dedicated CN1 interface I/O connector accessory designed for Schneider Electric Lexium 23 Plus servo drive systems. It provides a reliable connection interface for servo drive control wiring, enabling integration between motion controllers, external control equipment, and servo drive I/O systems.

The VW3M4112 is commonly used in industrial automation equipment, robotics systems, packaging machines, CNC applications, and precision motion platforms where stable servo control signal connections are required. As a dedicated Lexium accessory, it helps machine builders simplify wiring processes and maintain professional control cabinet organization.

Designed for engineers and OEM system integrators, this connector provides a practical solution for reliable CN1 interface installation while improving serviceability and overall motion system efficiency.

Key Engineering Advantages

Dedicated Lexium Interface Compatibility

The VW3M4112 is specifically designed for the Lexium 23 Plus servo drive range, providing direct compatibility with the CN1 interface and ensuring correct mechanical integration within Schneider motion systems.

Simplified Servo Wiring Installation

By using a dedicated I/O connector, engineers can reduce wiring complexity and achieve a cleaner connection between servo drives and external automation devices. This improves installation efficiency and helps minimize connection errors.

Reliable Control Signal Integration

The connector provides a stable interface for servo drive I/O signals, supporting applications that require accurate communication between motion controllers, PLC systems, and servo amplifiers.

Professional Automation System Design

The VW3M4112 helps machine builders create standardized servo control panels with improved maintenance accessibility and consistent wiring practices.

Technical FAQs

1. What is the main function of Schneider VW3M4112?

The VW3M4112 is an I/O connector accessory used for the CN1 interface of Schneider Lexium 23 Plus servo drives.

2. Which Schneider product range is compatible with VW3M4112?

The connector is designed for the Lexium 23 Plus servo drive range.

3. What type of connection does VW3M4112 provide?

The VW3M4112 provides a dedicated CN1 servo drive interface connection for external I/O wiring and control signal integration.

4. Is VW3M4112 an active electronic module?

No. The VW3M4112 is a passive connector accessory and does not contain electronic processing components or require an external power supply.

5. What is the purpose of the CN1 interface on Lexium servo drives?

The CN1 interface is used for connecting external control signals, including machine control inputs and outputs required for servo operation and automation integration.
