Applications in Servo Motor Power Systems

The Schneider VW3M5111R100 Power Cable Module is a preassembled servo motor power cable designed for connecting Schneider Electric BCH servo motors (without holding brake) to compatible Lexium 23 Plus servo drives. Featuring a factory-installed motor connector and free flying leads on the drive side, it provides a dependable power connection for industrial motion control applications. The 10-meter cable length offers flexibility for machine layouts where motors and control cabinets are installed at greater distances.

This cable is widely used in robotic systems, CNC machinery, packaging equipment, textile machines, automated production lines, electronic assembly equipment, and material handling systems. Its industrial-grade construction helps ensure stable electrical performance while simplifying installation and reducing commissioning time.

Performance Advantages

Engineered for Lexium 23 Plus Motion Systems

The VW3M5111R100 is specifically designed for Schneider Electric Lexium 23 Plus servo systems and compatible BCH servo motors without holding brake, ensuring reliable electrical compatibility and dependable operation.

Factory-Assembled Cable for Faster Installation

The cable is supplied preassembled with a motor-side connector and free flying leads, reducing installation effort, minimizing wiring errors, and improving commissioning efficiency.

Reliable Industrial Power Transmission

Constructed with 4 × 0.82 mm² conductors, the cable delivers stable power transmission for servo applications while maintaining excellent flexibility for routing inside industrial equipment.

Flexible Machine Integration

With a 10 m cable length, the VW3M5111R100 is suitable for medium- to large-sized automation equipment where servo motors are installed away from electrical control panels.

Technical FAQs

1. What is the primary function of the Schneider VW3M5111R100?

The VW3M5111R100 is a servo motor power cable used to connect BCH servo motors without holding brake to Schneider Electric Lexium 23 Plus servo drives.

2. Which Schneider servo systems are compatible with this cable?

It is designed for Lexium 23 Plus servo drives used with compatible BCH series servo motors without holding brake.

3. What conductor configuration does the cable use?

The cable features 4 × 0.82 mm² conductors, suitable for servo motor power transmission.

4. What type of connections are provided?

The cable includes:

• Factory-installed motor-side connector
• Free flying leads on the servo drive side

This design allows flexible integration into industrial control cabinets.

5. Is the VW3M5111R100 a communication cable?

No. It is a servo motor power cable and is intended only for electrical power transmission between the servo motor and servo drive.

6. Can this cable be used with motors equipped with a holding brake?

No. The VW3M5111R100 is designed specifically for BCH servo motors without a holding brake. Applications requiring brake wiring should use the appropriate dedicated cable.

7. Does the cable require software configuration?

No. As a passive electrical accessory, it requires no programming or configuration.

8. What industries commonly use this cable?

Typical applications include:

• Robotics
• Packaging machinery
• CNC machine tools
• Automated assembly
• Textile machinery
• Material handling systems

9. Why use an original Schneider Electric power cable?

Original Schneider accessories provide verified compatibility, reliable electrical performance, and simplified installation for supported motion control systems.

10. Is the VW3M5111R100 suitable for OEM machine builders?

Yes. Its preassembled design, industrial construction, and Schneider compatibility make it an excellent choice for OEM machinery and automation system integration.
