Introduction

The Bently Nevada 3500/05-02-05-00-00-01 System Rack is a robust and flexible chassis that forms the foundation of a high-performance machinery protection system. Designed to support critical monitoring modules, it delivers stable power and secure communication, enabling continuous real-time insights into shaft vibration, displacement, and temperature. Its durable construction, modular architecture, and redundancy support make it an essential component for plants seeking maximum equipment uptime and reliable protection of high-value rotating assets.

Technical Specifications

Specification	Details
Model	3500/05-02-05-00-00-01
System	Bently Nevada 3500 Machinery Protection System
Rack Type	3500/05 System Rack
Slot Layout	Supports monitoring, relay, communication, and keyphasor modules
Backplane	Integrated power and communication distribution
Power Supply	Single or dual 3500/15 modules (redundant)
Mounting	Panel-mounted industrial design
Material	Heavy-duty metal construction
Dimensions	Rack Size : 12-inch (7 module slots)
Weight	4.5 kg

Recommended Related Models

Bently Nevada 3500/15 Power Supply
Bently Nevada 3500/22M Transient Data Interface
Bently Nevada 3500/25 Keyphasor Module

Popular Related Models

Bently Nevada 3500/42M Proximitor/Seismic Monitor
Bently Nevada 3500/32 4-Channel Relay Module
Bently Nevada 3500/93 LCD Display Module

Applications

The 3500/05-02-05-00-00-01 System Rack is engineered for critical rotating equipment monitoring where reliability and modularity are paramount. It supports Bently Nevada 3500 Series modules for turbine and compressor protection, generator monitoring, and key industrial processes. Ideal for power plants, oil & gas facilities, refineries, and heavy industrial machinery, this rack ensures a stable platform for real-time vibration, temperature, and shaft position monitoring.

Advantages

Rugged industrial chassis designed for long-term durability in vibration-heavy environments
Modular slot design allows flexible system configurations and future expansion
Supports redundant power supply setups for uninterrupted operation
Facilitates clean wiring and secure backplane communication between modules
Simplifies maintenance and reduces downtime with organized module access
Compatible with a full range of 3500 Series monitoring, relay, and communication modules

Technical FAQs

What is the main purpose of this rack?
To house and provide power and communication to 3500 Series monitoring modules.
Does it support redundant power supplies?
Yes, it accommodates dual 3500/15 power supplies for fail-safe operation.
Which module types are compatible?
Monitoring, relay, communication, keyphasor, and display modules from the 3500 Series.
Does the rack come with modules pre-installed?
No, modules are supplied separately; the rack is sold as a standalone chassis.
Can it be installed in harsh industrial environments?
Yes, it is engineered for reliable operation near high-vibration and high-temperature machinery.
Is panel mounting required?
Yes, the rack is designed for secure cabinet or panel installation.
Does it support system expansion?
Yes, multiple racks can be combined for larger monitoring architectures.
Is the backplane included?
Yes, the integrated backplane handles both communication and power distribution.
Can it handle mixed module types in the same rack?
Absolutely, it is designed for full multi-module compatibility.
Are there any special cooling requirements?
No special cooling is required, though adequate enclosure ventilation is recommended.
