Brand:Schneider PLC Item No.:BMXCRA31200 Product Origin:France Product Dimensions:32 x 100 x 87.5 mm Product Weight:0.225 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
Introduction to Schneider BMXCRA31200 Remote I/O Output Adapter
The Schneider BMXCRA31200 Remote I/O Output Adapter is an industrial communication component designed to extend Modicon X80 automation systems beyond the main control cabinet. It provides the necessary interface for creating distributed I/O architectures where field devices and control modules are installed in separate locations.
By enabling remote rack communication over Ethernet RIO networks, the BMXCRA31200 helps reduce complex field wiring, improve system organization, and provide greater flexibility for large automation installations. It is particularly suitable for applications requiring centralized control with geographically distributed I/O points.
For automation engineers, system integrators, and maintenance teams, the BMXCRA31200 offers a reliable solution for expanding Schneider Electric control systems while maintaining efficient communication and stable industrial performance.
Technical Specifications
Parameter
Specification
Manufacturer
Schneider Electric
Model Number
BMXCRA31200
Product Type
Remote I/O Output Adapter
Series
Modicon X80
Application
Ethernet Remote I/O Drop Adapter
Compatible Platform
Modicon M580 / Modicon X80
Network Type
Ethernet RIO
Ethernet Ports
2 RJ45 Ports
Communication Speed
10/100 Mbps
Protocol Support
EtherNet/IP, Modbus TCP Diagnostics
Backplane Communication
X-Bus
Supported I/O Capacity
Up to 128 Discrete Channels / 16 Analog Channels
Network Topology
Ring Topology Supported
Diagnostic Functions
Remote I/O Device Diagnostics
Status Indicators
RUN, ERR, Network Status LEDs
Input Voltage
3.3 V DC
Current Consumption
1200 mA
Dimensions
32 × 100 × 87.5 mm
Weight
0.23 kg (0.50 lb)
Recommended Related Models
Model
Product Type
Schneider BMXCRA31210
Performance Remote I/O Adapter
Schneider BMECRA31210
X80 Remote I/O Adapter
Schneider BMENOC0311
Ethernet Communication Module
Schneider BMEP586040
Modicon M580 Independent Processor
Schneider BMEXBP0800
Ethernet Backplane
Popular Related Models
Model
Application Category
Schneider BMXDDI3203
Discrete Input Module
Schneider BMXDDO3202
Discrete Output Module
Schneider BMXAMI0810
Analog Input Module
Schneider BMXP3420302
Modicon M340 Processor Module
Schneider BMENUA0100
OPC UA Communication Module
Applications and Distributed Automation Communication
The Schneider BMXCRA31200 Remote I/O Output Adapter is a dedicated remote I/O communication module designed for the Modicon X80 automation platform, providing a reliable connection between distributed I/O racks and Schneider Electric control systems. This adapter acts as the communication interface for remote I/O drops, allowing field-level modules to exchange data efficiently with centralized PLC controllers in industrial automation networks.
The BMXCRA31200 is widely used in manufacturing plants, process industries, energy systems, water treatment facilities, and infrastructure automation projects where remote signal management and distributed control architectures are required. It supports Ethernet RIO networks and enables connection of Modicon X80 discrete and analog I/O modules in remote locations, reducing long-distance wiring requirements and improving system flexibility.
Designed for Modicon M580-based architectures, this remote I/O adapter provides engineers with a practical solution for expanding automation systems, organizing distributed control cabinets, and improving communication reliability between field devices and the main controller.
System Integration Advantages and Remote Control Benefits
Reliable Ethernet RIO Communication
The BMXCRA31200 provides Ethernet Remote I/O connectivity through an industrial network interface, allowing distributed I/O stations to communicate efficiently with the main automation controller. This architecture helps simplify large-scale automation projects by placing I/O modules closer to field equipment.
Flexible Distributed I/O Expansion
Supporting Modicon X80 discrete and analog I/O modules, this adapter allows engineers to create remote I/O drops according to application requirements while reducing control cabinet wiring complexity.
Modicon M580 Platform Compatibility
The BMXCRA31200 is designed for Schneider Electric Modicon M580 automation systems and provides a dependable interface for expanding existing PAC architectures with remote I/O capability.
Stable Industrial Network Performance
With Ethernet communication support, RSTP network capability, and diagnostic functions, the adapter helps maintain reliable data transmission in industrial environments where continuous operation is essential.
Compact Remote Rack Design
The compact module structure allows efficient installation in distributed control cabinets while maintaining compatibility with standard Modicon X80 rack configurations.
Technical FAQs About Schneider BMXCRA31200 Remote I/O Output Adapter
1. What is the Schneider BMXCRA31200 used for?
The BMXCRA31200 is a remote I/O drop adapter used to connect Modicon X80 remote racks to Ethernet RIO networks.
2. Which Schneider PLC platforms support the BMXCRA31200?
The module is mainly designed for Modicon M580 automation systems and is compatible with Modicon X80 architectures.
3. What communication network does the BMXCRA31200 use?
The adapter communicates through Ethernet RIO networks using industrial Ethernet protocols.
4. What types of modules can be installed on a BMXCRA31200 remote rack?
It supports compatible Modicon X80 discrete and analog I/O modules.
5. How many BMXCRA31200 modules can be installed in one remote I/O drop?
One BMXCRA31200 adapter is installed per Modicon X80 remote I/O drop.
6. How can Ethernet communication faults be diagnosed?
Technicians should check network cables, Ethernet port indicators, IP settings, rack configuration, and PLC diagnostic messages.
7. What causes a remote I/O station to lose communication?
Possible causes include network cable problems, incorrect addressing, power interruptions, configuration errors, or communication parameter mismatches.
8. Can the BMXCRA31200 support remote analog modules?
Yes. Compatible Modicon X80 analog I/O modules can be installed in the remote rack.
9. How is the BMXCRA31200 configured in a control project?
The module is configured through Schneider Electric engineering software as part of the Modicon M580 hardware architecture.
10. What maintenance practices improve remote I/O reliability?
Regular inspection of Ethernet connections, power supply stability, module status indicators, and configuration backups helps maintain reliable operation
