Brand:Schneider PLC Item No.:BMXAMI0810H Product Origin:France Product Dimensions:116 x 110 x 55 mm Product Weight:0.175 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
Introduction to Schneider BMXAMI0810H Analog Input Module
The Schneider BMXAMI0810H Analog Input Module is a professional industrial measurement solution designed for applications requiring accurate analog data acquisition and reliable operation in challenging environments. As part of the Modicon X80 I/O family, it provides a direct interface between field instrumentation and PLC control systems.
The module is especially suitable for process industries where continuous monitoring of temperature, pressure, flow, level, and other analog variables is required. Its isolated inputs, configurable signal ranges, and hardened design allow engineers to develop flexible automation systems capable of operating under demanding industrial conditions.
For system integrators, OEM manufacturers, and industrial maintenance teams, the BMXAMI0810H provides a reliable method for expanding analog input capacity while improving measurement accuracy and long-term system performance.
Technical Specifications
Parameter
Specification
Manufacturer
Schneider Electric
Model Number
BMXAMI0810H
Product Type
Analog Input Module
Series
Modicon X80
Module Version
Hardened / Severe Environment Version
Number of Analog Inputs
8 Channels
Input Type
Isolated High-Level Analog Input
Supported Signals
0–20 mA, 4–20 mA, ±20 mA, 0–10 V, ±10 V
Analog Resolution
16-bit Conversion
Input Isolation
Channel Isolation / Bus Isolation
Input Impedance
10 MΩ
Digital Filtering
First Order Digital Filtering
Fast Acquisition Time
1 ms + 1 ms × Number of Channels Used
Standard Acquisition Time
9 ms for 8 Channels
Overload Protection
Voltage and Current Input Protection
Operating Temperature
-25 to 70 °C
Protection Treatment
Conformal Coating
Compatible Platform
Modicon M340 / Modicon M580 / Modicon X80
Connection Type
28-Way Connector
Dimensions
116 × 110 × 55 mm
Weight
0.18 kg (0.39 lb)
Recommended Related Models
Model
Product Type
Schneider BMXAMI0810
Analog Input Module
Schneider BMXAMO0410
Analog Output Module
Schneider BMXART0414
Temperature Input Module
Schneider BMEP586040
Modicon M580 Independent Processor
Schneider BMEXBP0800
8-Slot Ethernet Backplane
Popular Related Models
Model
Application Category
Schneider BMXDDI3203
Discrete Input Module
Schneider BMXDDO3202
Discrete Output Module
Schneider BMXCRA31200
Remote I/O Adapter Module
Schneider BMENOP0300
Communication Module
Schneider BMXCPS3522
Redundant Power Supply Module
Applications and High-Precision Analog Signal Acquisition
The Schneider BMXAMI0810H Analog Input Module is a hardened high-performance analog input module designed for the Modicon X80 automation platform, providing accurate measurement and monitoring of industrial analog signals in demanding environments. This module is developed for applications requiring reliable data acquisition from field sensors, transmitters, and process instrumentation where signal accuracy and system stability are essential.
The BMXAMI0810H is widely applied in process automation, chemical plants, power generation, water treatment, manufacturing systems, and infrastructure control applications. Featuring 8 isolated analog input channels, the module supports voltage and current measurement ranges, including 0–20 mA, 4–20 mA, ±20 mA, 0–10 V, and ±10 V signals, allowing flexible integration with different industrial sensors and transmitters.
Designed as the ruggedized version of the standard BMXAMI0810, the BMXAMI0810H includes enhanced environmental resistance and conformal coating protection, making it suitable for harsh industrial locations with extended temperature requirements. It provides engineers with a dependable solution for continuous monitoring, closed-loop control, and advanced process management.
Performance Advantages and Industrial Integration Features
Hardened Design for Harsh Industrial Conditions
The BMXAMI0810H is built for severe environments, offering enhanced resistance against temperature variations and industrial conditions. Its ruggedized construction makes it suitable for outdoor cabinets, chemical environments, and demanding automation installations.
Eight-Channel Isolated Analog Measurement
With eight isolated analog input channels, the module allows multiple field instruments to be connected within a compact PLC configuration. The isolated design helps improve measurement reliability by reducing interference between channels and the control system.
Flexible Voltage and Current Input Support
The module supports multiple configurable signal ranges, allowing users to connect various industrial transmitters without requiring additional signal converters. This flexibility simplifies system design and improves compatibility with existing instrumentation.
High-Resolution Data Conversion
The BMXAMI0810H uses 16-bit analog-to-digital conversion technology to provide accurate process measurement data, supporting applications where precise monitoring and control are required.
Reliable Modicon X80 System Integration
The module integrates directly into Modicon X80 architectures and can be used with Schneider Electric automation systems, providing a scalable solution for expanding analog measurement capabilities.
