Brand:Schneider PLC Item No.:BMXCPS4022H Product Origin:France Product Dimensions:250 x 178 x 90 mm Product Weight:0.81 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
Introduction to Schneider BMXCPS4022H Redundant Power Supply Module
The Schneider BMXCPS4022H Redundant Power Supply Module is a high-performance industrial power component developed for Schneider Electric Modicon X80 automation systems. It provides a reliable electrical foundation for PLC controllers, I/O modules, and communication devices operating in demanding industrial applications.
Designed with redundancy and severe-environment capability, the BMXCPS4022H helps automation engineers build control systems with improved fault tolerance and operational continuity. Its intelligent diagnostic functions allow maintenance teams to monitor system health and respond quickly to potential power-related issues.
For system integrators, OEM manufacturers, and industrial maintenance professionals, this power supply module delivers a practical solution for expanding Modicon X80 installations, improving system reliability, and supporting high-availability automation architectures.
Temperature Sensing, Redundancy Test, Uptime Monitoring, Remaining Lifetime Monitoring
Compatible Platforms
Modicon M340 / Modicon M580 / Modicon X80
Backplane Compatibility
All Modicon X80 Backplanes
Operating Temperature
-25 to 70 °C
Mounting Type
Rack Mount
Dimensions
250 × 178 × 90 mm
Weight
0.81 kg (1.79 lb)
Recommended Related Models
Model
Product Type
Schneider BMXCPS4022
Redundant Power Supply Module
Schneider BMXCPS3522H
125 V DC Redundant Power Supply Module
Schneider BMXCPS3540T
Extended Temperature Power Supply Module
Schneider BMXCPS3500H
Hardened Power Supply Module
Schneider BMEXBP0800
8-Slot Ethernet Backplane
Popular Related Models
Model
Application Category
Schneider BMEP586040
Modicon M580 Independent Processor
Schneider BMENOP0300
Communication Module
Schneider BMXCRA31200
Remote I/O Adapter Module
Schneider BMXAMI0810H
Hardened Analog Input Module
Schneider BMXAMO0410H
Hardened Analog Output Module
Applications and High-Reliability Industrial Power Solutions
The Schneider BMXCPS4022H Redundant Power Supply Module is a hardened DC power supply module designed for the Modicon X80 automation platform, providing stable and redundant power delivery for PLC processors, I/O modules, and industrial communication components. This module is engineered for severe industrial environments where continuous operation, enhanced system availability, and reliable power management are essential.
The BMXCPS4022H is widely applied in process automation, energy management, transportation systems, manufacturing plants, water treatment facilities, and critical infrastructure control applications. Supporting 24–48 V DC input power, it provides regulated backplane power for Modicon X80 racks while supporting redundant architectures that help reduce the risk of unexpected system shutdowns.
With its hardened construction, advanced diagnostics, and compatibility with Schneider Electric Modicon M340 and M580 systems, the BMXCPS4022H offers engineers a dependable power solution for automation projects requiring improved availability and long-term operational stability.
Power System Advantages and Industrial Reliability Features
Hardened Design for Severe Operating Environments
The BMXCPS4022H is developed for harsh industrial conditions and features enhanced environmental resistance compared with standard versions. The hardened design allows reliable operation in applications with wider temperature ranges and demanding installation environments.
Redundant Power Architecture for Improved Availability
The module supports redundant power configurations, allowing automation systems to maintain higher availability by reducing dependency on a single power source. This makes it suitable for mission-critical control applications where downtime must be minimized.
Wide 24–48 V DC Input Compatibility
The BMXCPS4022H accepts a broad DC input range, providing flexibility for industrial power infrastructures and simplifying integration into existing control systems.
Integrated Protection Functions
Built-in overload protection, overvoltage protection, and short-circuit protection help safeguard connected automation devices and improve overall system reliability.
Advanced Diagnostic Monitoring Capability
The module provides intelligent monitoring functions including temperature sensing, redundancy testing, uptime monitoring, and remaining lifetime information, helping maintenance teams improve preventive maintenance efficiency.
