Introduction
The HIMA F-PWR 01 Power Supply Module is a key power management component for HIMA HIQuad X safety automation systems. It provides dependable energy conversion and distribution to critical system modules, ensuring stable operation of safety controllers and connected I/O components.
Designed for demanding industrial environments, the F-PWR 01 combines reliable power performance, redundancy support, and modular installation flexibility. It helps organizations build robust safety architectures for continuous process protection, emergency shutdown applications, and other high-integrity automation functions.
Technical Specifications
| Specification | Details |
|---|
| Manufacturer | HIMA |
| Model | F-PWR 01 |
| Order Number | 984714100 |
| Module Type | Power Supply Module |
| Product Family | HIQuad X Safety System |
| Compatible Systems | H41X / H51X / HIQuad X |
| Function | System Power Conversion and Distribution |
| Input Voltage | 100–240 VAC |
| Output Voltage | 24 VDC / 5 VDC |
| Rated Power | Approx. 50 W |
| Redundancy Function | Supported |
| Safety Application | SIS, ESD, Process Protection |
| Safety Level | SIL 3 Compatible |
| Installation Type | 19-inch Rack Mounting |
| Protection Class | IP20 |
| Dimensions | Approx. 267 × 40 × 220 mm |
| Weight | Approx. 0.5 kg |
Recommended Companion Models
| Model | Product Name |
|---|
| F-CPU 01 | HIMA HIQuad X CPU Module |
| F-IOP 01 | HIMA HIQuad X I/O Processing Module |
| F-COM 01 | HIMA HIQuad X Communication Module |
| F-BASE RACK 01 | HIMA HIQuad X Base Rack Module |
Frequently Selected Alternatives
| Model | Product Name |
|---|
| F-PWR 02 | HIMA HIQuad X Power Supply Module |
| PS 1000/230/01 | HIMA Industrial Power Supply Unit |
| F60 PS 01 | HIMA HIMatrix F60 Power Supply Module |
| K9203A | HIMA Rack Fan Module with Redundant Supply |
Technical FAQs
1. What is the primary function of the HIMA F-PWR 01?
The HIMA F-PWR 01 is a Power Supply Module designed to provide stable operating power for HIMA HIQuad X safety system components.
2. Which HIMA systems are compatible with the F-PWR 01?
The module is designed for HIMA H41X, H51X, and HIQuad X safety automation systems.
3. What type of power conversion does the F-PWR 01 provide?
The module converts input power into regulated DC outputs required by HIMA safety system modules, including system logic supply voltages.
4. Is the F-PWR 01 suitable for SIL 3 applications?
Yes. When integrated into an approved HIMA safety system architecture, it supports SIL 3 safety applications.
5. Can the F-PWR 01 operate in redundant configurations?
Yes. Multiple power modules can be configured in parallel redundancy arrangements to improve system availability.
6. What modules receive power from the F-PWR 01?
The module supplies power for components such as CPU modules, I/O processing modules, and communication modules within the HIQuad X system.
7. Does the F-PWR 01 provide diagnostic functions?
Yes. The module supports monitoring functions for power status and system operating conditions.
8. Is the F-PWR 01 a control processing module?
No. The F-PWR 01 only provides power conversion and distribution functions. Safety logic processing is performed by CPU modules such as the F-CPU 01.
9. What is the difference between F-PWR 01 and F-PWR 02?
The F-PWR 01 is the main power supply module, while F-PWR 02 is designed as an additional power-related module for system expansion and support functions.
10. Why use a dedicated safety power module instead of a standard industrial power supply?
A dedicated safety power module provides better compatibility, monitoring capability, and integration with certified safety automation architectures.
