ABB 07KT94G / 07KT94I Thermocouple Input Modules

Introduction

The ABB 07KT94G and ABB 07KT94I are high-precision thermocouple input modules designed to offer exceptional performance in temperature monitoring and control applications. These modules are optimized for integration with ABB’s automation systems and support up to 8 thermocouple inputs. With their flexibility in handling multiple thermocouple types and wide temperature range, the 07KT94G and 07KT94I modules are ideal for industrial applications in power generation, chemical processing, HVAC systems, and other industries requiring precise temperature data. Both modules are built for high reliability and offer ease of installation and maintenance in demanding environments.

Technical Specifications

Specification	07KT94G	07KT94I
Model	07KT94G	07KT94I
Module Type	Thermocouple Input Module	Thermocouple Input Module
Number of Inputs	8	8
Input Types	Type J, K, T, E, R, S, B, N, L	Type J, K, T, E, R, S, B, N, L
Input Range	-200°C to +1800°C	-200°C to +1800°C
Resolution	16-bit	16-bit
Size (W x H x D)	120 x 125 x 55 mm	120 x 125 x 55 mm
Weight	0.55 kg	0.55 kg
Mounting Type	DIN Rail	DIN Rail
Operating Temperature	-20°C to +60°C	-20°C to +60°C
Certifications	CE, UL, RoHS	CE, UL, RoHS

Recommended Related Models

Model	Module Type	Input Type	Number of Inputs
ABB 07KT92	Thermocouple Input Module	Type J, K, T, E, R, S, B	8
ABB 07KT93	Thermocouple Input Module	Type J, K, T, E, R, S, B	16
ABB 07KT94	Thermocouple Input Module	Type J, K, T, E, R, S, B	8
ABB 07KT94G	Thermocouple Input Module	Type J, K, T, E, R, S, B	8
ABB 07KT94I	Thermocouple Input Module	Type J, K, T, E, R, S, B	8

Popular ABB Models

Model	Module Type	Input Type	Number of Inputs
ABB 07KT90	Thermocouple Input Module	Type J, K, T, E	4
ABB 07KT92	Thermocouple Input Module	Type J, K, T, E, R, S, B	8
ABB 07KT93	Thermocouple Input Module	Type J, K, T, E, R, S, B	16

Applications

Advantages

Technical FAQs

What thermocouple types are supported by the ABB 07KT94G/07KT94I modules?
The modules support Type J, K, T, E, R, S, B, N, and L thermocouples.

What is the temperature input range for the ABB 07KT94G/07KT94I modules?
The modules support a temperature range of -200°C to +1800°C.

How many thermocouple inputs do the ABB 07KT94G/07KT94I modules have?
Each module has 8 thermocouple inputs.

What is the resolution of the ABB 07KT94G/07KT94I modules?
Both modules provide 16-bit resolution for highly accurate temperature measurements.

What are the size dimensions of the ABB 07KT94G/07KT94I modules?
The modules are 120 x 125 x 55 mm in size.

How much do the ABB 07KT94G/07KT94I modules weigh?
Each module weighs 0.55 kg.

What is the operating temperature range for these modules?
The modules operate within a temperature range of -20°C to +60°C.

How are the ABB 07KT94G/07KT94I modules mounted?
The modules are designed for DIN rail mounting.

Are the ABB 07KT94G/07KT94I modules certified for safety?
Yes, both modules are CE, UL, and RoHS certified.

Can the ABB 07KT94G/07KT94I modules be used for power generation applications?
Yes, these modules are ideal for temperature monitoring in critical power generation applications, such as turbines and boilers.
