Ingersoll Rand 47704436001 / 24900433 Oil Filter Element

Where It Excels in Industrial Use

• Rotary Screw Compressor Lubrication: Helps remove contaminants from compressor lubricant before the oil returns to the airend and cooling circuit.
• RS-Series Compressor Service: Suitable for compatible Ingersoll Rand RS-series compressors using the 24900433 oil filter element, including a range of RS11–RS37 configurations.
• High-Utilization Industrial Systems: Supports clean lubricant circulation in compressors operating for long production cycles and demanding service conditions.
• Preventive Maintenance: Provides a practical replacement component for scheduled oil-filter service, helping maintain filtration performance and protect lubrication-sensitive components.

Key Strengths at a Glance

• Efficient Oil Filtration: Helps remove particles and debris from compressor lubricant before circulation through critical components.
• Airend Protection: Cleaner lubricant helps reduce the contaminant load reaching the compressor airend.
• Stable Lubrication: Supports consistent oil circulation and helps maintain the intended lubrication system condition.
• Spin-On Filter Design: The 24900433 is identified as an oil filter element and is used as a spin-on filter for applicable Ingersoll Rand compressor configurations.

Technical FAQs

1. What is the primary function of Ingersoll Rand 47704436001 / 24900433?

The product is an oil filter element designed to remove contaminants from compressor lubricant before the oil is returned to the compression and cooling system.

2. Why is oil filtration important in a rotary screw compressor?

Compressor lubricant performs cooling, sealing, and lubrication functions. Removing particles and debris from the oil helps protect the airend and other components that depend on clean lubricant.

3. What type of filter is 24900433?

The 24900433 is identified as an oil filter element and is used as a spin-on oil filter for compatible Ingersoll Rand compressors.

4. Which Ingersoll Rand compressors use 24900433?

Available compressor documentation lists 24900433 among the recommended consumables for RS11–22i and RS15–22n configurations, while application listings also associate it with RS-series models extending through RS37. Exact compatibility should be verified against the compressor model and serial number.

5. What contaminants does the oil filter remove?

The filter is intended to capture particulate contamination present in the compressor lubricant, including wear particles and other debris that could otherwise circulate through the lubrication system.

6. What can happen if the oil filter becomes excessively restricted?

A heavily loaded filter can increase pressure drop through the lubrication circuit and interfere with normal oil circulation. This can negatively affect compressor operation and should be addressed according to the applicable maintenance procedure.

7. Can a dirty oil filter affect compressor temperature?

Potentially. Lubricant is also responsible for carrying heat away from the compression process. If oil circulation becomes restricted, the compressor's thermal behavior can be affected.

8. How often should 24900433 be replaced?

Replacement should follow the maintenance schedule specified for the particular compressor. Available service information for compatible RS-series equipment indicates oil-filter replacement as part of scheduled maintenance, with some applications specifying replacement at least annually or every 4,000 operating hours.

9. Can 24900433 be used as a universal Ingersoll Rand oil filter?

No. Ingersoll Rand uses different filter configurations across its compressor ranges. The existing filter number, compressor model, serial number, and applicable parts documentation should be checked before ordering.

10. What should be checked when installing a new 24900433?

The filter should be checked for correct part number, sealing condition, installation orientation, and proper seating. After installation, the compressor should be inspected for oil leakage and normal operating pressure and temperature.
