Brand:Ingersoll Rand Item No.: 47704458001 / 2362951 Product Origin:USA Product Dimensions:202 × 21 × 261 mm Product Weight:0.08 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Ingersoll Rand 47704458001 / 23629512 Compressor Controller is an electronic control component for compatible Ingersoll Rand rotary screw compressor systems.
The primary verified component, 23629512, is an XE-90M standard controller. Ingersoll Rand parts documentation identifies this controller in applicable starter-box assemblies and lists 23711288 as the enhanced-controller alternative.
The XE-90M platform is designed to provide compressor control together with diagnostic and monitoring capabilities. Published technical descriptions include performance logging, trend analysis, alarm/report functions, and communication with external control systems.
This type of controller is particularly important during electronic maintenance because replacement is not simply a matter of matching the physical connector. Software, compressor configuration, control architecture, and machine-specific settings can all affect successful commissioning.
The supplied 47704458001 / 23629512 references are therefore retained as one product listing, while the confirmed technical identity is based primarily on the well-documented 23629512 XE-90M controller reference.
Technical Specifications
Specification
Details
Brand
Ingersoll Rand
Primary Part Number
47704458001
Corresponding Reference
23629512
Product Type
Compressor Controller
Controller Model
XE-90M
Controller Configuration
Standard
Application
Rotary Screw Air Compressor Control
Primary Function
Compressor Control, Monitoring and Diagnostics
Control System
Ingersoll Rand XE-Series
Communication
Configuration-dependent; supports industrial communication functions
Not reliably verified from available technical documentation
Electrical Specifications
Configuration-specific; verify OEM documentation
Compatibility
Model-, serial-number and software-configuration dependent
23629512 is described as an XE-90M controller, while one technical listing specifies an operating supply range of 10.9–26.4 VDC and approximately 0.45 A consumption, with triac and relay outputs. These electrical values should be confirmed against the exact controller revision before installation.
Reliable product-level dimensions and weight for the exact 47704458001 / 23629512 listing were not sufficiently verified, so they should be confirmed from the supplied controller or applicable OEM documentation.
Recommended Companion Models
Model
Product Name
23711288
Ingersoll Rand XE-145M Enhanced Controller
24474652
Ingersoll Rand Xe Controller Retrofit Kit
24474660
Ingersoll Rand Xe Controller Retrofit Kit
24496788
Ingersoll Rand Xe-90M Controller Retrofit Kit
These references are associated with Ingersoll Rand Xe-controller upgrades and related control configurations. In particular, Ingersoll Rand's retrofit documentation identifies retrofit kits for Xe90M and Xe145M applications and specifies 23629512 as the Xe90M controller.
Frequently Selected Alternatives
Model
Product Name
23711288
Ingersoll Rand XE-145M Controller
39875158
Ingersoll Rand Compressor Controller
39817655
Ingersoll Rand Compressor Controller
54642129
Ingersoll Rand Compressor Controller
Where It Excels in Industrial Use
Compressor Control and Monitoring: The supplied 47704458001 / 23629512 references are treated as one product listing. The verified component identity is 23629512, Ingersoll Rand XE-90M controller, used for compressor control, monitoring, diagnostics, and operating management.
Rotary Screw Compressor Applications: 23629512 is documented as an XE-90M controller for Ingersoll Rand rotary screw compressor equipment. Parts documentation also identifies it as a standard controller in applicable R-Series starter-box assemblies.
Industrial Control Replacement: The controller can serve as a replacement for a failed or obsolete standard controller where the compressor configuration calls for the XE-90M platform.
Compressor Automation: The XE-Series controller provides operating control, diagnostics, data logging, and connectivity functions designed for modern compressed-air system management.
Key Strengths at a Glance
XE-90M Platform: 23629512 is specifically identified as an XE-90M controller, providing a defined control platform rather than a generic PLC module.
Standard Controller Configuration: Ingersoll Rand parts documentation lists 23629512 as Controller (Standard), with 23711288 identified separately as the enhanced controller.
Advanced Compressor Management: The XE-90M platform supports diagnostics, data logging, trend analysis, and communication functions for compressor operation.
Service and Retrofit Potential: Ingersoll Rand documentation describes Xe90M retrofit kits that include the controller, associated plugs, gasket where required, electrical documentation, and installation instructions.
Technical FAQs
1. What is Ingersoll Rand 47704458001 / 23629512?
The supplied references are treated as one product listing. The clearly verified component identity is 23629512, XE-90M compressor controller. Public parts catalogs also associate 47704458001 with Ingersoll Rand controller references.
2. What type of controller is 23629512?
23629512 is an XE-90M standard compressor controller. Ingersoll Rand parts documentation lists it as the standard controller, with 23711288 serving as the enhanced alternative in applicable assemblies.
3. What is the main function of the XE-90M controller?
It manages compressor operating functions and provides monitoring, diagnostic, logging, and communication capabilities for the connected compressed-air system.
4. Which compressor families can use 23629512?
Published documentation identifies 23629512 in applicable R-Series rotary screw compressor assemblies, including R37ie/R45i/R37ne/R45n documentation and R90–160 configurations. Exact compatibility depends on the machine's control architecture and serial number.
5. Is 23629512 the same as 23711288?
No. Both are controller assemblies, but Ingersoll Rand documentation identifies 23629512 as the standard controller and 23711288 as the enhanced controller for applicable assemblies.
6. Can the controller be installed without configuration?
Not necessarily. Controller software and machine-specific configuration may need to be programmed or verified after installation. Ingersoll Rand's retrofit documentation specifically recommends programming the new XE controller and checking configuration after installation.
7. What communication capabilities does the XE controller provide?
The XE-Series platform supports communication with systems such as DCS through Modbus, Xi System Controls, and Ethernet-based connectivity depending on the controller and system configuration.
8. What should be checked when replacing 23629512?
Verify the compressor model, serial number, existing controller part number, software configuration, electrical connections, and whether the machine requires the standard or enhanced controller.
9. Can a failed controller affect compressor operation?
Yes. Because the controller manages critical operating and monitoring functions, a controller fault can prevent normal starting, loading, unloading, alarm handling, or communication with other compressor-control components.
10. Is 47704458001 a confirmed direct supersession of 23629512?
The available public evidence supports the association of 47704458001 with the controller family but does not establish a sufficiently authoritative OEM supersession statement. Therefore, the two supplied references are treated as one listing while final replacement should be verified against the compressor's parts documentation.
