The ABB TP853 Power Supply Module is a robust and high-performance 24V DC power supply designed to meet the demanding power requirements of large-scale industrial automation systems. With an impressive 150A output capacity, the TP853 delivers continuous and stable power to PLCs, sensors, actuators, robots, and a wide range of industrial control equipment. This power supply is built to provide exceptional reliability, efficiency, and long-term performance in critical industrial environments.

With an efficiency of up to 98%, the ABB TP853 helps to significantly reduce energy consumption, minimize heat generation, and lower operational costs. Its rugged design and integrated protection features ensure it remains a dependable solution for demanding applications in manufacturing, material handling, HVAC, energy management, and more.

Technical Specifications

Specification	Details
Model	TP853 Power Supply Module
Input Voltage	85-265 VAC, 47-63 Hz
Output Voltage	24V DC ±1%
Nominal Output Current	150A
Efficiency	98% (at full load)
Operating Temperature	-10°C to 70°C (14°F to 158°F)
Weight	22 kg (48.5 lbs)
Dimensions (W x H x D)	600 x 550 x 350 mm (23.62 x 21.65 x 13.78 inches)
Cooling Type	Forced Air Cooling
Protection Features	Overvoltage, Overcurrent, Overtemperature, Short Circuit, Surge Protection
Mounting Type	DIN Rail Mounting
Certifications	CE, UL, RoHS

Recommended Related Models

ABB offers a range of power supply solutions suitable for various industrial applications. Here are related models that complement the TP853:

ABB TP850: A 120A power supply, ideal for high-demand systems that require reliable 24V DC power for medium-scale automation.
ABB TP820: A 100A power supply solution for large systems that need continuous and efficient 24V DC power delivery.
ABB TC530: A 50A power supply for mid-range industrial systems, offering reliable power for smaller-scale automation and control.
ABB TB850: A 120A high-output power supply for large-scale industrial setups with demanding power requirements.
ABB DCS 800 Series: A modular power supply system offering scalability and flexibility, suitable for complex, high-power industrial needs.

Popular ABB Models

ABB is renowned for providing reliable and high-performance industrial solutions. Here are some of the most popular products from ABB:

ABB ACS580: A variable frequency drive (VFD) that improves motor efficiency and performance, designed for industrial applications.
ABB IRB 6700: A versatile industrial robot used in applications like welding, assembly, and material handling, known for its precision and speed.
ABB SD880: A power supply solution that offers stable and reliable 24V DC output, ideal for large and complex automation systems.
ABB PPM500: A power protection module designed to safeguard critical equipment against power surges and electrical issues.
ABB MNS 3.0: A modular power distribution system ideal for large facilities, providing efficient energy management and reliable power distribution.

Applications

The ABB TP853 Power Supply Module is designed to support a wide range of industrial applications where high-output, reliable power is required. These include:

Industrial Automation: Powers PLCs, sensors, actuators, and robotic systems in large automated manufacturing lines, control systems, and assembly operations.
Manufacturing: Provides stable 24V DC power to automated production lines, CNC machines, robotic arms, and other critical manufacturing equipment.
Material Handling: Powers material handling systems such as conveyors, automated sorters, and automated storage/retrieval systems (ASRS) used in warehouses, distribution centers, and logistics operations.
HVAC Systems: Supplies power to HVAC control systems in industrial buildings, factories, and large commercial spaces, optimizing temperature regulation and energy efficiency.
Energy Management: Ideal for use in power plants, smart grids, renewable energy systems, and energy distribution applications, ensuring reliable and efficient power management.

Advantages

High Output Capacity: The 150A output ensures the TP853 can supply sufficient power for large-scale systems with high power demands.
High Efficiency: The TP853 operates with 98% efficiency, reducing energy loss, heat generation, and overall operational costs.
Built-In Protection: Includes advanced protection features such as overvoltage, overcurrent, short-circuit, thermal overload, and surge protection to safeguard both the power supply and the connected equipment.
Compact and Durable: Despite its high-output capacity, the TP853 is designed to be space-efficient and rugged, capable of withstanding harsh industrial environments.
Wide Operating Temperature Range: The TP853 functions reliably in temperatures ranging from -10°C to 70°C (14°F to 158°F), making it suitable for various industrial conditions.
Global Compatibility: The input voltage range of 85-265 VAC ensures compatibility with international power standards, providing flexibility for global installations.
Easy Installation: Designed for DIN rail mounting, the TP853 can be easily installed in control panels, reducing setup time and improving system integration.

Technical FAQs

What input voltage range does the ABB TP853 support?
- The TP853 operates within an input voltage range of 85-265 VAC, which makes it compatible with a wide variety of global electrical standards.
What is the efficiency of the ABB TP853?
- The TP853 achieves 98% efficiency at full load, ensuring minimal energy waste and reducing heat generation for a more energy-efficient system.
What protection features are included in the TP853?
- The TP853 offers comprehensive protection features, including overvoltage, overcurrent, thermal overload, short-circuit, and surge protection, ensuring the safety of both the module and connected equipment.
How much current can the TP853 supply?
- The TP853 can provide up to 150A of 24V DC power, making it ideal for large, power-hungry industrial systems and applications.
Can the TP853 be used outdoors?
- The TP853 is designed for indoor use but can be used outdoors if installed inside a protective enclosure that shields it from environmental elements.
What is the operating temperature range for the TP853?
- The TP853 operates effectively in environments with temperatures ranging from -10°C to 70°C (14°F to 158°F).
How is the ABB TP853 mounted?
- The TP853 is designed for DIN rail mounting, ensuring a fast, secure installation in control panels or industrial enclosures.
What are the dimensions and weight of the ABB TP853?
- The TP853 measures 600 x 550 x 350 mm (23.62 x 21.65 x 13.78 inches) and weighs 22 kg (48.5 lbs).
Is the TP853 suitable for larger systems?
- Yes, with its 150A output, the TP853 is ideal for high-demand industrial systems. For even larger systems, ABB offers models like the TB850 (200A).
Can the TP853 be integrated with other ABB products?
- Yes, the TP853 is fully compatible with other ABB automation and control solutions, allowing for seamless integration into existing or new industrial systems.
